  1. Sharing Geographic Content John Thieling

  2. Agenda • ArcGIS Online • ArcGIS for Server • Portal for ArcGIS

  3. ArcGIS: A platform for collaboration • Mapping • Analysis • Visualization Citizens Managers DeployedUsers KnowledgeWorkers EnterpriseIntegration Cloud Professional GIS . . . A Framework for Sharing, and Collaborating

  4. Esri- or self-hosted content Esri-hosted Self-hosted Portal for ArcGIS ArcGIS Online • Maps, apps, data, tools • Maps, apps, data, tools ArcGIS Online is secure ArcGIS for Server • All types of services (data) Could exist in the cloud(e.g., Amazon EC2)

  5. Five groups Maps Data layers Data files Tools Applications What types of content can be shared?

  6. With whom do you want to share? • No one(keep private) • Specific group(s) • Your organization • Everyone

  7. ArcGIS services ArcGIS Online ArcMap data layers Web maps Hosted services Services (on-premises) ArcGIS for Server

  8. Web maps Operational layer Basemap layer Web map D

  9. Using ArcGIS for Desktop Preparing operational content TYPE OF CONNECTION TYPE OFDATA ArcGISOnline WHERE TO PUBLISH THE DATA? Operational ArcGISServer Desktop TYPE OF SERVICE? Basemap

  10. Feature service versus map service Streams features Service Streams picture TYPE OFSERVICE Feature Feature service streams vector features to client. Map Map service streams picture to client. D

  11. Two options: Copy data to the server OR Register data source with the server How to handle the data Service Register the data Copy data to server Server location Author location ArcGIS for Server ArcGIS for Server ArcGIS Online D

  12. Registering a service Add service as an item to ArcGIS Online/Portal for ArcGIS Share with others D

  13. Using ArcGIS for Desktop Sharing operational content TYPE OF SERVICE TYPE OF CONNECTION Feature ArcGISOnline TYPE OFDATA Map Operational ArcGISServer Desktop Map Basemap AddFeature Access

  14. Using services (Services) ArcGIS Online ArcGISServer Web maps Web apps Mobile Desktop

  15. Web maps to web apps Web app* Web map Hosted by ArcGIS Online Hosted by your web server Services *Many prebuilt JavaScript app templates D

  16. Create your own custom web apps without coding ArcGIS viewers ArcGIS Viewer for Flex ArcGIS Viewer for Silverlight JS Web App Builder D

  17. Developer apps Mobile Web Flex Silverlight Java • Web APIs • JavaScript • Flex • Silverlight • Runtime SDKs • iOS • Android • Windows Store • Windows Phone .NET Objective-C HTML5/JS

  18. Basemap services TYPE OFDATA TYPE OF CONNECTION TYPE OFSERVICE Operational ArcGISfor Server Cached map ArcGISfor Desktop Basemap ArcGISOnline Tiled map

  19. Map services in ArcGIS Online ArcGIS Online ArcGIS for Desktop Tiled map service Option #1 Option #2 Tile package (TPK) Tile package D

  20. Should you create your own image service? ArcGIS Online Basemap Cached / tiled map service In-house data Purpose of imagery Image service (dynamic) Image service with caching Analysis, visualization, downloads D

  21. Image services Raster datasets Mosaic datasets Layer files Image service • Imaging • WCS • WMS Caching option Dynamic capabilities ArcGIS for Server D

  22. Using image services Desktop • Fully supports dynamic and cached • Toggle display between both Web maps • Can display time enabled imagery Web APIs • Use either cached or dynamic • If dynamic, a set of analyticaloperations is supported

  23. Why share geoprocessing services? Desktop users only GP Package Entire ArcGIS Online community GP Service D

  24. Steps to create a geoprocessing service Prepare / run model Publish model results Use service

  25. Preparing and running the model Need to set symbology? Need to setinput parameters? Modelprocesses Inputparameters Output parameters

  26. Using geoprocessing services Web app ArcGIS for Desktop D

  27. Geocoding Latitude 50oN 85oW 125oW 5oW 45oW Gray Ave 20oN Longitude Warner St 10oS 508 Gray Ave, Durham, NC 78o53’21.57”W, 35o59’58.56”N D

  28. Portal for ArcGIS • At 10.2 an alternative implementation • Value and functionality of Online • Same collaboration tools and apps that you see in ArcGIS Online (e.g. Esri Maps for Office) • Same ArcGIS applications to fully deliver a WebGIS experience • Full productization with installers, support, and documentation • Works closely with ArcGIS for Server

  29. Portal for ArcGIS • Typical reasons for choosing Portal for ArcGIS • Have no internet/www connection • Have strict SLAs and governance • Are not ready for cloud yet • Typical reason for choosing ArcGIS Online • Lower overall cost (faster start, less admin costs) • Continuous updates and improvements • Elasticity

  30. Portal for ArcGIS deployment Client applications and browsers Private Network Web Server Portal Web Adaptor Server Web Adaptor Portal for ArcGIS ArcGIS for Server

  31. Architectural challenges • Requires an fully qualified domain names • Need to install a Windows AD domain controller • DNS needs to be configured in AD • When working with Server acts as a proxy • Requires SSL • Self-sign certificates will fail in the proxy process • Should also use AD certificate management

  32. License basics Server extension Included with Advanced license Provides unlimited anonymous access Named user licenses Available for purchase in blocks of users Full web GIS capability for each use Desktop licenses with current maintenance One named user per license Available for either ArcGIS Online or Portal Licensing Portal for ArcGIS Advanced ? Esri License Portal for ArcGIS

  33. Questions

  34. Sharing Geographic Content Thank you… Please fill out the session survey: Offering ID: 1048 Online – www.esri.com/ucsessionsurveys Paper – pick up and put in drop box
