  1. PW8 Pick-Up Header Features & Benefits

  2. Overview Heavy Duty Draper Tracking System MacDon's patented V-Guide roller groove tracking system provides reliable, maintenance free draper tracking. Our four draper joining system and large 5 inch (12.7cm) diameter drive roller minimizes the chance of draper slippage even with today’s larger, heavier swaths. Seed Saving Technology Unique draper connectors and increased overlap of front to rear draper decks ensure hours of slip free draper operation and enhanced seed saving technology when harvesting delicate small or large swaths. Serious Capacity A robust and extremely durable endless 80 chain Auger Drive, allows the PW8 to provide significantly more capacity than previous models. • PW8 Features & Benefits

  3. Overview (continued) • PW8 Features & Benefits Simple Adjustments A simple draper tensioning system, easy to see draper tension indicators, and common all metric hardware allow adjustments to to be made in a flash. Drop and Go Float Performance Our simple and effective Spring-Over-Shock floatation system provides a ground following 18 inches (45.7cm) of wheel float, and requires no adjustment during operation or lockout during transport, it is a true plug and play for the combine operator. Float indicator numbers are clearly displayed on both sides of the machine, letting you know the PW8 is operating at an optimum float position.

  4. Overview (continued) • PW8 Features & Benefits Easy Maintenance Five 100 hour lubricating points make for quick easy maintenance of this machine. On the Go Control The PW8 is Header Height Control and Lateral Tilt ready. Adapts to Any Brand of Combine Combine Completion Packages allow quick and easy mounting to most combine makes and models, this flexibility also increases resale value down the road.

  5. Improved Draper Tracking • Patented Design • Both front and rear belts have these unique tracking guides • Simple, maintenance free design • PW8 Features & Benefits

  6. Improved Draper Capacity • Individual bars connect draper belts to enable one continuous belt for improved traction • +50% conveying capacity to handle the largest swaths • Long draper connector bars join draper belts to form a continuous assembly • PW8 Features & Benefits

  7. Belt Drives and Tracking • 2 Hydraulic Motors (5.9 CID) in series to drive front and rear belts, elimination of belt and tensioner • 25% Larger drive rollers for improved traction on drapers • Drive Rollers 5” (125mm) in diameter • PW8 Features & Benefits

  8. Reduction of Seed Loss • More overlap to rear deck, similar geometry to previous grass seed model • Improved sealing at rear roller to header connection • Connected belts forming a “continuous” cover to minimize seed loss. • PW8 Features & Benefits

  9. Flexibility at Dealer Level • Combine completion components which positions combine feeder to optimal combine feed chain/auger relationship • Dealer available combine completion packages which has driveline, multi coupler and faceplate connection. (similar to draper header) • PW8 Features & Benefits

  10. Configuration • 1 Base Model B5458 • Suffixes used for shipping destination and combine completion/customer (Same as draper header) • Through MD designation available for CNH and JD combines only (PW8) • PW8 Features & Benefits

  11. Auger Drive • Auger Drive changed from # 60 to Endless # 80 chain to increase auger drive capacity • Auger drive handles todays largest combines and larger swaths with reserve capacity • PW8 Features & Benefits

  12. Float • New Improved Float System • Has integral dampening (assembly) • Eliminates the requirement for external float lock out • Reduced complexity of assembly • One factory float position, no adjustment necessary • PW8 Features & Benefits

  13. AHHC • Dual Height Control Sensors (LH/RH ends) • Improves auto header height control/sensitivity • Allows the function of lateral tilt (If combine equipped) • Improved ground following and header contouring • PW8 Features & Benefits

  14. Options and Attachments Hold Down Performance Kit • Optional DIA kit B5475 • This attachment is for light swaths to reduce “Swath Roll” in front of rollers • PW8 Features & Benefits

  15. Easy Maintenance Lubricating Points (100 hrs) • A - Auger bearing • B - Drive line slip joint • C - Auger chain • PW8 Features & Benefits

  16. Easy Maintenance (continued) Lubricating Points (100 hrs) • D - Drive line clutch • E - Drive line guard • PW8 Features & Benefits

  17. Video PW8 MacDon Video, click here. PW8 on MacDon website, click here. • PW8 Features & Benefits

  18. Thank You
