  1. Introduction to Endevor

  2. System Subsystem 1 Subsystem 2 Type 1 Type 2 Type 3 Elements Elements Elements Repository Structure

  3. Element Types JCLPROD Production CA-7 JCL (PRDCTRL Approved) PROCPROD Production Cataloged Procedure (PRDCTRL Approved) DOCNPROD Production Documentation (PRDCTRL Approved) DATA Input Control Data COBOL COBOL Program COPYCOB COBOL Copycode REXX REXX Program NAPGM NATURAL Program NAPGMSYS NATURAL Program (SYSTEM) NASUB NATURAL Subprogram NASUBSYS NATURAL Subprogram (SYSTEM) NAMAP NATURAL Map NAMAPSYS NATURAL Map (SYSTEM) etc.

  4. Production JCLLIB Production Natural Lib Delta Library Endevor Base Library source load source source source JCLPROD DOCNPROD NAPGM Source/Load Management

  5. Endevor Main Menu -------------------- ENDEVOR 3.7.1 Primary Options Menu --------- Option ===> 0 DEFAULTS - Specify ENDEVOR ISPF default parameters 1 DISPLAY - Perform Display functions 2 FOREGROUND - Execute Foreground Actions 3 BATCH - Perform Batch Action processing 4 PACKAGE - Perform Foreground Package processing 5 BATCH PACKAGE - Perform Batch Package SCL Generation U USER MENU - Display user option menu T TUTORIAL - Display information about ENDEVOR C CHANGES - Display summary of changes for this release X EXIT - Exit the ENDEVOR/MVS dialog Current environment: ENVPROD

  6. Defaults UPDATE ----------------- ENDEVOR USER DEFAULTS ------------------ COMMAND ===> WORK DATASET ALLOCATION INFORMATION: LIST DATASET ALLOCATION INFO: PRIMARY QUANTITY ===> 1 PRIMARY QUANTITY ===> 1 SECONDARY QUANTITY ===> 1 SECONDARY QUANTITY ===> 1 SPACE UNITS ===> CYL (TRK/CYL/BLK) UNIT NAME ===> SYSSCR VOLUME SERIAL ===> (BLANK FOR DEFAULT) PRINT OPTIONS: FOREGROUND ACTION OPTION: SYSOUT CLASS ===> A DISPLAY MSGS WHEN RC GE ===> 0 LINES PER PAGE ===> 60 JOB STATEMENT INFORMATION: ===> //OSSINGE JOB (DSSM%%%%),'OSSINGER ENDEVOR',MSGLEVEL=(1,1), ===> // CLASS=S,MSGCLASS=T,NOTIFY=OSSINGE ===> //*

  7. Display ------------------------ DISPLAY OPTIONS MENU ------------------ OPTION ===> 1 ELEMENT - Display element/component list information 2 FOOTPRINT - Display footprinted members and listings 3 SITE - Display site information 4 STAGE - Display stage information 5 SYSTEM - Display system definitions 6 SUBSYSTEM - Display subsystem definitions 7 TYPE - Display type definitions 8 PROCESSOR GROUP - Display processor group definitions 9 APPROVER GROUP - Display approver groups A RELATE GROUP - Display system/approver group relationships E ENVIRONMENT - Display information about current environment

  8. Display Element ----------------- Display Elements/Component Lists --------------- OPTION ===> blank - Display selection list B - Browse element current level S - Display summary of levels C - Display changes current level M - Display element master info H - Display history current level FROM ENDEVOR: LIST OPTIONS: ENVIRONMENT ===> ENVPROD DISPLAY LIST ===> Y (Y/N) SYSTEM ===> WHERE CCID EQ ===> SUBSYSTEM ===> WHERE PROC GRP EQ ===> ELEMENT ===> DISPLAY SYS/SBS LIST ===> N TYPE ===> BUILD USING MAP ===> N (Y/N) STAGE ===> 1 - CERT 2 - PROD

  9. Display Options S - Summary of Levels shows an Element’s change history. From this panel you can select a specific level for display using option B, C, or H. M - Element’s Master Control File information. B - Browse Element’s current level, showing level at which each statement was inserted. C - Element Changes panel shows all inserts and deletes to the Element at the current level. H - History panel shows all statements in all levels of an Element, and the level at which each insert/delete occurred.

  10. Display Footprint ----------------------- ENDEVOR - FOOTPRINT DISPLAY ------------- Option ===> blank - Member selection list I - Display load module CSECTS and ENDEVOR footprints L - Display the library member FROM ISPF LIBRARY: PROJECT ===> END.CERT LIBRARY ===> SHARED TYPE ===> LISTLIB MEMBER ===> THRU MEMBER ===> OTHER PARTITIONED DATA SET: DATA SET NAME ===>

  11. Footprint Listing BROWSE OSSINGE.C1#1TMPL.LIST Command ===> ********************************************* ** ******** ADD ******** ** ** USER ID......... OSSINGE ** ** DATE............ 13MAY96 09:15 ** ** ENDEVOR RC...... 0012 ** ** ** ** ENVIRONMENT..... ENVPROD ** ** STAGE........... CERT ** ** SYSTEM.......... TEST ** ** SUBSYSTEM....... TEST ** ** ELEMENT......... END01P ** ** VV.LL........... 01.00 ** ** TYPE............ NAPGM ** ** PROC GROUP...... NATNNL ** ** PROCESSOR....... GNATNNL ** ** INIT.......... RC=0000 ** ** **NATVALID...... RC=0012 > MAXRC ** *********************************************

  12. Footprint Listing BROWSE OSSINGE.C1#1TMPL.LIST Command ===> APPL-ID: USER ID: PASSWORD DATA ENDEVOR,ENDVMNT *CF* %* Logon accepted to library ENDEVOR. NEXT EXECUTE GNEN5100 DATA END01P,NAPGM Page 1 ******************** PROCESSOR ERROR ******************** END01P not registered in Job/Program Name file. ******************** PROCESSOR ERROR ******************** NAT9987 NATURAL SESSION TERMINATED ABNORMALLY - RC=012 ******************************** Bottom of Data ***********

  13. Footprint Listing BROWSE OSSINGE.C1#1TMPL.LIST Command ===> NEXT GNEN5000 GNOS5170,P,S NEXT USR0210P STOW,GNOS5170,Y,P 0110 DEFINE DATA <<<< NAT0273 Error 0974 in line 0130 of data area GNDU006L processing SPOOL-UPDATE. 0320 1 REDEFINE #GNOA-HOLD-KEY ******** NAT0220 Statement not allowed or keyword COMPUTE/ASSIGN required 0370 1 REDEFINE #TEXT-A ******** NAT0220 Statement not allowed or keyword COMPUTE/ASSIGN required 0500 MOVE +GNOA-HOLD-KEY TO #GNOA-HOLD-KEY ************** NAT0384 Explicit format specification required. 0540 #JOB-NAME *********

  14. SYSTEM ACSTOOL INCLUDE ACSTOOL@ Natural Certification Library

  15. Endevor Main Menu -------------------- ENDEVOR 3.7.1 Primary Options Menu --------- Option ===> 0 DEFAULTS - Specify ENDEVOR ISPF default parameters 1 DISPLAY - Perform Display functions 2 FOREGROUND - Execute Foreground Actions 3 BATCH - Perform Batch Action processing 4 PACKAGE - Perform Foreground Package processing 5 BATCH PACKAGE - Perform Batch Package SCL Generation U USER MENU - Display user option menu T TUTORIAL - Display information about ENDEVOR C CHANGES - Display summary of changes for this release X EXIT - Exit the ENDEVOR/MVS dialog Current environment: ENVPROD

  16. Stage 1 Stage 2 MOVE CERT PROD Certification Stage Production Stage ADD/UPDATE RETRIEVE Work PDS Element Lifecycle

  17. Foreground Actions -------------------------- Foreground Options Menu ----------------- Option ===> 1 DISPLAY - Display an element 2 ADD/UPDATE - Add or update an element into stage 1 3 RETRIEVE - Retrieve or copy an element 4 GENERATE - Execute the Generate Processor for this element 5 MOVE - Move an element to the next inventory location 6 DELETE - Delete an element 7 PRINT - Print elements, changes and detail change history 8 SIGNIN - Explicitly sign-in an element

  18. Add/Update ---------------------------- ADD/UPDATE ELEMENTS ---------------- OPTION ===> blank - Member list A - Add an element U - Update an element TO ENDEVOR: ACTION OPTIONS: ENVIRONMENT ===> ENVPROD CCID ===> SYSTEM ===> TAPE GENERATE ELEMENT ===> Y (Y/N) SUBSYSTEM ===> TAPE DELETE INPUT SOURCE ===> N (Y/N) ELEMENT ===> NEW VERSION ===> TYPE ===> JCLPROD OVERRIDE SIGNOUT ===> N (Y/N) STAGE: 1 PROCESSOR GROUP ===> UPDATE IF PRESENT ===> N (Y/N) COMMENT ===> Update REGION parameter FROM ISPF LIBRARY: LIST OPTIONS: PROJECT ===> OSSINGE DISPLAY LIST ===> Y (Y/N) LIBRARY ===> END TYPE ===> JCLPROD MEMBER ===> THRU MEMBER ===>

  19. Add/Update ADD/UPDATE -------------- MEMBER SELECTION LIST ---------- Row 1 to 1 COMMAND ===> FROM Data set: OSSINGE.END.JCLPROD TO Environment: ENVPROD System: TAPE Subsystem: TAPE Stage: 1 MEMBER ELEMENT TYPE COMMENT CCT801 JCLPROD Update REGION parameter CCT803 JCLPROD Update REGION parameter CCT806 JCLPROD Update REGION parameter ******************************* Bottom of data **********************

  20. Add/Update Output C1F0000I BC1PTMP0 CALLING EXEC AT 13:17:22 EXEC 'END.PROD.ENDEVOR.EXECLIB(EREX010)' 'TEST TEST NAPGM GNTB5000' END *** BROWSE OSSINGE.C1TEMPR1.MSGS Line 00000000 Col 0 Command ===> Scroll === ******************************** Top of Data ******************* 3:16:58 C1G0203I ADD ELEMENT GNTB5000 3:16:58 C1G0205I FROM DSNAME: OSSINGE.END.NAPGM 3:16:58 C1G0204I TO ENVIRONMENT: ENVPROD SYSTEM: TEST 3:16:58 C1G0232I OPTIONS: COMMENT: New TEST program 3:16:58 C1G0265I PROCESSOR GROUP NATNNL FOR ELEMENT GNTB5000 W 3:17:01 SMGR121I ELEMENT GNTB5000 01.00 CREATED AT LOCATION EN 3:17:01 C1G0143I BEGINNING EXECUTION OF GENERATE PROCESSOR GNA 3:17:02 C1G0006I SYMBOLIC SUBSTITUTION: 3:17:02 C1G0007I SYMBOLIC EXPINC DEFINED BY PROCESSOR: N

  21. Retrieve ------------------------------ RETRIEVE ELEMENTS ------------------- OPTION ===> ELEMENT DISPLAY OPTIONS: blank - Element list S - Summary B - Browse H - History R - Retrieve element M - Master C - Changes FROM ENDEVOR: ACTION OPTIONS: ENVIRONMENT ===> ENVPROD CCID ===> SYSTEM ===> TAPE EXPAND INCLUDES ===> N (Y/N) SUBSYSTEM ===> TAPE SIGNOUT ELEMENT ===> Y (Y/N) ELEMENT ===> CCT801 OVERRIDE SIGNOUT ===> N (Y/N) TYPE ===> JCLPROD REPLACE MEMBER ===> N (Y/N) STAGE ===> 2 1 - CERT 2 - PROD COMMENT ===> Update Region Parameter TO ISPF LIBRARY: LIST OPTIONS: PROJECT ===> OSSINGE DISPLAY LIST ===> Y (Y/N) LIBRARY ===> END WHERE CCID EQ ===> TYPE ===> JCLPROD WHERE PROC GRP EQ ===> MEMBER ===> BUILD USING MAP ===> N (Y/N) FIRST FOUND ===> Y (Y/N)

  22. Batch Actions BATCH ----------------------- BATCH OPTIONS MENU ----------------- OPTION ===> 1 BUILD SCL - Build batch SCL actions 2 EDIT - Edit request data set 3 SUBMIT - Submit job for batch processing 4 VALIDATE - Check request data set for syntax errors 5 BUILD JCL - Enter additional JCL to be included with the job REQUEST DATA SET: PROJECT ===> OSSINGE APPEND ===> N (Y/N) GROUP ===> END INCLUDE JCL ===> N (Y/N) TYPE ===> BATCH MEMBER ===> ADD OTHER PARTITIONED OR SEQUENTIAL DATA SET: DSNAME ===> JOB STATEMENT INFORMATION: ===> //OSSINGEM JOB (DSSM%%%%),'OSSINGER ENDEVOR',MSGLEVEL=(1,1), ===> // CLASS=S,MSGCLASS=T,NOTIFY=OSSINGE ===> /*JOBPARM LINES=9999

  23. Batch Actions ------------------------------- SCL GENERATION ------------------- OPTION ===> 1 DISPLAY - Display an element 2 ADD/UPDATE - Add or update an element into stage 1 3 RETRIEVE - Retrieve or copy an element 4 GENERATE - Execute the Generate Processor for this element 5 MOVE - Move an element to the next inventory location 6 DELETE - Delete an element 7 PRINT ELEMENT - Print elements, changes and detail change history 8 SIGNIN - Explicitly sign-in an element 9 TRANSFER - Transfer elements between two ENDEVOR locations 0 PRINT MEMBER - Print a compressed listing or member 1 LIST ELEMENT - Create List actions for ENDEVOR elements 2 LIST MEMBER - Create List actions for external members 3 ARCHIVE - Archive elements REQUEST DATA SET: OSSINGE.END.BATCH(ADD) APPEND: N

  24. Batch Add -------------------------- ADD/UPDATE ELEMENTS --------------------- OPTION ===> blank - Member list A - Add an element U - Update an element TO ENDEVOR: ACTION OPTIONS: ENVIRONMENT ===> ENVPROD CCID ===> SYSTEM ===> TAPE GENERATE ELEMENT ===> Y (Y/N) SUBSYSTEM ===> TAPE DELETE INPUT SOURCE ===> N (Y/N) ELEMENT ===> NEW VERSION ===> TYPE ===> JCLPROD OVERRIDE SIGNOUT ===> N (Y/N) STAGE: 1 PROCESSOR GROUP ===> UPDATE IF PRESENT ===> N (Y/N) COMMENT ===> Initial TAPE System Load FROM ISPF LIBRARY: LIST OPTIONS: PROJECT ===> OSSINGE DISPLAY LIST ===> Y (Y/N) LIBRARY ===> END TYPE ===> JCLPROD MEMBER ===> THRU MEMBER ===>

  25. Batch Actions BATCH ----------------------- BATCH OPTIONS MENU ----------------- OPTION ===> 1 BUILD SCL - Build batch SCL actions 2 EDIT - Edit request data set 3 SUBMIT - Submit job for batch processing 4 VALIDATE - Check request data set for syntax errors 5 BUILD JCL - Enter additional JCL to be included with the job REQUEST DATA SET: PROJECT ===> OSSINGE APPEND ===> N (Y/N) GROUP ===> END INCLUDE JCL ===> N (Y/N) TYPE ===> BATCH MEMBER ===> ADD OTHER PARTITIONED OR SEQUENTIAL DATA SET: DSNAME ===> JOB STATEMENT INFORMATION: ===> //OSSINGEM JOB (DSSM%%%%),'OSSINGER ENDEVOR',MSGLEVEL=(1,1), ===> // CLASS=S,MSGCLASS=T,NOTIFY=OSSINGE ===> /*JOBPARM LINES=9999

  26. Create Delete Cast Review Commit Execute Package Lifecycle

  27. Create Delete Cast Reset Review Commit Execute Package Lifecycle

  28. Create Cast Review Backout Execute Package Lifecycle Backin

  29. System Name Sequence (A - Z) SYSNAME 960704A Date (YYMMDD) Package Names

  30. Package Menu ---------------------- Package Foreground Options Menu ------------- Option ===> 1 1 DISPLAY - Display Package Information 2 CREATE/MODIFY - Create or Modify Package 3 CAST - Prepare Package for Review 4 REVIEW - Approve or Deny Package 5 EXECUTE - Submit or Execute Package 6 SHIP - Ship Packages 7 BACKOUT - Perform Backout or Backin Processing 8 COMMIT - Clear Backout Information 9 UTILITIES - Reset, Delete, or Export Package Package ID ===> ENDEVOR* Limit selection list by Package Status. These are used by the DISPLAY and UTILITIES options: In-Edit......... Y In-Execution.... Y In-Approval..... Y Executed........ Y Denied.......... Y Committed....... Y Approved........ Y

  31. Display Package DISPLAY -------------- PACKAGE SELECTION LIST ------- Row 37 to 49 COMMAND ===> D - Display Package PACKAGE STATUS DESCRIPTION ENDEVOR 960416C EXECUTED Add Program/Job Name Validatio ENDEVOR 960417A EXEC FAILED Delete GNDANNL Processor ENDEVOR 960419A EXECUTED Obsolete GNDANNL Natural Data ENDEVOR 960422A EXECUTED GNATNNL processor ENDEVOR 960423A EXECUTED GJCLNNR processor ENDEVOR 960423B EXECUTED Adding GNEN5000 and GNEN5010 ENDEVOR 960423C EXECUTED Update EREX010 & EREX030 ENDEVOR 960423D EXECUTED Delete obsolete Natural elemen ENDEVOR 960423E EXECUTED GDOCNNR and DDOCNNN processors ENDEVOR 960426A EXECUTED sign-in GNATNNL ENDEVOR 960429A EXECUTED PROC processors ENDEVOR 960509A EXECUTED Cleanup GCOBNBL COBOL Processo ENDEVOR 960513A EXECUTED Change Prod Listlib Name in Na

  32. Create Package MODIFY -------------- CREATE/MODIFY PACKAGE ---------------------- OPTION ===> B - Build Package Actions I - Import SCL E - Edit Package C - Copy Package N - Add Notes to Package PACKAGE ID: TEST 960704A STATUS: IN-EDIT DESCRIPTION ===> Fix DPS831 JCL Error PACKAGE TYPE ===> STANDARD SHARABLE PACKAGE ===> N (Y/N) APPEND TO PACKAGE ===> (Y/N) ENABLE BACKOUT ===> Y (Y/N) EXECUTION WINDOW FROM ===> 05JUL96 00:00 TO ===> 31DEC99 00:00 INPUT PACKAGE ID ===> FROM ISPF LIBRARY: PROJECT ===> OSSINGE GROUP ===> END

  33. Edit Package SCL EDIT - PACKAGE ID: TEST 960704A ----------------------------- COMMAND ===> DESCRIPTION: Fix DPS831 JCL Error ****** ***************************** Top of Data **************** 000001 MOVE ELEMENT 'DPS831' 000002 FROM ENVIRONMENT 'ENVPROD' SYSTEM 'TEST' SUBSYSTEM 'TEST' 000003 TYPE 'JCLPROD' STAGE 1 000004 OPTIONS COMMENTS "Fix JCL Error" 000005 . ****** **************************** Bottom of Data **************

  34. Cast Package CAST -------------------------- CAST PACKAGE ------------------- OPTION ===> C - Cast Package S - Display SCL N - Add Notes to Package PACKAGE ID: TEST 960704A STATUS: IN-EDIT DESCRIPTION: Fix DPS831 JCL Error PACKAGE TYPE: STANDARD SHARABLE PACKAGE: N VALIDATE COMPONENTS ===> Y (Y/N/W) ENABLE BACKOUT ===> Y (Y/N) EXECUTION WINDOW FROM ===> 05JUL96 00:00 TO ===> 31DEC99 00:00 USER ID DATE TIME CREATED: OSSINGE 05JUL96 14:26 LAST UPDATED: OSSINGE 05JUL96 14:30

  35. Review Package REVIEW ----------------------- REVIEW PACKAGE -------------------- OPTION ===> blank - Display Action Summary D - Deny Package A - Approve Package L - Display Approver Groups N - Add Notes to Package PACKAGE ID: TEST 960704A STATUS: IN-APPROVAL DESCRIPTION: Fix DPS831 JCL Error PACKAGE TYPE: STANDARD SHARABLE PACKAGE: N EXECUTION WINDOW FROM: 05JUL96 00:00 TO: 31DEC99 00:00 User Id Date Time CREATED: OSSINGE 05JUL96 14:45 LAST UPDATED: CAST: OSSINGE 05JUL96 14:45 DENIED:

  36. Approver Groups DISPLAY ------------------ PACKAGE APPROVER GROUPS -------- COMMAND ===> S - Select Approver Group PACKAGE ID: TEST 960704A STATUS: IN-APPROVAL DESCRIPTION: Fix DPS831 JCL Error PACKAGE TYPE: STANDARD APPROVER APPROVAL NUMBER OF NUMBER NUMBER ENVIRONMENT GROUP STATUS QUORUM APPROVERS APPROVED DENIED ENVPROD ENDVADMN APPROVED 0 2 0 0 ENVPROD AISUPP APPROVED 1 2 0 0 ENVPROD PRDCTRL1 1 5 0 0

  37. Execute Package EXECUTE ---------------- EXECUTE/SUBMIT PACKAGE ------------- OPTION ===> E - Execute Package S - Submit Package PACKAGE ID: TEST 960704A STATUS: APPROVED DESCRIPTION: Fix DPS831 JCL Error PACKAGE TYPE: STANDARD SHARABLE PACKAGE: N EXECUTION WINDOW FROM ===> 05JUL96 00:00 TO ===> 31DEC99 00:00 USER ID DATE TIME CREATED: OSSINGE 05JUL96 14:35 LAST UPDATED: CAST: OSSINGE 05JUL96 14:35 APPROVED: 05JUL96 14:35 EXECUTED: ENDEVOR RC:

  38. Package Execution • Foreground • Batch • Daily Scheduled DEN870 (3:15 pm) • Production Control Coordination Initiation

  39. Outstanding Issues • Emergency Changes • Package Deletions • Element Obsoletions

  40. Demo • Display Elements • Foreground Add/Retrieve • Package Processing
