  1. Cabling

  2. UTP Cabling • 10Base-T (Cat3) 100m – 802.3 • 100Base-TX(Cat5) 100m – 802.3u • 1000Base-T(Cat5e, Cat6a) 100m - 802.3ab • 10GBase-T (Cat6a) 100m • 1000Base-SX (Fiber) 550m - 802.3z • 1000Base-LX (Fiber) 5km – 802.3z

  3. Cable Pinouts • This is the T568-A Standard (Less Used)

  4. Cable Pinouts • This is the T568-B Standard (Most Common)

  5. Fiber Optics • GBIC • SFP • Multi mode – 62.5/125(older) 50/125 • Single mode 8-9/125

  6. GBIC

  7. SFP

  8. Multi Mode

  9. Single Mode
