Solution: Homework 6

Fuzzy Logic. Fuzzy Control. Solution: Homework 6. v. small. small. perfect. big. v. big. growing. declining. constant. 1. 1. 0. 75. 0.6. 0.4. 0.25. 0 5 10 15 20 25. – 10 – 5 0 5 10. speed change [m/s 2 ]. distance to next car [m].

knoton
Télécharger la présentation

Solution: Homework 6

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Fuzzy Logic Fuzzy Control Solution: Homework 6 v. small small perfect big v. big growing declining constant 1 1 0.75 0.6 0.4 0.25 0 5 10 15 20 25 –10 –5 0 5 10 speed change [m/s2] distance to next car [m] 2.5 m/s2 13 m –big zero +small +big –small 1 –2 –1 0 1 2 acceleration adj. [m/s2]

  2. Fuzzy Logic Fuzzy Control 0 0.4 0 0.6 Solution: Homework 6 (Cont.) 0 0.4 • Rule 1:IF distance is small ANDspeed is declining,THENmaintain acceleration. • Rule 2: IF distance is small ANDspeed is constant,THENacceleration adjustment negative small. • Rule 3: IF distance is perfect ANDspeed is declining, THEN acceleration adjustment positive small. • Rule 4: IF distance is perfect ANDspeed is constant, THEN maintain acceleration. 0.75 0.4 0 0.6 0.75 0.6 FL-Operators: AND  Min OR  Max

  3. Fuzzy Logic Fuzzy Control 0.4 0.6 1 –2 –1 0 1 2 acceleration change [m/s2] Solution: Homework 6 (Cont.) –big zero +small +big A2 –small 1 A1 –2 –1 0 1 2 acceleration adj. [m/s2]

  4. Fuzzy Logic Fuzzy Control Solution: Homework 6 (Cont.) Implementation in Matlab Input 1 MFs Input 2 MFs Output MFs Rule Viewer

  5. Fuzzy Logic Fuzzy Control Fuzzy Logic Toolbox in Matlab • The toolbox can be opened by typing “fuzzy” in Matlab Workspace • Some variables must be defined: • Number of inputs and outputs • Membership functions of each input and output • Fuzzy rules that will connect the membership functions • Fuzzy set operators, inference core, accumulation, and defuzzification

  6. Fuzzy Logic Fuzzy Control Fuzzy Logic Toolbox in Matlab • Now, we utilize the fuzzy toolbox to analyze the input-output behavior of the fuzzy control. • Later, the resulting fuzzy control can be applied to control dynamic systems in Simulink environment. • In each session, remember to save the controller that has been designed: • Save files using Files >> Export >> To Disk • Open files using Files >> Import >> From Disk

  7. Fuzzy Logic Fuzzy Control Homework 7 • Read the manual of Fuzzy Logic Toolbox carefully. • Learn how to use the toolbox and get familiar with it. • Redo the quiz problem in Matlab. Submit the *.fis file of the fuzzy control along with necessary supporting documents. • Submission must be in hardcopy and softcopy. • Incomplete submission will not be graded.
