  1. Programming in Processing Taught by Ms. Madsen Assistants: Ms. Fischer and Ms. Yen Winsor School, 2/13/08

  2. Who are we? • We’re MIT students. Ms. Fischer Ms. Yen Ms. Madsen

  3. Quick review of last week’s material:Remember that green numbers, blue  names. void setup() { color colorName; colorName = color(redValue, greenValue, blueValue); background(colorName); size(width, height); } void draw() { rect(xStart, yStart, width, height); ellipse(xStart, yStart, width, height); }

  4. Review of rect() #2: yStart #1: xStart #4: height #3: width rect(xStart, yStart, width, height);

  5. Review of ellipse() #2: yStart #4: height #1: xStart #3: width ellipse(xStart, yStart, width, height);

  6. Rules for naming things (for example, colors): • The name… • Must start with a LETTER (not a number or symbol.) • Must not have any spaces. • Can’t be a special word, like ‘color’ or ‘size’ or ‘background’.

  7. We can use fill() to give color to our shape. • First, create a color, like we did for background: color colorName2 = color(redValue2, greenValue2, blueValue2); • Then, call fill() with that color name as an argument: fill(colorName2);

  8. New material: fill! Remember that green numbers, blue  names. void setup() { color colorName; colorName = color(redValue, greenValue, blueValue); background(colorName); size(width, height); } void draw() { color colorName2 = color(redValue2, greenValue2, blueValue2); fill(colorName2); rect(xStart, yStart, width, height); ellipse(xStart, yStart, width, height); }

  9. We use stroke the same way as fill. • You can set the outline color of a shape by using stroke() with a color name. • All of the shapes will use the same stroke color until you change it. • Also, instead of giving a color name, you can just give the three RGB values directly instead. (You don’t have to create a color for each fill/stroke statement.) • So you can do this: stroke(colorName3); • Or this: stroke(redValue3, greenValue3, blueValue3);

  10. New material: stroke! Remember that green numbers, blue  names. void setup() { color colorName; colorName = color(redValue, greenValue, blueValue); background(colorName); size(width, height); } void draw() { color colorName2 = color(redValue2, greenValue2, blueValue2); fill(colorName2); stroke(redValue3, greenValue3, blueValue3); rect(xStart, yStart, width, height); ellipse(xStart, yStart, width, height); }

  11. We can use strokeWeight to change the thickness of our outline. • strokeWeight takes just one argument: a number that can have a decimal point (called a float, which stands for “floating-point decimal.”) • You can call strokeWeight before your shapes to make the outlines thicker or thinner. • The existing strokeWeight for all your outlines is 1, but you can change it by setting a different strokeWeight.

  12. New material: strokeWeight! Remember that green numbers, blue  names. void setup() { color colorName = color(redValue, greenValue, blueValue); background(colorName); size(width, height); } void draw() { color colorName2 = color(redValue2, greenValue2, blueValue2); fill(colorName2); stroke(redValue3, greenValue3, blueValue3); strokeWeight(lineThickness); rect(xStart, yStart, width, height); ellipse(xStart, yStart, width, height); }

  13. What’s the command to make triangles? • triangle(), of course! • triangle() takes six arguments, which are coordinate pairs for the three corners of a triangle. • So the command looks like this: triangle(x1, y1, x2, y2 , x3, y3);

  14. Here’s what that looks like. #4: y2 #2: y1 #6: y3 #1: x1 #3: x2 #5: x3 triangle(x1, y1, x2, y2 , x3, y3);

  15. New material: triangle! Remember that green numbers, blue  names. void setup() { color colorName = color(redValue, greenValue, blueValue); background(colorName); size(width, height); } void draw() { color colorName2 = color(redValue2, greenValue2, blueValue2); fill(colorName2); stroke(redValue3, greenValue3, blueValue3); strokeWeight(lineThickness); rect(xStart, yStart, width, height); ellipse(xStart, yStart, width, height); triangle(x1, y1, x2, y2 , x3, y3); }

  16. You can make custom shapes by using the beginShape command. • The custom shape command starts with beginShape(). • You then give the x, y coordinates of a series of vertices like this: vertex(x, y); vertex(x, y); vertex(x, y); vertex(x, y); • Finally, finish your shape with endShape(). • You can also try using endShape(CLOSE) instead.

  17. New material: beginShape/vertex/endShape! Remember that green numbers, blue  names. void setup() { color colorName = color(redValue, greenValue, blueValue); background(colorName); size(width, height); } void draw() { beginShape(); vertex(x, y); vertex(x, y); vertex(x, y); vertex(x, y); endShape(); // try using endShape(CLOSE) instead. }
