  1. The MPEG-4 Fine-Grained Scalable Video Coding Method for Multimedia Streaming Over IP Hayder Radha ,Mihaela van der Schaar and Yingwei Chen IEEE TRANSACTIONS ON MULTIMEDIA, VOL.3, NO.1,MARCH 2001

  2. Outline • Introduction • SNR FGS Video Coding Method • FGS Coding with Adaptive Quantization • Hybrid Temporal-SNR Scalability with an All FGS Structure • Conclusions

  3. Introduction • Video-Coding and Networking • Minimal real-time processing and rate control when large number of unicast • Highly adaptable to unpredictable bandwidth • Low-complexity decoding and low-memory requirements

  4. Introduction(2) • Able to support both multicast and unicast applications • Scalable bitstream must be resilient to packet loss events

  5. SNR FGS Video Coding [ Rmin = Rb, Rmax = Rb + Re ]

  6. SNR FGS Video Coding(2)

  7. SNR FGS Video Coding -encoder • Two encoders base layer->motion compensation enhancement layer->fine-granular • Each DCT FGS-residual frame consists of NBP bitplanes

  8. SNR FGS Video Coding -scanning order

  9. Architecture for the SNR FGS Video Coding -decoder

  10. SNR FGS Video Coding -performance • Compared with traditional SNR scalability video coding

  11. SNR FGS Video Coding -performance(2)

  12. SNR FGS Video Coding -performance(3)

  13. SNR FGS Video Coding -conclusions • FGS exploits temporal redundancy only at the base layer • FGS is good for high motion sequences such as “movie trailers”,certain commercials and news clips with high-action content

  14. SNR FGS Video Coding -conclusions • Base-layer could have a major impact on the overall performance of FGS • [R2,Rmax] could be significantly better than the average performance over the wider range[R1,Rmax]

  15. FGS Coding with Adaptive Quantization • FGS-based AQ is achieved through bitplane shifting • Selected macroblocks within an FGS enhancement layer frame • Selected coefficients within the 8 * 8 blocks

  16. Adaptive Quantization-Selective Enhancement

  17. Adaptive Quantization-frequency weighting

  18. Adaptive Quantization-combine SE with FW

  19. Adaptive Quantization-notice • SE : macroblock-by-macroblock basis • FW : use the same FW matrix • Selective enhancement is a relative operation • Up-shifting operation does not guarantee that a particular SE macroblock gets scanned earlier(MSB)

  20. Adaptive Quantization-evaluation • Not improve the rate-distortion performance ,but rather to improve the visual quality • SE can be used to enhance a particular region • FW can reduce some of blockiness, but may softening some of the sharp edges and other finedetails

  21. Adaptive Quantization-evaluation(2)

  22. Hybrid Temporal-SNR Scalability • Temporal scalability : Enhance the motion smoothness of compressed video • F = FBL + FEL • Provide the flexibility of choosing between temporal scalability and SNR scalability (Users’ performance and real-time bandwidth)

  23. all-FGS hybrid temporal-SNR scalability structure

  24. Architecture for the all-FGS hybrid temporal-SNR scalability encoder

  25. Architecture for the all-FGS hybrid temporal-SNR scalability decoder

  26. Performance Evaluation of the Hybrid FGS Scalability Method

  27. Performance Evaluation of the Hybrid FGS Scalability Method

  28. Conclusions • MPEG-4 FGS framework • Supporting unicast and multicast Internet video application • Adaptive quantization • Hybrid temporal-SNR scalability method
