  1. MICROSCOPY Tutorial 1

  2. Types of Microscopy • Light • Fluorescence • Confocal • Electron • Transmission Electron Microscopy (TEM) • Scanning Electron Microscopy (SEM)

  3. LIGHT MICROSCOPY • Advantages • Live cells can be viewed, color can be seen • Disadvantages • Limit of resolution is 0.2 microns • Organelles viewable • Nucleus, sometimes mitochondria and the Golgi apparatus

  4. Light Microscopy cont. • Example: Onion epidermal cells. You can see the nucleus.

  5. Fluorescence Microscopy • Fluorescent dyes (ie fluorochromes) (used for staining cells) are detected with the aid of a fluorescence microscope • Dyed objects show up in bright color on a dark background • Advantage – Can see live cells • Can highlight particular structures or molecules

  6. Fluorescence Microscopy cont. • Example: DAPI stained to show DNA during cell division. • Top: (Interphase) Only the nucleus is visible • Bottom: (Mitosis) chromosomes lined up at centre of cell.

  7. Transmission Electron Microscopy • Advantages • Good resolution (200 nm to 0.2 nm; size from organelles to macromolecules • Disadvantages • Samples subject to electron bombardment and vacuum • Lots of sample preparation is required (fixation, resin embedding, sectioning into slices 50-100 nm thick, heavy metal stain) • Hard to construct 3-D structure from 2-D slices • TEM cannot be used with living material

  8. TEM cont. Example • Liver hepatocytes of a rat showing rough endoplasmic reticulum (RER) and mitochondria

  9. Scanning Electron Microscopy • Advantages • Show surface structures • 3-D images • Great depth of field • Disadvantages • Electrons require a vacuum so most samples have to be fixed and dried • Only topography (surface structure) can be seen

  10. SEM cont • A male wolf spider • These teeth contain openings that release poison. They not only grasp the prey but immobilize it and inject it with poison.

  11. Image Collection • The following slides contain images from the image database https://www.biomedia.cellbiology.ubc.ca/cellbiol/ Can you tell what technique was used for each of the following images?
