  1. Track systems technology Introduction

  2. Introduction Pandrol Australia is a member of the Pandrol Group, a leading supplier of track systems technology to the rail industry. As part of a total track systems methodology, Pandrol Australia is proud to represent a range of products to help capitalise on the efficiencies available for constructing, maintaining and running railways now and into the future.

  3. Partners • Vortok International • Clever solutions for signalling, maintenance and de-stressing • Rosenqvist • Track machinery for construction and maintenance • On Track Technology • In-Motion weighing solutions • IEM Corp • Automated train inspection systems

  4. Track systems technology Vortok International

  5. Vortok International • Products • Balise Mounts • Safety Barrier • Stressing Rollers • VERSE - Rail stress measurement • SFTPro

  6. Vortok International • Balise Mounts • Drill-free, dig-free mounting to a variety of fastening types • Insulated

  7. Vortok International • Safety Barrier • Rail mounted • Self adjusts to different rail sizes • Double Insulated • Modular

  8. Vortok International • Stressing Rollers • 3 operations in 1 • Rail jack • Side Roller • Under Roller • One-man operation

  9. Vortok International • VERSE – VErticalRail Stiffness Equipment • Non-destructive measurement of Rail Stress-Free temperature • High accuracy • Typically ± 0.2°C

  10. Vortok International An innovative solution for the measurement of rail stress free temperature. Gives stress free temperature readings in situations where conventional methods can not. • S&C • Turnouts

  11. Vortok International • Typical Installation

  12. Track systems technology Rosenqvist

  13. Rosenqvist • Products • Clipping Machines • Sleeper laying • Rail handling • Trailers • Hy-Rail attachments

  14. Rosenqvist • Products • Clipping Machines

  15. Rosenqvist • Products • Sleeper Laying

  16. Rosenqvist • Products • Rail Handling

  17. Rosenqvist • Products • Trailers and Hy-rail attachments

  18. Track systems technology On Track Technology

  19. In-Motion Weighing • The advantages of choosing On Track Technology: • Non-destructive • Sleeper or Rail replacement is NOT REQUIRED! • NO disruption to track foundations • In-Motion • Saves time, and money • Weigh vehicles without disturbing the flow of traffic • Modular, Scalable system • Adapts to expanding requirements • Wheel impact monitoring • Available on larger systems

  20. In-Motion Weighing • Parameters that can be measured: • Vehicle Mass • Vehicle Speed • Overloading • Unbalanced loads • Wheel impact (on larger systems)

  21. In-Motion Weighing • Vertical Load Receptor (VLR) • 4 sensors in each • Individually replaceable • Bonded to the rail • NO Drilling required • Retro-fit • NO Sleeper substitution • NO disturbance to track structure • NO replacement of rail

  22. In-Motion Weighing T4 • 4VLR • 3 sleeper length The small footprint and relatively high accuracy of the Dynamass-T4 system makes it ideal for situations where accurate weighing is required at relatively slow speeds. The Dynamass-T4 system is the ideal solution for infrastructure protection, and the flexible communication options and low power consumption of the microprocessor means that it is ideal for remote locations, and can be solar powered if required.

  23. In-Motion Weighing 08 • 8 VLR • 11 sleeper length Providing high accuracy at medium line speeds, the Massize-08 system is ideal for situations where you wish to obtain accurate information on train weights that you can use for record keeping or customer billing. Trade metrology approved, the system requires a PC-based processing system, which must be installed in a track-side building. Quite often the weighbridge can be incorporated into an existing enclosure where other trackside monitoring equipment is located.

  24. In-Motion Weighing • System Outputs: • Date and time • Vehicle speed and mass • Train mass • AVI information • Automatic net mass calculation • Automatic locomotive recognition (does not require AVI) • Direction of travel • Side-to-side loading balance • Front-rear loading balance • Overload/incorrect loading alarms

  25. Track systems technology International Electronic Machines Corporation

  26. Automated Train Inspection Systems • from International Electronic Machines Corp. • Technology for: • Wheel Profile & Diameter Measurement • Brake Pad Measurement • High, Wide, and Shifted Load Detection • Flat Wheel Detection System • by tread-plate or strain-gauge detection • In-Line Tread Crack Detection System • by EMAT Technology • Hot Box Detection • by Acoustic Bearing or Infra-Red Inspection

  27. Automated Train Inspection Systems • from International Electronic Machines Corp. • something

  28. Wheel measurement capabilities • something

  29. Infra-red Inspection Systems

  30. Automated Train Inspection Systems • from International Electronic Machines Corp. • Installation References: • Wheel Truing Building, Selkirk, NY • AMTRAK, Rensselaer, NY (1997-2002) • AE Pearlman Yard, Selkirk, NY • Rice Yard, Waycross, GA • Queensgate Yard, Cincinnati, OH • Sydney, Australia (RailCorp)

  31. Thank you • Please contact us if you have any further questions • Mark Pittendrigh • Sales Manager – Pandrol Australia • salesaus@pandrol.com.au • http://www.pandrol.com.au
