  1. Moa Products Moa Telecom Co. Ltd Aug. 2011

  2. Major Business Area : Manufacturing • PoE (Power over Ethernet) • PoE refers to the ability to carry electrical power over a standard Ethernet cable-the same one used • today for transferring data. PoE allows IP telephones, WLAN APs(Access Point) and Web cams to • receive power as well as data over existing LAN cabling, without any requirement to modify the • existing Ethernet infrastructure. After ratification of the IEEE802.3af -2003 standard on June 2003 • for 12.95W delivery to PD, growth in PoE devices and installation has been increased, also • IEEE802.3at-2009 known as PoE+ or PoE Plus for higher power delivering 25W to PD was also • ratified 2009. • xDSL POTS(Plain Old Telephone Set) Splitter • The xDSL POTS splitter enables simultaneous use of telephone and high speed Internet linkage • using xDSL modem by mixing and separating digital signal and analog signal. • Ethernet Surge Protector • appliance designed to protect Ethernet devices from voltage spikes. A surge protector attempts to • regulate the voltage supplied to an electric device by either blocking or by shorting to ground • voltages above a safe threshold. • Magnetic Components for Telecom Industry • RF Module, Parts • HIC

  3. PoE(Power over Ethernet) • Power Over Ethernet technology allows IP telephones, wireless LAN Access Points and other embedded computer appliances to receive power as well as data over existing CAT5 LAN cabling. Established as an IEEE standard, Power over Ethernet offers new options to system designers by providing economical and flexible deployment of networked devices.

  4. PoE Key Benefits • Installation Cost Savings • Eliminates the need for electrical outlet installation • Dramatically reduces cost of deployment-saving up to $1,000 per PD • No need for bulky AC power adapter • Simplifies Installation • Uses a single Cat5/5e/6 cable for both data and power • Centralized Power Backup • Continuous operation during power interruptions • Centralized Power Management • Devices can be remotely powered down during periods of low usage or for security purposes • SAFE Power • Will not damage Non-PoE devices or legacy periperals

  5. PSE(Power Sourcing Equip) vs PD(Powered Device) of PoE products

  6. PSE(Power Sourcing Equipment) vs PD(Powered Device) • Power sourcing equipment (PSE) is a device such as a switch that provides ("sources") power on the Ethernet cable. The maximum allowed continuous output power per cable in IEEE 802.3af is 15.40 W. A later specification, IEEE 802.3at, offers 25.50 W. When the device is a switch, it's called an endspan. Otherwise, if it's an intermediary device between a non PoE capable switch and a PoE device, it's called a midspan. An external PoE injector is a midspan device • A powered device (PD) is a device powered by a PSE and thus consumes energy. Examples include wireless access points, IP Phones, and IP cameras. Many powered devices have an auxiliary power connector for an optional, external, power supply. Depending on the PD design, some, none, or all power can be supplied from the auxiliary port, with the auxiliary port sometimes acting as backup power in case of PoE supplied power failure. PDs are usually built in WAP, VoIP, Web Camera and for the legacy devices without built in PD, PoE function can be enabled by Splitter type PDs.

  7. PoE Products Family Cat5 Cable PSE, Midspan PD Single Port Adaptor Type Built In Type Network Switch 15.4W 30W 20W Multi Port Type Splitter Type Data Power

  8. PSE Product Series, Single Port Adaptor Type Mid Span • MPSE 4803 • Compliant with IEEE802.3af(PD Discovery, Classification, Current Limit, DC/AC Load Disconnection Detection), Non-Vented Case, Full Protection, Field Proven Quality • Applicable to IP Phones, WiFi AP, Wimax AP, Security Camera, etc • Safety approved - cUL/UL, CE, ITE • Inputs : AC Inlet :90-264VAC, 47-63Hz( Free Voltage ) • RJ45Jack :10/100 Base T Data • Outputs : RJ45Jack : DC48V, 0.32A Max.(15.4W) and 10/100 Base T Data • 75% Efficiency and 4% Line/Load Regulation, FCC Part 15 Class B • 140mm(L) X 62mm(W) X 35mm(H), 160 gr Data RJ45 AC Inlet AC In Data RJ45 DC Out MPSU 4803 • No IEEE802.3af Function, to minimize Cost, All others are exactly same as MPSE4803

  9. PSE Product Series, Single Port Adaptor Type Mid Span-Cont. MPSE 4804 • Compliant with IEEE802.3af(PD Discovery, Classification, Current Limit, DC/AC Load Disconnection Detection), Non-Vented Case, Full Protection, Field Proven Quality • Applicable to IP Phones, WiFi AP, Wimax AP, Security Camera, etc • Safety approved - cUL/UL, CE, ITE; in Process • Inputs : AC Inlet :90-264VAC, 47-63Hz( Free Voltage ), RJ45Jack :10/100 Base T Data • Outputs : RJ45Jack : DC48V, 0.42A Max.(20W) and 10/100 Base T Data • 75% Efficiency and 4% Line/Load Regulation, FCC Part 15 Class B • 150mm(L) X 65mm(W) X 36mm(H), 205 gr AC In Data RJ45 AC Inlet Data RJ45 MPSU 4804 DC Out • No IEEE802.3af Function, to minimize Cost, All others are exactly same as MPSE4804

  10. PSE Product Series, Single Port Adaptor Type Mid Span-Cont. MPSE 4805 • Compliant with IEEE802.3af/at(PD Discovery, Classification, Current Limit, DC/AC Load Disconnection Detection), Vented Case, Full Protection, Field Proven Quality • Applicable to IP Phones, WiFi AP, Wimax AP, Security Camera, etc • Safety approved - cUL/UL, CE, ITE; in Process; In Process • Inputs : AC Inlet :90-264VAC, 47-63Hz( Free Voltage ), RJ45Jack :10/100 Base T Data • Outputs : RJ45Jack : DC48V, 0.63A Max.(30W) and 10/100 Base T Data • 75% Efficiency and 4% Line/Load Regulation, FCC Part 15 Class B • 143mm(L) X 83mm(W) X 44mm(H) AC In Data RJ45 AC Inlet Data MPSU 4805 RJ45 DC Out • No IEEE802.3af/at Function, to minimize Cost, All others are exactly same as MPSE4805

  11. PD Products, Built In Module Types(rev.1, 12/20/’10) These modules are designed as embedded isolated PD solutions and extract power from Power Sourcing Equipment (PSE) via conventional Category 5 Ethernet cable and convert the DC voltage from PSE to DC voltage as needed for terminals.

  12. PD Products, Built In Module Types, Photos

  13. PD Products, Splitter Types A splitter enables easy integration of the Power over Ethernet technology into legacy Equipment(w/o PoE function). Using the same infrastructure, without making any modifications to the end points, already designed legacy devices, such as Wireless LAN access points and IP telephone sets become Power over Ethernet enabled when connected to the active splitter. MPD-xxV-N • Single Port Splitter Type PD(Powered Device) per IEEE 802.3af • Input : DC 48V(typ.) + 10/100 Base T Data thru RJ45 Jack • Output : 13W(@ 3.3 or 5 or 12V DC Typ.) thru DC Plug and 10/100 Base T Data thru RJ45 Plug • Input to Output Isolated 1,500 Vrms min. • Line Regulation; 1% max. and Load Regulation 3% max. • Efficiency : 80% min. • Overload protected • Dimension : 95mm(L) X 35mm(W) X 24mm(H) 10/100 Base T Data DC 48V(typ.) -To legacy NIC 10/100 Base T Data From PSE 13W(@ 3.3 or 5 or 12V DC Typ.) -To legacy NIC

  14. PD Products, Splitter Types-Cont. MPD-xxV • Single Port Splitter Type PD(Powered Device) per IEEE 802.3af • Input : DC 48V(typ.) + 10/100 Base T Data thru RJ45 Jack • Output : 13W(@ 3.3 or 5 or 12V DC Typ.) thru DC Plug and 10/100 Base T Data thru RJ45 Plug • Input to Output Isolated 1,500 Vrms min. • Line Regulation; 1% max. and Load Regulation 3% max. • Efficiency : 80% min. • Overload protected • Dimension : 95mm(L) X 35mm(W) X 24mm(H) 10/100 Base T Data To legacy terminal 13W(@ 3.3 or 5 or 12V DC Typ.) DC 48V(typ.) From PSE 10/100 Base T Data

  15. xDSL POTS Splitter Products A filtering device to separate high frequency signals(Data) and low frequency signals(Voice) coexisting over same pair of subscriber line located at both ends of the line, CO(Central Office) and CP(Customer Premises). The filtering should be preformed while maintaining the quality of the end-to-end.Our solutions covers ANSI T1.413 600 Ω, 900 Ω of the same standard, ITU-T G.992.1(Full DMT) type 1 Zcomplex(n) for Europe, type 2 for North America, type 3 for ISDN and type 4 for Japan. * xDSL POTS Splitter CPE & Micro Filter * xDSL POTS Splitter(CO) 54-Plug Type Splitter can be installed into MAT54 Terminal block which is Installed on existing MDF saving floor space and wiring in half. Easy installation, per line basis maintenance and inventory control are the major features of this product. MAT54 Terminal Block Plug Type Splitter

  16. xDSL POTS Splitter Products • It is filtering device to separate high frequency signals(Data) and low frequency signals(Voice) coexisting over same pair of subscriber line located at both ends of the line, CO(Central Office) and CP(Customer Premises). The filtering should be preformed while maintaining the quality of the end-to-end.Our solutions faithfully cover • ANSI T1.413 600 Ω, 900 Ω of the same standard, • ITU-T G.992 Series Recommendation • ETSI TS 101 952 Series Standards • ETSI TS 101 388 • ETSI TS 101 270 Series • ETSI TS 101 524 • ETSI TS 102 080 • Etc • xDSL boom was triggered in Korea on 2000, we were the first runner in developing xDSL POTS Splitter, • occupying more than 60% Korean market share and have supplied to the overseas as Russia, Philippine, Japan, USA, England, Iran, Macedonia, Kuwait, Singapore, Pakistan, Slovenia, Germany

  17. xDSL POTS Splitter for CO(Central Office) High Density xDSL Splitter Boards MDF Terminal Block and per channel Plug type Splitter Incased Mat54 MDF Terminal Block for Splitter Plug type Splitter Clock here to see the detail

  18. * xDSL POTS Splitter & Micro Filter for CP(Customers’ Premises)

  19. Ethernet Surge Protectors Ethernet Surge Protectors for Category-5e must meet Category 5e Connecting Hardware Limits per ANSI/TIA/EIA-568B.2 and for Category-6 must meet Category 6 Connecting Hardware Limits per ANSI/TIA/EIA-568B.2-1

  20. MSP-CAT5-CO Ethernet Surge Protector Block Diagram

  21. MSP-CAT5-CO Ethernet Surge Protector-Cont. Outline Drawing SM or GM Module Terminal Block

  22. MSP-CAT5-CO Ethernet Surge Protector-Cont. Appearance SM Module GM Module

  23. MSP-CAT5-CO Ethernet Surge Protector-Cont.

  24. MSP-CAT5-CO Ethernet Surge Protector-Cont.

  25. Magnetic Components for Telecom Industry

  26. Magnetic Components – PoE PD Transformers PoE PD 13W and 30W application, Flyback as well as Forward converter topology. Provides output voltages as required such as 3.3, 5, 12 Volt DC. 1,500 Vrms minimum Isolation Primary and Bias windings to the Secondary. They are usually designed to work at 250 kHz with an input of 36 – 72 Volts typically. These products have been tested by using in house PoE products and installed in the public network for several years. Custom design is welcomed. EFD2124, 30W EFD1525, 13W EP13, 13W

  27. Magnetic Components – misc Common Mode Chokes

  28. RF Components and HICs Hybrid Power Splitter/Combiners Directional Coupler HIC
