  1. System IC Product Short Form Catalog Dec. 1999

  2. PRODUCT INDEX

  3. MERGED MEMORY LOGIC 6 • DIGITAL MEDIA • MCU 2 3 • MIXED SIGNAL 4 • PRODUCT LINE - UP 1 • IMAGING TECHNOLOGY 5 • FOUNDRY & ASIC 7 • SALES NETWORK 8

  4. PRODUCT LINE UP DIGITAL MEDIA Front-End QPSK NIM VSB DIGITAL TV/ Chipset HD Video 3 Chips SD Video Processor * Audio Decoder * DTV MCU Back-End JAVATM PROCESSOR MJ501 ARM7201 ARM PROCESSOR USB USB Memory Controller MCU Remote Controller 8bit General Purpose TV (OSD) MCS-51 Compatible Series RISC CPU + DSP RISC CPU 32bit MIXED SIGNAL CDMA * Base Band Analog * Voice Band Codec Telecom Micro Peripheral Super I/O SCSI Line Driver LOGIC LCD Source Driver Gate Driver Miscellaneous TV Remocon ELB Monitor Audio PC Sound Karaoke VCD MP3 IMAGING TECHNOLOGY CMOS Image Sensor Color SVGA Color VGA Color CIF B/W SVGA B/W SVGA B/W SVGA CCD Image Sensor 1/3” B/W 250/290K Pixels 1/3” Color 250/290 K Pixels 1/3” Color 330 K Pixels * 1/4” B/W 250/290K Pixels * 1/4” Color 250/290 K Pixels * 1/4” Color 330 K Pixels CMIC & BE Chipset CIS ISP Comp. & USB VD * 2’nd VD B/W TG B/W SP Color 1’st CDC * Color 2’st CDC Color TG Color 1’st ISP * Color 2’st ISP USB Interface * 2’st ISP for USB HDL350 MERGED MEMORY LOGIC Technology HDL350A HDL250 HDL180 HDL351 FOUNDRY & ASIC FOUNDRY 0.25um 0.35um 0.5um 0.6um 0.8um CELL-BASED 0.25um 0.35um 0.5um 0.6um 0.8um ASIC GATE-ARRAY 0.5um 0.65um 0.8um * Coming Soon

  5. MERGED MEMORY LOGIC 6 • PRODUCT LINE - UP • MCU 1 3 • MIXED SIGNAL 4 • DIGITAL MEDIA 2 • IMAGING TECHNOLOGY 5 • FOUNDRY & ASIC 7 • SALES NETWORK 8

  6. Digital TV 8M Byte SDRAM 8M Byte SDRAM 4M bit DRAM Tuner HDTV Video Signal Output DTV Front-End DTV Back-End I/F Demod. (LA7785M) Video Decoder (GDC21D401B) VDP (GDC21D701C) VSB Receiver (GDC21D003) Transport (GDC21D301A) ADC Audio Decoder (GDC23D801) 5.1 Ch. Audio DTV MCU (GDC21D601)

  7. Digital TV DEVICE PACKAGE FUNCTION REF. GDC21D003 (VSB Receiver) 128HQFP - 10 bit internal ADC - Synchonizer & Equalizer - VSB Channel Decoder OWN GDC21D301A (Transport Demultiplexer) 176TQFP - MPEG-2 transport & PES layer handling. - Identify & Extract TS packet PIDs OWN GDC21D401B (Video Decoder) 240HQFP MPEG2 MP@HL decoder - 3:2 Pull Down - Macroblock format out OWN - Format Conversion : All ATSC, NTSC & VGA input ,1080 60 I Output, Digital/Analog GBR/YPbPr - PIP & Display Control - Internal 3Ch. DAC - 1,2,4,8 bit/ pixel OSD OWN GDC21D701C (Video Display Processor) 304QFP(PQ2) OWN GDC23D801 (Audio Decoder) 128MQFP - Dloby AC-3 / Pro-logic/ MPEG Decoding - 3D Virtual Surround GDC21D601 (ARM RISC) 240MQFP OWN 32 bit ARM720T Core 0~60MHz Operation

  8. NIM RF Tuner HDM8513A (QPSK & FEC & ADC) Satellite Digital Set Top Box ! HYUNDAISolution Common Interface SERIAL INPUT Analog Video MPEG2 Decoder Video Encoder Video Decoder Transport Demux Analog Audio Audio DAC Audio Decoder I2C BUS I/R Remote Key Pad Interface External MCU Sub MCU SYSTEM ROM SYSTEM RAM

  9. Fully DVB&DSS compliant HDM8513AP 100 PQFP • Dual 6bit A/D converters HMD8513AT 64TQFP • Continuously variable symbol rate from 1Msps to 55Msps (75MHz clock) • Internal digital root raised cosine filter • Less than 0.5 dB implementation loss • Frequency multiplexing capability • Automated frequency search • Internal bias cancellation • Both wide band and narrow band AGC • Noise calibration for antenna steering • Output data rate as high as 68Mbps • Fixed frequency sampling clock • Simple interface with tuner and analog processing • Micro controller interface • Eight bit parallel or I2C monitor and control interface • I2C by-pass mode • Two package types 8513A Features & Benefits SECTION DEVICE PACKAGE FUNCTION REF. OWN QPSK

  10. NIM Module Products Line Up PRODUCT SPECIFICATION AVAILABILITY PART NUMBER PACKAGE FEATURE NIM Module Product 115-T-7121TP 115-T-7211TP Module DBS Module ( Tuner + HDM8513A) - ZIF Vertical type, 3 voltage input, loop-through DBS Module ( Tuner + HDM8513A) - ZIF Horizontal type, 3 voltage input, loop-thgh NOW

  11. Java Processor - enabled STB , POS , I - TV Design(Full Features) Flash ROM Up to 64MB CRT Monitor ( POS ) ROM Up to 64MB SDRAM Up to 256MB Video DAC TV Monitor ( TV, STB ) Audio CODEC MJ501 Java Processor Speaker Line-In Ethernet Card keyboard/ Mouse Fax/ Modem Printer Smart Card

  12. SECTION DEVICE PACKAGE FUNCTION REF. MJ501 JavaTM Processor GMJ30501SB 352SBGA • MJ501 is a device targeted for network consumer applications such as Web browser for TV, POS and other various consumer applications. • Designed for an integrated embedded system controller incorporating PicoJAVA-IITM. • 100MHz @ 2.5V • Integrates various I/O peripherals such as memory controller, • 2D graphics engine, CRT controller, TV encoder, PCI controller, UART, ECP, CODEC interface for audio, keyboard and mouse controller, GPIO and smart card interface in a single chip. OWN JavaTMProcessor

  13. ARM Processor - enabled Data Terminals, PDA, CNS, Web Phone Design Speaker & MIC. VGA LCD Parallel Port Serial Ports IrDA USB Power Super I/O GM82C803 Serial Ports SDRAM 32MB 7201 Multi ICE SRAM 2MB Embedded ICE EPROM 512KB Flash ROM 8MB Expansion Connector MMC PCMCIA Type2 KBD

  14. ARMProcessor SECTION DEVICE PACKAGE FUNCTION REF. ARM Processor GMS30C7201 360PBGA • The GMS30C7201 is designed for portable devices applications such as data terminals, PDA, CNS and other various portable applications. • Incorporated into the ARM720T is an enhanced memory management unit(MMU) which allows for support of sophisticated operating systems like Microsoft Windows CE. • 60MHz @ 3.3V • Integrates various I/O peripherals such as memory controller, • LCD controller, VGA controller, 2 channel PCMCIA controller, 2UART, 10Bit 5 channel ADC, 8Bit DAC for audio, keyboard controller, GPIO and JTAG debug interface in a single chip. OWN

  15. USB Controller SECTION DEVICE PACKAGE FUNCTION REF. USB Memory Card Controller GDS30C6001 32 SOP • Complete USB Device Controller for MMC /SSFTC card interface • One-chip transceiver • Supports 3.3V /5.0V Smart media Card from 2MB to 128 MB and MMC from2 MB to 32MB • Supports Windows 95 OSR2.1/2.5 ,Windows98 and Mac0s8.1(iMac) • No external power required • Compliant to USB v 1.1 Specification • Support 12Mbits/s “full speed” serial data transmission • Partly programmable USB descriptors via Host ( Supports Set_Descriptor) • For MMC, Supports SPI mode and MMC mode • For SSFDC, Support 1MByte/s data transfer • Specific Vendor commands for Card I/F OWN

  16. USB Controller - Application 1. External Card Reader USB MMC or USB SSFDC Memory Card Socket USB 2. For Digital Camera, MP3 Player ,Integrated mode in the system USB USB USB MMC or SSFDC USB MMC or SSFDC Intmcu System MCU System MCU System Decoder System Decoder Memory Card Socket Memory Card Socket

  17. MERGED MEMORY LOGIC 6 • PRODUCT LINE - UP • DIGITAL MEDIA 1 2 • MIXED SIGNAL 4 • MCU 3 • IMAGING TECHNOLOGY 5 • FOUNDRY & ASIC 7 • SALES NETWORK 8

  18. REMOTE CONTROLLER FUNCTION GUIDE DEVICE ROM PACKAGE FUNCTION APPLICATION REF. Remote Control Remote Control Transmitter GMS30Ser. GMS34Ser. GMS34xxxT 0.5-1K 0.5-1K 1K(EPROM) 16DIP/SOP 20DIP/SOP 24DIP/SOP 20SSOP OWN Remote Control (Built in Output Tr) GMS36Ser. GMS36xxxT 1K 1K(EPROM) OWN Remote Control Transmitter GMS37Ser. GMS37xxxT 1K 1K(EPROM) Remote Control (Key Extention ver) Remote Control Transmitter OWN GMS810Ser. GMS810xxT 4,8,16, 24,32K 32K (EPROM) OWN 20DIP/SOP 24skDIP/SOP 28skDIP/SOP 44PLCC Universal Remote Control LVD circuit Univerdal Remote Control Transmitter GMS81C5032 GMS87C5032 16,24,32K 32K (EPROM) OWN 28skDIP/SOP 40PDIP 44PLCC/QFP Universal Remote Control LVD circuit WDT Auto Start Wireless Keyboard, Univerdal Remote Control Transmitter * GMS81C5108 * GMS87C5108 8K 8K (EPROM) 80QFP OWN LCD Display/Controller 4ch ADC LVD circuit LCD Remote Control Transmitter (For Airconditioner) * Coming Soon

  19. G M S 3 0 (4) X X X K0 VDD K1 ＋ K2 K3 R0 REMOUT R1 R2 R3 RESET D0 D8 D9 D1 D2 GND D3 D4 OSC1 D5 D6 OSC2 D7 8 ×10 KEY MATRIX REMOTE CONTROLLER APPLICATION BLOCK DIAGRAM

  20. 8 BIT MICROCONTROLLER FUNCTION GUIDE DEVICE ROM PACKAGE FUNCTION APPLICATION REF. GMS81504 GMS81504T 4K EPROM 30SDIP/28SOP 30SDIP ADC (4CH~8CH),Timer Watchdog Timer Programmable Buzzar Driving Port Power Saving Mode Fan, Rice Cooker, Vacuum Cleaner, Air Cleaner, etc. OWN GMS81604 4K 40PDIP/42SDIP/ 44PLCC GMS81608 GMS81608T 8K EPROM Refrigerator, Air Conditioner, Microwave Oven, Rice Cooker, SVR, etc. * GMS82512 12K 42SDIP/44PLCC/ 44QFP * GMS82516 16K * GMS82524 * GMS82524T 24K EPROM GMS81508A 8K CHIP/64SDIP 64QFP/64LQFP ADC(8CH),SCI(1CH),PWM(2CH), Timer Watchdog Timer Programmable Buzzar Driving Port Power Saving Mode Refrigerator,Air Conditioner, Washing Machine, Fan Heater, Camcorder,VCR etc. GMS81516A GMS81516AT 16K EPROM GMS81508B 8K CHIP/64SDIP 64LQFP * Coming Soon

  21. 8 BIT MICROCONTROLLER FUNCTION GUIDE DEVICE ROM PACKAGE FUNCTION APPLICATION REF. GMS81516B GMS81516BT 16K EPROM CHIP/64SDIP 64LQFP ADC(8CH),SCI(1CH),PWM(2CH), Timer Watchdog Timer Programmable Buzzar Driving Port Power Saving Mode Refrigerator,Air Conditioner, Washing Machine, Fan Heater, Camcorder,VCR etc. OWN GMS81524B GMS81524BT 24K EPROM GMS87C1102 GMS81C1102 2K EPROM 16PDIP/16SOP ADC(8CH),PWM(1CH),Timer Watchdog Timer Oscillator(Crystal, Ceramic Resonator, RC) Power Saving Mode (Stop,Wake-Up,RC) Battery Charger, Car Alarm, Toy, Rice Cooker, Booster, Boilor, ABS, Air Bag, Temp Controller, etc. GMS87C1202 GMS81C1202 20PDIP/20SOP GMS87C1101 GMS81C1101 1K EPROM 16PDIP/16SOP GMS87C1201 GMS81C1201 20PDIP/20SOP GMS87C1404 GMS81C1404 4K EPROM 28SKDIP/28SOP ADC(8CH),PWM(2CH),Timer Watchdog Timer,SCI(1CH) Oscillator(Crystal, Ceramic Resonator, RC) Power Saving Mode (Stop,Wake-Up,RC) GMS87C1408 GMS81C1408 8K EPROM GMS77C1000 512×12bit EPROM 18PDIP/18SOP Timer,Watchdog Timer High Speed,Low Power

  22. 8 BIT MICROCONTROLLER FUNCTION GUIDE DEVICE ROM PACKAGE FUNCTION APPLICATION REF. GMS77C1001 1024×12bit EPROM 18PDIP/18SOP Timer,Watchdog Timer High Speed,Low Power Battery Charger, Car Alarm, Toy, Rice Cooker, Booster, Boiler, ABS, Air Bag, Temp Controller, etc. OWN GMS84512 GMS84512T 12K EPROM 52SDIP TV GMS84524 GMS84524T 24K EPROM ADC,SCI(1CH),PWM(9CH) Timer,Watchdog Timer OSD GMS81C4040 40K GMS87C4060 60K EPROM GMS87C2020 * GMS81C2020 20K EPROM 64SDIP/64QFP/ 64LQFP MWO, VCR, Audio, Fan Heater ADC(12CH),SCI(1CH),PWM (1CH) ,Timer,Watchdog Timer,High Voltage Port, Programmable Buzzar, Driving Port, Power Saving Mode * GMS81C2012 * GMS81C2112 12K GMS87C2120 * GMS81C2120 20K EPROM 40PDIP/42SDIP/ 44QFP GMS81C3004 4K CHIP/80QFP ADC(4CH),PWM(1CH),Timer, Watchdog Timer,LCD Hand-Held Game, Caller ID, Intelligent LCD Panel, Time Piece, etc. * Coming Soon

  23. 8 BIT MICROCONTROLLER FUNCTION GUIDE DEVICE ROM PACKAGE FUNCTION APPLICATION REF. HU80C500 32K 80TQFP ADC(8CH),Built-In PLL, SIO (3CH),Timer Car Audio , Home Audio OWN HU61C930 44TQFP MP3 Decoding,ADPCM, 8-Band Digital Equalizer Built-In PLL, I2C Interface MP3 Player , Car Audio HU16CF84 HU16CF44 COB HU16CF24 HU16CF14 Bank Credit, Debit Card, Electroni Commerce, Transportation, Hearth Care cards, Communication, Electronic ID card SIO, E2PROM(0.5K,1K,2K,4K, 8K,16K) 16K HU16CF82 HU16CF42 HU16CF22 HU16CF12

  24. Audio amplifier Tuner SIF/PIF AV S/W Speaker Tunning Video S/W Chroma CRT EEPROM Data store GMS84512/24 Key input Audio control On screen display Picture control Remote control TV APPLICATION BLOCK DIAGRAM

  25. 8bit T/C 2Ch Interval Timer CPU 8bit A/D Converter 4ch 23 I/O BATTERY CHARGER APPLICATION BLOCK DIAGRAM GMS81504 (30SDIP/28SOP) PHONE SUB BATTERY LED LED TR POWER TR DC

  26. TEMPERATURE DISPLAY Sensor(room temp.) Sensor(humidity) G M S 8 1 5 1 6 room set A/D converter LED Vdd Function 1. A/D converter 2. Operating S/W input 3. Remocon decoding 4. Display signal output 5. Compressor motor output 6. Fan motor output 7. 4 way valve control (cool & warm change) M Compressor motor M Fan motor(room) operating S/W M remote control receiver Fan motor(out door) Remote control transmitter 4 way valve (cool & warm) AIR CONDITIONER APPLICATION BLOCK DIAGRAM

  27. 8 BIT MICROCONTROLLER FUNCTION GUIDE DEVICE ROM PACKAGE Oper. Voltage FUNCTION APPLICATION REF. 16Bit Timer/Counter, USART, Power Saving Mode High Speed Operation (MAX. 40MHz, OTP : 33MHz) i80C32 i80C31, SAB-C301 Video-CD,SVR,MODEM,Key Phone, Cordless Phone, FAX Machine, Home Automation, Sound Card, CD-ROM, Monitor,etc. ROM LESS GMS90C32 GMS90C31 4.25~5.5 40 DIP/ 44 PLCC/ 44 MQFP i80C52/ i80C51/ SAB-C501 GMS90C52 GMS90C51 8K 4K 8K 4K EPROM GMS97C52 GMS97C51 (OTP) i87C52 Cordless Phone,Home Appliance, Wireless Keyboard, Toy, Meter,etc. 16Bit Timer/Counter, USART, Power Saving Mode, Low Voltage Operation (3V Operation) i80C32L i80C31L, ROM LESS GMS90L32 GMS90L31 40 DIP/ 44 PLCC/ 44 MQFP 2.7~5.5 i80C52L/ i80C51L GMS90L52 GMS90L51 8K 4K 8K 4K EPROM GMS97L52 GMS97L51 (OTP) i87C52L 4.25~5.5 2.7~5.5 AT89C2051 AT89C1051 GMS97C2051 GMS97C1051 (OTP) 2K 1K EPROM 16Bit Timer/Counter, UART, Low Voltage Power Down Mode, Direct LED Drive Output Battery Charger, Toy, Rice Cooker, Booster, Boiler, ABS, Air Bag, SVR, Temp Controller 20PDIP/ SOIC Video-CD,SVR,MODEM,Key Phone, Cordless Phone, FAX Machine, Home Automation, Sound Card, CD-ROM, Monitor,etc. i80C58 i80C54 32K 24K 16K GMS90C58 GMS90C56 GMS90C54 16Bit Timer/Counter, USART, Power Saving Mode High Speed Operation (MAX. 40MHz, OTP : 24MHz) 4.25~5.5 2.7~5.5 40 DIP/ 44 PLCC/ 44 MQFP i87C58 I87C54 32K 24K 16K EPROM GMS97C58 GMS97C56 GMS97C54 (OTP)

  28. SVR APPLICATION BLOCK DIAGRAM Ant Video LPF Tuner DE-EMP CL AMP VIDEO PAL MAC AFT AUDIO L Audio Audio STEREO (PLL+DE-EMP) AUDIO R MCU Volume Stereo/Mono GMS90C5x GMS97C5x Store Data EPROM LED Display Key Matrix

  29. 32 BIT MICROCOMPUTER FUNCTION GUIDE DEVICE ROM PACKAGE FUNCTION APPLICATION REF. DVD Driver,STB Digital TAD,GAMES CD-ROM Driver, Karaoke, DSC, PCMCIA Card etc. 32Bit RISC CPU, Fixed Length Instruction 40MIPS @ 40MHZ,5V Cache ( 8K Byte-Data / Instruction ) - ARM710A 144TQFP GMS30C710A - 32Bit RISC CPU+DSP 128 Byte Instruction Cache 66MIPS @ 66Mhz 100MIPS @ 100Mhz GMS30C2132 GMS30C2232 144TQFP 160MQFP HYPERSTONE ARCHITECTURE E1-32 - GMS30C2116 GMS30C2216 16Bit RISC CPU+DSP 128 Byte Instruction Cache 66MIPS @ 66MHZ 100MIPS @ 100MHz 100TQFP 16Bit Fixed Point DSP Unit UART x 2CH, SIO x 2CH ADC : 10BIT x 8CH On-Chip PLL Timer: 16bit x 4CH, 32bit x 1CH GMS31C26128 GMS37C26128 (OTP) 128K 128K EPROM 144TQFP HPC,Wallet PC,IPC ARM720T Memory Controller SCI PCMCIA Ⅱ ADC(126bit),DAC(10bit) PLL ,PMN , DMA , JTAG GMS30C7201 - 360BGA

  30. MERGED MEMORY LOGIC 6 • PRODUCT LINE - UP • DIGITAL MEDIA 1 2 • MCU 3 • MIXED SIGNAL 4 • IMAGING TECHNOLOGY 5 • FOUNDRY & ASIC 7 • SALES NETWORK 8

  31. CDMA FUNCTION GUIDE SECTION DEVICE PACKAGE FUNCTION APPLICATION REF. • Combined A/D, D/A and Filters • Electric Microphone Bias Reference Voltage Available • Compatible with All DSPs • Programmable Volume Control in 13bit Linear Mode • Designed for Standard 2.048MHz Master Clock *Voice Band CODEC for CDMA GM0936TQ 48TQFP Own CDMA Cellular/PCS • CDMA / AMPS Dual mode Operation • 2.7 V min. Supply voltage Operation • Operational Mode compatibility with the • MSM2300&3000 • Enhanced features with MSM3000 through • three-line serial bus interface (SBI) • BBA+Tx-AGC, BBA+Rx-AGC *BBA3000 GDC6P1310TQ GDC6P1320TQ 48TQFP Own CDMA Cellular/PCS *GDC6P1310TQ Mixer Ant. PA Tx AGC MobileStationModem *Voice BandCODEC(GM0936TQ) DA BBA SRAM Duplex Synth. Flash Memory LNA Rx AGC *GDC6P1320TQ * Coming Soon

  32. GD75232 ⓐ GD75232 SUPER I/O MICRO PERIPHERAL Available ⓐ : GM82C803C(Prime 3C) ⓑ : Line Drivers / Receivers Not Available ⓒ : SIR Module Printer External Storage used by EPP/ ECP (CD-ROM, HDD, FDD) ⓑ External Fax / Modem Serial Mouse Super I/O Part Memory Part ⓒ Main Chipset Part CPU Part BIOS Part (Main Board)

  33. MICRO PERIPHERAL FUNCTION GUIDE SECTION DEVICE PACKAGE FUNCTION REF. Super I/O GM82C803C 100 PQFP 2.88MB FDC, UART with FIFO, EPP/ECP PIO, IDE, SIR, PC 95 Compatible SMC37C669 SCSI GM82C700 68 PLCC/80 QFP Fast SCSI-2 Controller AIC6360 UART GM16C550 40 DIP, 44 PLCC/QFP UART with 16byte FIFOs NS16C550 Line Dirver / Receiver GD75232 20 DIP/SOP EIA RS-232D Interface (3D/5R) SN75C185 GD75323 20 DIP/SOP EIA RS-232D Interface (5D/3R) Own

  34. TELECOM FUNCTION GUIDE Cordless Telephone Hand-set Single In Line Telephone & Cordless Telephone Base-set GM6530/32/35 DPLL 2 E PROM GL3361 FM IF GL6840A/B GL6850/1 GMS81C6004 Compander Ringer DPLL Dialer GL6551 GL6552 FM IF 1 2 3 4 5 6 7 8 9 * 0 # Dialer Compander GL6965 GL6962/A Speech Key Pad Microcontroller GMS81C6004 MIC Speaker HEI Products

  35. TELECOM FUNCTION GUIDE SECTION DEVICE PACKAGE FUNCTION REF. Compander GL6551 20 DIP/SOP Low Operating Voltage : 2.4 ~ 7V Total Gain : 10 ~ 100 dB TK10651 GL6552 14 DIP/SOP Built-in Auto Level Control KA8512 FM IF GL3361 16 DIP/SOP Low Power FM IF for CT MC3361C DPLL GM6530 16 DIP/SOP 15Ch, Selecting for 46/49㎒ CT (Serial Interface) MC145169 GM6532 16 DIP/SOP 10Ch, Selecting for 45/48㎒ CT (Parallel Interface) HYL21014 GM6535 16 DIP(300MIL) 16 SOP(150MIL) Universal Programmable PLL for CT MC145162 Speech GL6965 20 DIP External Adjustable Transmitting, Receiving & Side Tone Gains TA31065N GL6962/A 16 DIP/SOP Auto Gain Control, Low Operating Voltage TEA1062/A Ringer GL6840A/B 8 DIP Internal Rectifier Bridge & Zener Diode L3240/1240 GL6850/1 8 DIP Adjustable 2-frequency Tone KA2410/1 X-point Switch GM62093A 40 DIP CMOS 12 x 8 Cross Point Switch with Control Memory M093 LED Driver GM6486 40 DIP / 44 PLCC 33 Output LED Driver MM5486

  36. T V / REMOCON / OTHERS FUNCTION GUIDE DEVICE PACKAGE FUNCTION REF. SECTION TV GL3812 22 DIP Audio/Video Switch Own GL3820 8 DIP Video Switch TEA2014 Remocon GL3276A 8 SOP Preamplifier for Remote Control Use • PC2800AGR GL3277 8 SOP Preamplifier for Remote Control Use (Enhanced immunity against noise, Support RC-5) OWN SMPS GL494 16 DIP/SOP Voltage Mode PWM Control Circuit TL494 Leakage Detector GL7101 8 DIP/SOP Earth Leakage Current Detector M54122L Sync. Deflection Circuit GL1151 20 DIP Horizontal Phase Shifter AFC, Sawtooth Wave Generator LA7851 Clock Driver HC2509 HC2510 24 TSSOP PLL Clock Distribution for Synchronous DRAM Application PI6C2509 PI6C2510 Memory Register HG74ALVC16835C HG74ALVC168235C 56 TSSOP/ SSOP 18-bit Universal bus Driver Designed for 2.3V to 3.6V Operation PI74ALVC16334

  37. LCD Drive IC FUNCTION GUIDE ▣ TFT-LCD MODULE BLOCK DIAGRAM VGA CARD LCD MODULE Source Driver L V D S Controller (ASIC) VGA Card Gate Driver TFT-LCD Panel DC-DC Converter

  38. LCD Drive IC FUNCTION GUIDE SECTION DEVICE PACKAGE FUNCTION REF. TFT-LCD GM10S6401 TCP TFT-LCD Source Driver / 6bit / 384Ch. Output VS3384 GM10S6402 TCP TFT-LCD Source Driver / 6bit / 384Ch. Output TMS57561 HD66324 GM10S8401 TCP TFT-LCD Source Driver / 8bit / 384Ch. Output / 10V uPD16750 GM10S8402 TCP TFT-LCD Source Driver / 6bit / 384Ch. Output / 15V T6L50 *GM10G5251 TCP TFT-LCD Gate Driver / 256Ch. Output TMS57605 *GM10G5252 TCP TFT-LCD Gate Driver / 256Ch. Output / Output Mod. Own STN-LCD *GM11S1201 TCP / COG STN-LCD Driver / 65Com * 132Seg SED1565 SEG-LCD HL14203 QFP Segment type LCD Driver / 3Com * 42Seg LC75853 HL15203 QFP Segment type LCD Driver / 3Com * 52Seg LC75823 HL15703 QFP Segment type LCD Driver / 3Com * 57Seg LC75883 HL14104 QFP Segment type LCD Driver / 4Com * 41Seg LC75854 HL15604 QFP Segment type LCD Driver / 4Com * 56Seg Own * Coming Soon

  39. Audio FUNCTION GUIDE Section Device Package Funtion Application Ref. DSP& Controller QS3100 144QFP/LQFP • PCI FM Sound Controller • Hardwired 3D Effect PC Sound Own QS3000 100FP/LQFP • PCI FM Audio Controller with Softwired 3D • Wavetable & Audio Station Software Support PC Sound Own QS1500 100/148QFP • 64Poly Wave Table Sound DSP • Max 24M ROM & AC97 Codec Compatible • Reverb & Chorus, Mic Echo Game Machine Music Instrument Own QS1000 100QFP • Wave Table 2Chip Sound DSP • 4/8/16M ROM Compatible KARAOKE,VCD Own QS1080 100QFP • Wave Table 1Chip Sound DSP • 8M ROM Compatible Built-in KARAOKE,VCD Own DAC& Codec GMAC9704 48LQFP • High Performance  Audio CODEC • 18bit Full Duplex Stereo D/A, A/D PC, MP3 STAC9704 GMAC9708 48LQFP • High Performance  Audio CODEC • 2 Additional DAC's for Multi-Channel Application PC, MP3 STAC9708 GM0560 24SSOP • High Performance  Audio DAC • 384fs/768fs or 33.8688MHz System Clock • Dual PLL, 96dB Dynamic Range DVD, DBS, Karaoke, MP3 PCM1727 GM0561 20SSOP • High Performance  Audio DAC • 384fs/768fs or 33.8688MHz System Clock • 96dB Dynamic Range DVD, DBS, Karaoke, MP3 PCM1720 GM0550 24SSOP • High Performance  Audio DAC • 256fs/384fs/768fs System Clock • 96dB Dynamic Range DVD, DBS, Karaoke, MP3 PCM1723 GM0551 20SSOP • High Performance  Audio DAC • 256fs/384fs/768fs System Clock • BPZ Control, De-emphasis DVD, DBS, Karaoke, MP3 PCM1720 GM0552 GM0553 20SSOP • High Performance  Audio DAC • 256fs/384fs/768fs System Clock DVD, DBS, Karaoke, MP3 PCM1717 PCM1718

  40. MERGED MEMORY LOGIC 6 • PRODUCT LINE - UP • DIGITAL MEDIA 1 2 • MCU 3 • IMAGING TECHNOLOGY 5 • MIXED SIGNAL 4 • FOUNDRY & ASIC 7 • SALES NETWORK 8

  41. Row Driver CMOS Image Sensor Features • 800 x 600, 640x480, 400x300 Pixels • 8um x 8um Square Pixels • High Efficiency, Low Voltage Photosensor with on chip RGB color filters and microlens • Integrated 8-bit ADC for Direct Digital Output Built-in AGC • Digital Correction of Fixed Pattern Noise • Integrated Pan and Window Control • Clock Speed up to 15Mhz for 30fps Operation • Programmable Frame Rate and Readout Mode • Control through Standard I2C Bus • 3.3V (5V tolerant), 65mW@30fps of SVGA Color /B&W Pixel Array ADC Block I2C Timing and Control Register Line Buffer 8bit Horizontal Select

  42. Digital Imaging Systems • PC Video • Input Device • (PVID) Analog CCD Imager CDS/ADC/AGC Timing Gen. Digital Processing and Interface PC System Direct Display Communication channel Digital DC/DC Converter Driver CMOS Pixel Array • Low Power Consumption • - Mobile Application • Single Power Supply • SOC (System On a Chip) • - Lower System Cost • Ideal for PC and • Digital Communication Programmable Driver ADC Buffer

  43. Functional Block Diagram CMOS Pixel Color /B&W Pixel Array Control Signals Row Driver Analog Output Timing and Control Register ADC Block I2C Digital Noise Filter 1.7V Voltage 8bit Line Buffer Horizontal Select Intensity x Time

  44. 48 CLCC VGA HV7131B 640x480 Effective pixels, Integrated 8-bit ADC with Built-in AGC /20 CDIP CIF HV7121B 48 CLCC 400x300 Effective pixels, Integrated 8-bit ADC with Built-in AGC SVGA HB7141B 48 CLCC 800x600 Effective pixels, Integrated 8-bit ADC with Built-in AGC 48 CLCC VGA HB7131B 640x480 Effective pixels, Integrated 8-bit ADC with Built-in AGC /20 CDIP CMOS Image Sensor Product SECTION DVICE PACKAGE FEATURE SVGA HV7141B 48 CLCC 800x600 Effective pixels, Integrated 8-bit ADC with Built-in AGC Color Black /White CIF HB7121B 48 CLCC 400x300 Effective pixels, Integrated 8-bit ADC with Built-in AGC Dedicated sensor control and signal processing chip for HYUNDAI CMOS ISP H1A424M167 64 LQFP Chipset Comp./USB HSE401 100 PQFP HYUNDAI Image Compression & Maple bus interface & DSP/ISP interface Controller

  45. Black & White CCD Camera DISPLAY EIA/CCIR Type VIDEO OUTPUT CCD Image Sensor Signal Processor GCA325/29DB GCD4402 LENS Monitor Timing Generator Vertical Clock Driver GCD1001S GCD5412 HEI Products

  46. PACKAGE 16 PLASTIC DIP TIMING & SYNC PULSE GENERATOR SIGNAL PROCESSOR FOR B/W CCD CAMERA B/W CCD Camera DISPLAY DEVICE FUNCTION REF. GCA325DB 250K EFFECTIVE PIXELS . EIA TYPE ICX054AL GCA329DB 16 PLASTIC DIP 290K EFFECTIVE PIXELS. CCIR TYPE ICX055AL GCD1001S 16 SSOP VERTICAL CLOCK DRIVER FOR CCD SYSTEM OWN GCD5412 48 TQFP CXD2400R GCD4402 32 TQFP CXA1310AQ

  47. Digital Color CCD Camera DISPLAY NTSC/PAL Type CCD Image Sensor ANALOG Output CDC DSP CCIR656 Digital Output GCD4101/AT GCD4002 GCA325/329DC LENS *GCD4102 Timing Generator Camera Controller USB Interface Vertical Clock Driver USB Output GCD1001S GCD2101 GMS81516 GCD3001A CDC : CCD to Digital Converter DSP : Digital Signal Processor USB : Universal Serial Bus HEI Products * Coming Soon

  48. Color CCD Camera DISPLAY VGA Type : New Feature CCD Image Sensor CDC GCA333KC GCD4002 LENS Vertical Clock Driver DSP USB Output GCD4132 GCD1001S CDC : CCD to Digital Converter DSP : Digital Signal Processor USB : Universal Serial Bus HEI Products * Coming Soon

  49. Color CCD Camera DISPLAY DEVICE PACKAGE FUNCTION REF. GCA325DC 16 PLASTIC DIP 250K Effective pixels NTSC type CCD image sensor ICX054AK GCA329DC 16 PLASTIC DIP 290K Effective pixels PAL type CCD image sensor ICX055AK GCA333KC 16 PLASTIC DIP 330K Effective pixels VGA type CCD image sensor ICX084AK GCD1001S 16 SSOP Vertical CCD clock driver OWN GCD2101 48 TQFP Timing clock generator for NTSC/ PAL CCD camera OWN GCD4101/AT 100 LQFP Digital signal processor for NTSC/ PAL CCD color camera OWN GCD4002 48 LQFP CCD output to 10 bit digital converter (CDS/AGC/ADC) OWN GCD3001A 100 TQFP USB camera interface OWN GCD4132 100 LQFP 1ST USB Image signal processor for VGA OWN GMS81516 64 LQFP Camera controller OWN
