Clustering in Microarray Data-mining and Challenges Beyond

1. CS491jh presentation March 7, 2002 Clustering in Microarray Data-mining and Challenges Beyond Qing-jun Wang Center for Biophysics & Computational Biology University of Illinois at Urbana-Champaign

2. Clustering What? Where? How? Challenges beyond clustering

3. Data Acquisition Data Processing • Experimental design • -MIAME • Replicates • Single/multiple slides • Perform experiment • Collect data • Grid alignment • Data quality • e.g. bad data, S/N • Missing data • Normalization • Total intensity normalization • Regression techniques • Ratio statistics

4. sam/ref Gene Expression Matrix (Affymetrix GeneChip® oligonucleotide arrays)

5. Gene Expression Matrix (glass slides)

6. Data Acquisition Data Processing • MIAME • Experiment design • Replicates • Single/multiple slides • Data quality • e.g. bad data, S/N • Grid alignment • Missing data • Normalization • Total intensity normalization • Regression techniques • Ratio statistics Data Analysis Re-scale Distance matrices Data Validation • Supervised analysis • e.g. SVM, K-nearest neighbor, decision trees, voted classification, weighted gene voting, Bayesian classification • Unsupervised analysis (clustering) • Hierarchical • Non-hierarchical (e.g. K-means, PCA-based clustering, self-organizing maps, block clustering,gene-shaving, plaid models)

7. Step 0 Step 1 Step 2 Step 3 Step 4 agglomerative (AGNES) a a b b a b c d e c c d e d d e e divisive (DIANA) Step 3 Step 2 Step 1 Step 0 Step 4 Hierarchical clustering Protocol • Calculate pairwise distance matrix • Find the two most similar genes or clusters • Merge the two selected clusters to produce a new cluster • Calculate pairwise distance matrix involving the new cluster • Repeat steps 2-4 until all objects are in one cluster • The clustering sequence is represented by a hierarchical tree – dendrogram.

8. Hierarchical clustering Variations – differ in how distances are calculated Single-linkage clustering – minimum distance Complete-linkage clustering – maximum distance Average-linkage clustering (UPGMA) Weighted pair-group average – use size of the clusters as the weights in computing averages Within-groups clustering Ward’s method – smallest possible increase in the sum of squared errors

9. Hierarchical clustering Bottom-up (agglomerative) approach One-way clustering Deterministic clustering Produce a greater number of clusters than k-means clustering – valuable feature for discovery. Produce an order for objects – informative for data display. Difficulties 1. As clusters grow in size, the expression vector that represents the cluster might no longer represent any of the genes in the cluster – an artifact 2. If a bad assignment is made early on, it cannot be corrected

10. Non-hierarchical clustering K-means clustering Top-down (divisive) approach Used when the number of clusters is known in advance One-way clustering Non-deterministic owing to the random initialization Produce tighter clusters than hierarchical clustering Protocol • Initial reference vectors are assigned randomly or according to previous knowledge • Assign each object to one of k clusters randomly • Calculate average expression vectors for each cluster (as reference vectors) and the distance between clusters • Iteratively move objects between clusters and the objects stay in the new cluster when they are closer to the new cluster than to the old cluster. • Repeat steps 3-4 until converge, i.e. moving any more objects would increase intra-cluster distances

11. 10 9 8 7 6 5 4 3 10 2 9 1 8 0 7 0 1 2 3 4 5 6 7 8 9 10 6 5 Update the cluster means Assign each objects to most similar center 4 3 2 1 0 0 1 2 3 4 5 6 7 8 9 10 reassign reassign K=2 Arbitrarily choose K object as initial cluster center Update the cluster means Non-hierarchical clustering K-means clustering (Borrowed from Dr. Jiawei Han March 5, 2002)

12. Non-hierarchical clustering K-means clustering Difficulty How to determine whether there are really only k distinct clusters represented in the data or not. Solutions Use K-means clustering with principal component analysis (PCA), which allows visual estimation of the number of clusters represented in the data. Try sequential k-means approach which finds number of clusters based on dataset.

13. Non-hierarchical clustering Self-organizing map clustering Top-down (divisive) approach One-way clustering Neural-network-based clustering approach Non-deterministic owing to the random order in which genes are used to move the reference vectors. Similar to k-means clustering except that the cluster centers are restricted to lie in a one or two-dimensional manifold Model the complexity within a dataset more effectively than k-means clustering.

14. Non-hierarchical clustering Self-organizing map clustering Protocol • Define a geometric configuration for the partitions, e.g. a 2D rectangular or hexagonal grid • Construct and assign random vectors to each partition • Pick a gene randomly; identify the reference vector that is closest to the gene • Adjust the reference vectors so that they are more similar to the gene vector • Repeat steps 3-4 until the reference vectors converge • Map genes to the relevant partitions based on the reference vectors to which they are most similar (Borrowed from Joshua Unger Feb. 28, 2002)

15. Non-hierarchical clustering One-way clustering – used to group genes with similar behavior across samples or samples with similar gene expression vectors Hierarchical clustering K-means clustering Self-organizing maps Two-way clustering – simultaneously cluster both genes and samples Block clustering Gene shaving Plaid models …

16. 1 4 5 3 2 Gene 3 1 2 Sample Non-hierarchical clustering Blocking clustering Top-down approach Two-way clustering Produce a matrix with homogeneous blocks of the outcomes Produce hierarchical clustering trees for the rows and columns Protocol • Begin with the entire matrix in one block • Sort rows and columns by row and column means • Find the row or column splits of all existing blocks, choosing the one that produces largest reduction in the total within-block-variance • If there are existing row/column splits that intersect the block, one of them must be used. Otherwise all split points are tried. • The splitting is continued until a large number of blocks are obtained • Apply weakest link pruning to recombine some of the blocks until the optimal number of blocks is obtained. • The optimal number of blocks is estimated by “maximum gap” approach

17. Non-hierarchical clustering Blocking clustering Difficulty When applied to median centered data, at the start, all rows and column means are approximately zero – the procedure has difficulty getting started.

18. Non-hierarchical clustering The two-way clustering approach seek a single re-ordering of the samples for all genes. However, one set of genes might cluster the samples in one way while another set of genes in a very different way. Gene Shaving approach finds the linear combination of genes having maximal variation among samples. This linear combination of genes is viewed as a “super gene”. The genes having lowest correlation with the “super gene” is removed (shaved). The process is continued until the subset of genes contains only one gene. This process produces a sequence of gene blocks, each containing genes that are similar to one another and displaying large variance across samples. A statistical approach Two-way clustering Identifies subsets of genes with coherent expression patterns and large variation across conditions Gene may belong to more than one cluster Can be either un-supervised or supervised

19. Gene shaving Protocol • Start with all data in one block. • Find the first principal component of the genes • For each gene i, compute the absolute value of its correlation with the first principal component • Remove the fraction a of genes having the smallest absolute correlation • Repeat steps 3~4 until only one gene remains • This procedure produces a set of nested gene groups G1G2 … G* … Gn, from which G* is selected as the optimal gene block (small ), where the optimal shave size is estimated using “maximum gap” method. • The rows of the gene expression matrix are orthogonalised with respect to the average of all genes in cluster G* to obtain a new gene expression matrix to encourage discovery of a different second cluster. Repeat steps 2-7 until no interesting gene shaves can be found.

21. Non-hierarchical clustering A cellular process may involve a relatively small subset of genes in the dataset. The process may take place only in a small number of samples. Therefore, when the full dataset is analyzed, the signal of this process may be completely overwhelmed by the noise of vast majority of unrelated data. Plaid models search for interpretable biological structures in microarray data, i.e. subsets of the genes/samples, one of which can be used to cluster the other to yield stable and significant partitions/layers. Two-way clustering Allows a gene to be in more than one cluster or in none at all Allows a cluster of genes to be defined with respect to only a subset of samples, not necessarily all of them

22. Non-hierarchical clustering Plaid models: Ideal reordering: Every gene and every sample are in exactly one cluster

23. Non-hierarchical clustering Plaid models:

24. Evaluate clustering Clarity of cluster definitions Computational cost Robustness Reproducibility Cancer research Cancer typing Correlating whole-genome expression pattern with particular clinical implication Diagnose malignant tissue from normal one Drug effect study • Pathway discovery • Assign functions of unknown genes • Gene network & regulation: • metabolism, photosynthesis, cell cycle, …

25. Challenges beyond clustering Understand sources of noise and variations in microarray experiments Combine expression data with other sources of information Published literature DNA & protein sequence databases Protein data bank Phylogenetic profiles Metabolic function Annotated experimental functional studies

26. Clustering Assumption: guilt-by-association Genes that are contained in a particular pathway, or that respond to a common environmental challenge, should be co-regulated and consequently, should show similar patterns of expression. This is a controversial hypothesis because the existence of Convergent regulation (similar temporal expression patterns, different control strategies) & Divergent regulation (similar control regions, different ways to take effects)

27. Challenges beyond clustering Understand sources of noise and variations in microarray experiments Combine expression data with other sources of information Published literature DNA & protein sequence databases Protein data bank Phylogenetic profiles Metabolic function Annotated experimental functional studies Reconstruct networks of genetic interactions to create integrated and systematic models of biological systems Boolean networks Linear modeling Generic programming Bayesian belief networks

28. References • Quackenbush (2001) Nature Reviews Genetics. 2:418-427 • Altman & Raychaudhuri (2001) Curr. Opin. Struct. Biol. 11:340-347 • Lazzeroni & Owen (2000) Tech. Report. Stanford Univ. • Aas (2001) SAMBA • Tibshirani et al. (1999) Tech. Report. Stanford Univ. • Hastie et al. (2000) Genome Biol. 1(2)
