  1. A Summarized Look into… NMR Spectroscopy From… Organic Chemistry Paula Yurkanis Bruice

  2. Nuclear Magnetic Resonance (NMR) Spectroscopy Identify the carbon–hydrogen framework of an organic compound Certain nuclei such as 1H, 13C, 19F, and 31P have allowed spin states of +1/2 and –1/2; this property allows them to be studied by NMR

  3. The spin state of a nucleus is affected by an applied magnetic field

  4. The energy difference between the two spin states depends on the strength of the magnetic field

  5. absorb DE a-spin states b-spin states release DE Signals detected by NMR

  6. An NMR Spectrometer

  7. The electrons surrounding a nucleus affect the effective magnetic field sensed by the nucleus

  8. Chemically equivalent protons: protons in the same chemical environment Each set of chemically equivalent protons in a compound gives rise to a signal in an 1H NMR spectrum of that compound

  9. The Chemical Shift The common scale for chemical shifts = d distance downfield from TMS (Hz) d = operating frequency of the spectrometer (MHz) The reference point of an NMR spectrum is defined by the position of TMS (zero ppm) The chemical shift is a measure of how far the signal is from the reference signal

  10. 1H NMR spectrum of 1-bromo-2,2-dimethylpropane

  11. The chemical shift is independent of the operating frequency of the spectrometer

  12. Electron withdrawal causes NMR signals to appear at higher frequency (at larger d values)

  13. Characteristic Values of Chemical Shifts

  14. 1H NMR spectrum of 1-bromo-2,2-dimethylpropane

  15. Integration Line The area under each signal is proportional to the number of protons that give rise to that signal The height of each integration step is proportional to the area under a specific signal The integration tells us the relative number of protons that give rise to each signal, not absolute number

  16. Diamagnetic Anisotropy The p electrons are less tightly held by the nuclei than are s electrons; they are more free to move in response to a magnetic field Causes unusual chemical shifts for hydrogen bonded to carbons that form p bonds

  17. Splitting of the Signals • An 1H NMR signal is split into N + 1 peaks, where N is the number of equivalent protons bonded to adjacent carbons • Coupled protons split each other’s signal • The number of peaks in a signal is called the multiplicity of the signal • The splitting of signals, caused by spin–spin coupling, occurs when different kinds of protons are close to one another

  18. 1H NMR Spectrum of 1,1-Dichloroethane

  19. The ways in which the magnetic fields of three protons can be aligned

  20. Splitting is observed if the protons are separated by more than three s bonds Long-range coupling occurs when the protons are separated by more than three bonds and one of the bonds is a double or a triple bond

  21. More Examples of 1H NMR Spectra

  22. The three vinylic protons are at relatively high frequency because of diamagnetic anisotropy

  23. The Difference between a Quartet and a Doublet of Doublets

  24. The signals for the Hc, Hd, and He protons overlap

  25. The signals for the Ha, Hb, and Hc protons do not overlap
