  1. SPARQL Query Rewriting for Implementing Data Integration over Linked Data Gianluca Correndo, Manuel Salvadores, Ian Millard, Hugh Glaser, Nigel Shadbolt

  2. Linked Data access • Retrieving RDF content via HTTP requests • Instance based vs. schema based access • Accessing SPARQL endpoints • Schema based vs. instance based access SPARQL+HTTP

  3. Linked Data – Schema based integration (SPARQL) Query Ontology Co-reference Data set source target OA = <SO,TO,TD,EA> SO: Source Ontologies TO: Target Ontologies TD: Target Dataset EA: Entity Alignments • Datasets can use more than one ontology for describing the data • More than one dataset can use the same set of ontologies coherently (e.g. RKB) • More than one ontology is used for defining a SPARQL query • Ontologies contain many entities to be aligned

  4. Query Rewriting Architecture <source> SPARQL query SPARQL query rewriter <target> SPARQL query <KISTI> SPARQL query <dbpedia> SPARQL query Alignments voiD

  5. Ontology Alignment • DL primitives are used to describe concept alignments (i.e. Equivalent, Subsume) • Implementation of the underneath ontological mediation usually not provided or relies on reasoners • Ontological mediation usually applied to data, not queries • rule systems that exploit alignments to translate data • [Euzenat] SPARQL for integrating dataCONSTRUCT { ?x rdf:type vc:VCard } WHERE { ?x rdf:type foaf:Person }How to write such queries?

  6. Anatomy of a SPARQL query • Query type: SELECT, DESCRIBE, CONSTRUCT, ASK • Basic Graph Pattern (or BGP): graph pattern that resulting triples must satisfy • Filter section: additional constraints over variables present in the BGPPREFIX id:<http://southampton.rkbexplorer.com/id/>PREFIX akt:<http://www.aktors.org/ontology/portal#>SELECT DISTINCT ?a WHERE { ?paper akt:has-author id:person-02686 . ?paper akt:has-author ?a .}

  7. SPARQL BGP ?paper PREFIX id:<http://southampton.rkbexplorer.com/id/>PREFIX akt:<http://www.aktors.org/ontology/portal#>SELECT DISTINCT ?a WHERE { ?paper akt:has-author id:person-02686 , ?a .} • “DISTINCT ?a” is not represented in this graph • Constraints over nodes can be represented either as a graph and within FILTER section akt:has-author akt:has-author ?a id:person-02686

  8. Entity Alignment as Graph Rewriting • Query rewriting based on BGP graph rewriting • Entity Alignment EA = <LHS, RHS, FD> • LHS : Triple to match (open variables to bind) • RHS : Set of triples to instantiate (depending on previous bindings on open variables) • FD : Functional dependencies (between variables)

  9. Entity Alignment as Graph Rewriting • Using the graph rewriting formalism we can rewrite queries defined for a dataset (or ontology) to integrate results from other data sets • But not only, we can also generate CONSTRUCT queries to integrate entire data sets

  10. SPARQL Rewriting • Each triple from the BGP is matched to the LHSs (generating variable bindings in the process) • Eventual functional dependencies are solved (enriching the bindings with new associations) • The respective RHS is instantiated with the given bindings and replace the original triple • Unbounded variables generates new variables

  11. SPARQL Rewriting • Example: • LHS1 = <_:1,rdf:type, source:A> • RHS1 = {<_:1,rdf:type,target:B>} • FD1 = {} • <?p,rdf:type,source:A> = LHS1[_:1/?p] • RHS1[_:1/?p]=<?p,rdf:type,target:B> • _:1 it’s the RDF way to define blank nodes, that are treated, within a graph, as existentially quantified variables.Triple(v1,rdf:type,source:A)Triple(v1,rdf:type,target:B)

  12. Ontology Alignments – Class Eq. • SELECT *WHERE { ?s a source:User.…}<_:1,rdf:type,source:User> • SELECT *WHERE { ?s a target:Agent.…}<_:1,rdf:type,target:Agent> source:User target:Agent rdf:type rdf:type _:1 _:1

  13. Ontology Alignments – Class Partition • SELECT *WHERE { ?s a source:WhiteWine.…}<_:1,rdf:type,source:WhiteWine> • SELECT *WHERE { ?s a target:Vin; target:has-color ”blanc”@fr…}<_:1,rdf:type,target:Vin><_:1,target:has-color, ”blanc”@fr> source:WhiteWine target:Vin rdf:type rdf:type _:1 target:has-color _:1 “blanc”@fr

  14. Ontology Alignments – Property Eq. • SELECT *WHERE { ?s source:has-name ?n.…}<_:1,source:has-name,_:2> • SELECT *WHERE { ?s target:fullName ?n.…}<_:1,target:fullName,_:2> _:2 _:2 source:has-name target:fullName _:1 _:1

  15. Ontology Alignments – Property Eq. • SELECT *WHERE { ?p akt:has-author ?a.…}<_:1,akt:has-author,_:2> • SELECT *WHERE { ?s kisti:CreatorInfo ?i. ?i kisti:hasCreator ?a…}<_:1,kisti:CreatorInfo,:_3><_:3,kisti:hasCreator,_:2> _:2 _:3 akt:has-author kisti:CreatorInfo kisti:hasCreator _:1 _:1 _:2

  16. Ontology Alignments – Property Eq. • SELECT *WHERE { ?p source:temp ”10”^^C.…}<_:1,source:temp,_:2> • SELECT *WHERE { ?p target:farenheit ”50”^^F…}<_:1,target:farenheit,_:2> celsius2farenheit _:2 _:3 _:2 source:temp target:farenheit _:1 _:1 binding directly Celsius values to Fahrenheit is wrong, the two values are linked by a functional dependency.

  17. SPARQL Rewriting • PREFIX id:<http://southampton.rkbexplorer.com/id/>PREFIX akt:<http://www.aktors.org/ontology/portal#>SELECT DISTINCT ?a WHERE { ?paper akt:has-author id:person-02686 . ?paper akt:has-author ?a .} ?paper akt:has-author akt:has-author ?a id:person-02686 _:2 _:3 akt:has-author kisti:CreatorInfo kisti:hasCreator _:1 _:1 _:2

  18. SPARQL Rewriting ?paper kisti:CreatorInfo akt:has-author ?paper ?new1 id:person-02686 akt:has-author akt:has-author kisti:hasCreator ?a ?a id:person-02686 Problem in KISTI dataset <http://southampton.rkbexplorer.com/id/person-02686> is unknown. ?paper kisti:CreatorInfo kisti:CreatorInfo ?new2 ?new1 kisti:hasCreator kisti:hasCreator ?a id:person-02686

  19. Co-reference integration • Constants in the query (like URIs) must be translated in order to retrieve correct results • URI equivalences are maintained by co-reference services like http://sameas.orgaccessible via REST interface. • Modeled as functional dependency within variables • Function returns the equivalent URI that satisfy a regex pattern • Datasets maintain URIs that are recognizable by a common schema (prefix for sure, e.g. http://dbpedia.org/resource/*)

  20. Co-reference integration http://kisti.rkbexplorer.com/id/\S* sameas _:11 _:12 kisti:CreatorInfo akt:has-author _:3 kisti:hasCreator sameas _:21 _:22 id:person-02686 kisti:PER_000000000105047

  21. Implementation • Java package based on Jena API for SPARQL Query rewriting • Code not released yet (planning to integrate it with INRIA ontology alignment API)

  22. Progress report • Contact with Francois Schraffe and Jerome Euzenat • Partial mapping to EDOAL ontology alignment specification (work in progress) • SPARQL query rewriter to be implemented in the Alignment API (partially done)

  23. EDOAL - Expressive and Declarative Ontology Alignment Language • Construction of entities from other entities can be expressed through algebraic operators • Restrictions can be expressed on entities in order to narrow their scope. • Transformations of property values can be specified. Property values using different encoding or units can be aligned using transformations.

  24. EDOAL - Example <http://oms.omwg.org/wine-vin/MappingRule_3> :entity1 wine:Bordeaux ; :entity2 [ edoal:and (vin:Vin [ a edoal:AttributeValueRestriction edoal:comparatorxsd:equals ; edoal:onAttribute [ edoal:compose (vin:hasTerroir proton:locatedIn ) ; a edoal:Relation ] ; edoal:valuevin:Aquitaine] ) ; a edoal:Class ] ; :measure "1."^^xsd:float ; :relation "SubsumedBy" ; a :Cell .

  25. Internal Representation vin:Vin rdf:type wine:Bordeaux vin:hasTerroir rdf:type _:6 _:9 proton:locatedIn _:6 vin:Aquitaine

  26. Progress report • Graph pattern rewriting can be used also for creating CONSTRUCT queries for translate RDF graphs with different ontologies. CONSTRUCT { ?9 <http://proton.semanticweb.org/locatedIn> <http://ontology.deri.org/vin#Aquitaine> . ?6 <http://ontology.deri.org/vin#hasTerroir> ?9 . ?6 <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <http://ontology.deri.org/vin#Vin> .} WHERE { ?6 <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <http://www.w3.org/TR/2003/CR-owl-guide-20030818/wine#Bordeaux> .}

  27. Thanks Questions?

  28. Outline • Linked Data • Data topology • Data access • Query Rewriting • Ontology Alignment • Entity Alignment • SPARQL rewriting

  29. Linked Data topology • Foreign URIs for referring to external entities • Co-references for referring to instance “equivalence”
