  1. Weapons Effects

  2. Overview • Epidemiology of Injuries • Mechanism of Injury • Antipersonnel Landmines • Small Arms

  3. Epidemiology of Injuries • Two Major Categories of Weapons • Explosives: artillery, grenades, mortars, bombs, hand grenades • Small Arms Fire: pistols, rifles, machine guns • Most common pattern or injury is multiple small fragment wounds of extremities

  4. Mechanism of Injury: Projectiles • There are two areas of projectile-tissue interaction • Permanent cavity: localized area of tissue injury that is proportional to the size of the projectile • Temporary cavity: Transient displacement of tissue, which occurs after passage of the projectile. • Elastic tissue, such as skeletal muscle, blood vessels and skin, may be pushed aside after passage of the projectile, but then rebound. • Inelastic tissue, such as bone or liver, may fracture in this area.

  5. Mechanism of Injuries: Explosives • Explosives have three mechanisms of injury: • Ballistic • Blast • Thermal

  6. Mechanism of Injury • Ballistic: • Injuries caused by fragments created by explosives • Typically cause multiple wounds • Blast • This occurs more closely to the explosion compared to ballistic injury • The ears are most often affected by the overpressure, followed by lungs and gastrointestinal organs. • The explosion creates a blast wind that can throw victims against solid objects, causing blunt trauma. • Thermal • The result of combustion, may cause burns

  7. Antipersonnel Landmines • Tree types of antipersonnel landmines • Static • Bounding • Horizontal spray

  8. Antipersonnel Landmines • Static: small landmines that detonate when stepped on and result in 2 types of injury • Partial or complete traumatic amputation • More proximally, tissue and other debris is pushed up along fascial planes, stripping tissue from bone

  9. Antipersonnel Landmines • Bounding: a mine that is propelled to 1-2m in height and then explodes, causing multiple small fragment wounds. This type of mine is associated with the highest mortality. • Horizontal spray mines: propel fragments in one direction, causing multiple small fragment wounds

  10. Small Arms • In the past, differentiation made between HI and LOW velocity weapons but now felt not to be totally different entities. • Change to higher velocity weapons a result of change to smaller and lighter automatic weapons • Automatic weapons more effective Most combat actions < 200 meters Most infantry not great marksman • Smaller, lighter ammo developed Less recoil, better aim Each soldier can can carry more rounds

  11. Small Arms (cont) • To maintain wounding power, higher bullet velocities were necessary • Higher velocities developed to increase FIREPOWER, not wounding power (same) • Always potential for higher energy transfer with higher velocity, but this is not always the case • Surgeon should always be concerned with the individual wound, rather than the “worst case scenario”

  12. Fragmentation/ Expansion • Some missiles are designed to fragment or expand Dum-dums, Hollow-points, Non-jacketed, Some fragments despite copper jacket (M-16) • Fragments cause multiple tracts of permanent and temporary cavities • Expansion makes the permanent cavity wider

  13. Yaw • Yaw is the deviation in the longitudinal axis of the bullet from its line of flight (tumbling) • Yaw is usually 180 degrees and can be caused by striking foliage or tissue • It increases the area of permanent and temporary cavitation • Important in the injuries caused by AK-47, AK-74

  14. Shotgun Injuries Shotgun shells have a big powder charge with a large mass of lead balls • Destructive potential depends on range • At close range, it can cause a large wound with severe disruption of anatomy by direct crush alone • Long range (>25m) cause usually only skin wounds • Wadding is a projectile too
