  1. E - 2000™ LED

  2. The new E-2000™ LED is a further development of the E-2000™ connector system, which offers a high quality optical as well as an electrical connection. E-2000™ LEDWith electric contact

  3. E-2000™ LEDConstruction Metal swinging spring for electric contact Plastic protection for metal swinging spring

  4. E-2000™ LEDConstruction Interchangeable color-coded and mechanical-keyed parts as from E-2000™ connector system

  5. E-2000™ LEDContact mechanism

  6. E-2000™ LEDApplication principle Metal latch (fixing clip) Matching adapters body Connector body Crimping sleeve Kevlar Copper wire Metal swinging spring Protection latch (snapped) Frontal plate *) Pretension in order to make sure the contact between connector and PC-Board

  7. Monitoring of a multi channel platform System diagnostic E-2000™ LEDApplication
