千分尺的读数

千分尺的读数. 千分尺结构及使用. 测微螺杆. 棘轮. 微分筒. 测砧. 固定套管. 测量范围 0~25mm. Ｕ型架. 准确度 0.01mm. 被测物体长度. d=d i － d 0 d i ---- 表示测量物体时读数 d 0 ---- 表示测微螺杆与测砧直接接 触时读数 , 称为 零点读数. 零点读数. 图 1 读数为 d 0 =+0.005mm. 图 1. 图２读数为 d 0 = － 0.015mm. 图 2. 测量物体时读数 d i. 图 4. 图 3. 图 5. 图 3 读数： d i = 0.500 mm

vernon
Télécharger la présentation

千分尺的读数

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 千分尺的读数

  2. 千分尺结构及使用 测微螺杆 棘轮 微分筒 测砧 固定套管 测量范围 0~25mm Ｕ型架 准确度 0.01mm

  3. 被测物体长度 d=di－d0 • di ----表示测量物体时读数 • d0 ----表示测微螺杆与测砧直接接 触时读数,称为零点读数

  4. 零点读数 • 图1读数为 d0=+0.005mm 图1 • 图２读数为 • d0=－0.015mm 图2

  5. 测量物体时读数di 图4 图3 图5 图3 读数： di=0.500mm 图4读数： di=0.515mm 图5读数： di=0.485mm

  6. 图6读数正确的是？ • 5.485mm • 5.485cm • 4.985mm (D) 4.985cm 图6
