  1. <Insert Picture Here> Networking Infrastructure Choices for Storage Product Manager

  2. Networking Infrastructures File File Block Block File LANIP/Ethernet 8Gb FC SAN Block LAN SAN Block Block File Block File Data Network Storage Network

  3. Block Data or File: What Protocols are Used • File Data • Networked Attached Storage uses LAN or WAN protocols i.e. TCP/IP over 10GbE or 1GbE • A NAS device can exist anywhere in a LAN or WAN. • Supported Protocols include CIFS, NFS and HTTP • Block Data • Storage Area Networks use multiple block protocols • FC • iSCSI (TCP/IP) • IB • FCoE • SAS

  4. The Market Selects FC While there is a use for every interface, FC (choice C) is the leader for enterprise demanding applications FC SANs account for 55% of the overall storage system interface market. “We continue to see strength in the FC market," said Casey Quillin, Analyst at Dell'Oro Group. IDC’s Q2 2010 Worldwide Storage Systems Hardware Tracker

  5. Reasons for FC Leadership • Mature and time-proven designs dominates SANs today in the enterprise market • FC Overview • High performance, robustness and addressability for demanding environments • Low latency, high IOPs, and congestion free • High addressability necessary for large customers • Investment protection with auto-negotiating link speeds • FC SANs ensure higher security • Data integrity in the near future with T10-Dif • Consolidate heavy server I/O demands For FC host connectivity, Oracle FC Networking Powered by QLogic the leading choice…

  6. Full Testing and Integration with SPARC Enterprise, Blade, and x86 Servers QLogic HBA technology is also embedded in ZFS & Axiom M9000 M5000 SPARC T4 Series M3000 SPARC T3 Series M4000 T5440 T5240 M8000 Blade Clusters (x86/SPARC) T5120 Rack-Mount Servers and Open Storage Open Applications-to-Disk Solutions from a Single Source

  7. Why QLogic: The Ultimate in Performance • Oracle 8Gb FC adapters powered by QLogic lead in real-world performance for Oracle database Benchmark running on Oracle Relational Database Management System (RDBMS)* • Across all three workloads (OLTP, Web and OLAP), QLogic’s performance averaged 98 percent better than the competition. • Ensures reduced response time of mission critical applications and backup time-windows *Running on Microsoft® Windows® 2003 Enterprise Edition with Service Pack 2. The tool used for predicting the performance of the Oracle database under-load was Orion from Oracle

  8. Full Hardware Offload for Improved System Performance • The lowest CPU utilization in the industry • Requires an average of 9% CPU utilization • Competitors Choke CPU utilization up to 90% • The ability to fully offload processing to the adapter improves server performance by freeing up the server CPU to other tasks • More bandwidth for multiple VMs and apps all on a single server

  9. The Ultimate in Low Power Usage • QLogic’s power management technologies • StarPower™ consumes only the power needed to run at full speed • Cool HBA™ technology: HBAs can operate without airflow Power Consumption 8 Gb Dual Port HBAs QLogic 8Gb FC HBAs consume 20-30% less power for greener IT! Watts QLogic ensures a lower power and cooling infrastructure

  10. FC Adapter of Choice for Oracle Database • For Optimized Database Solutions tested configurations, the Oracle 8Gb FC adapters powered by QLogic were the adapter of choice for Oracle Database BOMs Optimized Solutions for Database BOM Servers Processors Storage Storage Networking Warranty

  11. FC Adapter of Choice for Oracle Database • For Optimized Database Solutions tested configurations, the Oracle 8Gb FC adapters powered by QLogic were the adapter of choice for Oracle Database BOMs

  12. The Ultimate in Business Resiliency • QLogic’s Overlapping Protection Domains (OPDs) • Provides overlapping parity and cyclic redundancy checking and generation for continuous data protection Data moving from Host Bus to FC OPD OPD FC CRC Byte Parity PCI Parity / ECC Host Bus Interface Module FC Interface Module Frame Buffer Fibre Channel PCI Bus OPD OPD FC CRC Byte Parity PCI Parity / ECC CRC = Cyclic Redundancy Check ECC = Error Correction Code Data moving from FC to Host Bus

  13. Tightly Integrated with Oracle Operating Environments • 17 + years of field-hardened Solaris solutions • Pioneered Oracle Solaris FC I/O technology ensures solutions deliver a stable, reliable and highly available solution • Key foundational component of the Oracle Linux stack • A component of Oracle Linux pre-tested and certified architectures integral to Linux enterprise solutions • Flexible and adaptable to Oracle VM • Hardware-assisted VMflex supports multiple virtual connections sharing the same physical port

  14. Adapter of Choice for Oracle Customers • In the past year alone, Oracle has shipped 72,861 Oracle-branded QLogic adapters • Selected by top Fortune 500 customers

  15. Recap: Engineered to Win Together • Oracle HW, SW, and networking powered by QLogic provide a seamless high performance solution to your customers. • Best-in-class: QLogic has the largest Storage Networking I/O install base = reliability and turn-key deployment • Integral to the Oracle Stack: HBA technology embedded in Oracle storage hardware and fully tested across Oracle servers and apps • Optimized for Oracle Database: A key component in Oracle architected database configurations for optimal DB performance • The Ultimate Choice for FC Connectivity: Oracle-branded QLogic adapters provide performanceand business resiliency needed in today’s environments • We are here to help! • www.qlogic.com/go/oracleor email QLogic.oracle@qlogic.com

  16. Questions? Thank You! Thank You
