  1. MIR2 Audio & Networking

  2. MIR2 System Features • Fully Compatible with Signature Series • Fully Integrated Audio Capabilities • Compatibility with a Wide Range of Annunciation Products • User-friendly Front Panel Controls • Complete Range of System Reports • Simple Upgrade from standalone to networkedsystem Cost Effective = Reliable Protection

  3. Signature Series Support • Fully Signature Series Compatible • Up to 190 Devices per Signature Data Circuit • Completely Compatible with Existing Wiring GSA-PHS GSA-MDM Easy Installation and Reduced Maintenance Costs GSA-278

  4. Signature Series Mapping • Mapping Provided using the System Definition Utility • Provides an accurate picture of circuit wiring • Eliminates problems due to mis-installed devices after cleaning Easy Installation and Reduced Maintenance Costs

  5. User-friendly Front Panel • Large Alphanumeric LCD Display • Diagnostic LEDs and Control Switches • Event Queue Scroll Switches for Reviewing All Active Events • Switches to Access System Service / Maintenance Functions Fully Integrated User Controls = Faster Response to Alarms 2-LCD

  6. Complete System Reports • Detailed Sensitivity Reports on All Devices • Enhanced History Logs • Complete Status Reports on All System Events and Devices Decreased Maintenance Costs = Greater Margins

  7. Fully Integrated Audio • Choose from 3 Different Cabinet Configurations • 2-WB7 Cabinet Enclosure which provides space for both the 2-MIC and the 2-TEL • 2-WB3 Cabinet Enclosure which provides space for either the 2-MIC or the 2-TEL 2-WB7 2-WB3

  8. Fully Integrated Audio • Customizable With Either a Paging Microphone (2-MIC) and / or a Firefighter’s Telephone (2-TEL) 2-12/24SW 2-MIC

  9. Fully Integrated Audio • Customizable With Either a Paging Microphone (2-MIC) and / or a Firefighter’s Telephone (2-TEL) 2-TEL

  10. Fully Integrated Audio • Utilizes Signature Series Technology • 2-AAC Audio Controller Card • SIGA-AA30 and SIGA-AA50 Amplifiers • SIGA-APS Auxiliary Power Supply SIGA-AAC SIGA-AA30 SIGA-APS

  11. Optional Annunciators • LSRA Annunciators • SAN Series Annunciators • CDR-3, IOP-3, RPM • RSAN-PRT, PT-1S • ENVOY Graphic Annunciator 2-LSRA-MIR SAN Annunciator No More Compatibility Issues! ENVOY

  12. Network Annunciators • Full System Control • Space-saving, Attractive Design • Up to Five per Network MIR2-3ANN MIR2-6ANN

  13. Networking Capabilities • Configure the MIR2 with the optional MIR2-MCMN and it becomes a powerful network node • Each node capable of 2 Intelligent Loops with 2 built in NACs each • Connect up to 5 networked control panels and 5 networked annunciators over RS-485 wiring • Maximum of 10 Loop Controllers Per Network MIR2-MCMN

  14. Networking Capabilities Peer-to-Peer Network

  15. MIR2 Stand Alone or Network... The Most Comprehensive Mid Range Solution on the Market!
