  1. Manycast: Exploring the Space Between Anycast andMulticast in Ad Hoc Networks Casey Carter Seung Yi Prashant Ratanchandani Robin Kravets Department of Computer Science University of Illinois, Urbana-Champaign ACM-Mobihoc-2003

  2. Outline • Introuduction • Applications • Defining a manycast service • Service quality • Manycast routing • Experiment

  3. Introuduction • Ad hoc need server replication • Anycast delivers each transmission to a closest single member. • Anycast and multicast are special cases of manycast communication. • Manycast routing in application layer or network layer.

  4. Applications • NTP (Network Time Protocol): a client wish to locate the three best/nearest servers with which to synchronize its clock. • ITTC (Intrusion Tolerance via Threshold Cryptography): each server knows only a small part of the secret key. • Sensor Network • Averaging over the 50 closest temperature sensors.

  5. Defining a manycast service • Manycast like multicast and anycast. • Long-term communication can use manycast to discover k servers. • It be contacted using unicast communication. • Join a source-specific multicast group.

  6. Service quality • 1-to-k communication is k times more likely to fail than is 1-to-1. • If client wants to contact with k servers, it need send out K requests. • K > k

  7. Manycast routing • Vocabulary • There two phase: • discovery phase: The source has no knowledge about the network and the targets of a transmission. • delivery phase : The source has previously discovered something about the topology of network. • m: servers ;n: nodes; k: targets

  8. Manycast routing

  9. Manycast routing DSR: Discovery phase: 1 request + 27 relay + 1 response + 2 forward = 31 transmission Delivery phase: 1 request + 2 relay + 1 response + 2 forward = 6 transmission N=28 M=11

  10. Manycast routing • Application layer (11 +1) requests + 27*(11+1) relay + 2*11 responses + 26 forwards = 384 total transmissions N=28 M=11

  11. Manycast routing • Idealized 1 requests + 1 relay + 3 response+ 1 forwards = 6 total transmissions k=3

  12. Manycast routing • Flood 1 requests + 27 relay + 11 response+ 13 forwards = 52 total transmissions k=3

  13. Manycast routing • Scoped-Flood 1 requests + 5 relay + 7 response+ 5 forwards = 18 total transmissions k=3

  14. Manycast routing • Unicast 3 requests + 1 relay + 3 response+ 1 forwards = 8 total transmissions K=3

  15. Manycast routing • SGM & SGMB SGM: 2 requests +1 relay + 3 response+1 forwards = 7 total transmissions SGMB: 1 requests +1 relay + 3 response+1 forwards = 6 total transmissions (= Idealized) K=3

  16. Manycast routing • Multicast Based • Multicast 1 requests + 7 relay + 11 response+ 13 forwards = 32 total transmissions

  17. Manycast routing • Multicast Based • Scoped-Multicast 1 requests + 4 relay + 7 response + 5 forwards = 17 total transmissions

  18. Experiment • AODV:Flood, Scoped-Flood,Unicast, SGM and SGMB • ADMR for multicast • For the TTL-scoped delivery mechanisms, add a method to AODV’s route table for determining the smallest TTL that will reach K server.

  19. Experiment • Simulation Study • N=150nodes ; m=30servers • 1000*1000meter square • IEEE 802.11 • 2Mbps data rate • Speed 0-10 m/s ; pause time of 10 sec. • During 600 sec. • Each client send out 10 request.

  20. Experiment • Simple Traffic

  21. Experiment • Complex traffic

  22. Experiment • Reliability by K

  23. Experiment • Varying m

  24. Conclusions • Manycast is viable and necessarily must be implemented at the network layer. • Simple approaches are best • Scoped-Flood “heals” routes within scope.

  25. END
