Miscellaneous Forces

Miscellaneous Forces. Weight. Weight is the force of gravity upon an object. This force is represented by the symbol F g (units of Newtons) Acceleration of gravity on the earth is always -9.81 m/s/s, so weight can be calculated by multiplying the mass and -9.81 m/s/s. Normal Force.

majed
Télécharger la présentation

Miscellaneous Forces

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Miscellaneous Forces

  2. Weight • Weight is the force of gravity upon an object. This force is represented by the symbol Fg (units of Newtons) • Acceleration of gravity on the earth is always -9.81 m/s/s, so weight can be calculated by multiplying the mass and -9.81 m/s/s

  3. Normal Force • Normal Force is the force of a surface on an object, and acts against the force of gravity (weight). It is always perpendicular to the contact surface. It is represented by Fn

  4. Force of Friction • Friction is a force that opposes applied force • Static friction is the force that is exerted on a motionless object, and is always equal but opposite to an applied force. It is represented by Fs. • There is a limit where the static friction can no longer keep the object motionless. This limit is called the Fs,max

  5. Force of Friction • Kinetic friction is the force that opposes motion of a moving object. It is a fixed amount that depends on the surfaces involved. It is represented by the symbol Fk

  6. Force of Friction • The coefficient of friction describes the relative amount of friction between two surfaces. It is represented by μs or μk • It can be calculated by: μs= Fs,max / Fn • μk = Fk / Fn • See page 102 for a table of values
