  1. Kite Presentation Team III Marc Durigon Adam Menko Daniela Carizzo Theodore Dixon

  2. Kite Components • Top or “Leading Edge” • Area that the wind flows over to create the kite's lift. • Right/Left “Wings” • Right and left side of the kite; The "Wing Tip" is the furthest edge of the right or left wing.   • “Spar” • Frame of kite

  3. “Bridle” • Network of lines that attach to multiple “connecting points” on the kite and allow the kite to respond or perform to the flyer's commands. • Many kites will have different connecting points located on the bridle for different flying conditions.   • “Lines” • Flying lines used to control the kite.

  4. “Sail” • The material that spans the area of the kite.

  5. Kite Composition • Frame Materials • Wood: best if light, strong, and flexible, i.e. hardwood stripwood, staking cane, or rattan. • Fiberglass: rods or tubes • Carbon fiber: rods or tubes. • Graphite rods

  6. Sail Material • Tyvek: durable and lightweight; good for a myriad of applications. • Ripstop Nylon: tiny filaments of nylon slow the spread of rips. • Polyethelene: layered plastic. • Ripstop Polyester: lightest material, and least porous; generally makes for very light and fast kites.

  7. Lines • Generally nylon. • Most commonly range in number from 1- 4

  8. Sled Design

  9. Box Design

  10. Delta Design

  11. Applications • Bridge Building • Used to string the first cable for the bridge over Niagara falls. • Have also been used to carry telephone wires across gaps which would otherwise be hard to navigate. • Teddy Bear Lifting

  12. Lifting transmitting aerials • Marconi utilized kites in early experiments. • Allies in WWII at times used a box kite and a transmitter to communicate. • Man lifting • Prior to the development of powered flight, the military recognized the potential of kites for reconnaissance. • Not advisable.

  13. Search and Rescue • Beacon used for locating lost soldiers. Tubes of luminescent material will be attached for easy visibility, as well as a radio transmitter to speed up location. • Must reach altitude of at least 150 in order to achieve a visibility of 9 miles.

  14. Food/material transportation • Could be used to get food to people trapped in situations that prevent immediate rescue, i.e. avalanches, floods, and other natural disasters. • Transport materials for construction projects in hard to access venues.

  15. Chemical Weaponry Dispensation • Cans attached to the frame will contain chemical agents to be dispensed on enemy.
