Formaldehyde sensor

If you want to know about the overall air quality, formaldehyde sensor is the best to go for. It will let you know the air quality of your surroundings.<br><br>More info:- http://en.gassensor.com.cn/FormaldehydeSensor/

Engassensor
Télécharger la présentation

Formaldehyde sensor

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Formaldehyde Gas sensor http://en.gassensor.com.cn/

  2. About us Cubic Sensor and Instrument Co.,Ltd is a leading manufacturer of gas sensors and sensing solutions, which are for indoor air quality, outdoor air quality and automotive air quality, including non-dispersive infrared (NDIR) CO2 sensors, LED particulate matter sensors, laser particulate matter sensors, formaldehyde sensors, volatile organic compounds (VOCs) sensors, medical ultrasonic O2/flow sensors and etc. Founded in 2003, with over 16 years of experience on gas sensing technologies, Cubic has become the comprehensive provider of gas sensors, gas analyzers, gas monitoring systems and IoT gas sensing solutions. http://en.gassensor.com.cn/

  3. Diversified applications around the world already benefit from Cubic’s innovative patented technologies, including the fields of indoor and outdoor air quality monitoring, air purifier, heating, ventilation and air conditioning (HVAC) system, smart home, smart city, consumer electronics, automotive cabin air conditioning system, health care, industrial safety and intelligent agriculture etc.Cubic is ISO 9001, IATF 16949, ISO 14001 and OHSAS 18001 certificated, and has already been automotive authorized supplier.

  4. Air Quality Monitor Formaldehyde Detector Cubic Sensor Formaldehyde is a common precursor to more complex compounds which are used in several industrial applications. Formaldehyde resin is used in the textile industry to produce non-crease fabrics and is also a key component in the manufacture of automobiles. Formaldehyde solution is commonly used as a disinfectant to kill most bacteria and fungi and can also be used to preserve tissues or cells for scientific analysis. However, when you use formaldehyde sensor it will be easier for you to come with perfect figure that will depict with various things that come with after result. These sensors are completely developed in order to make all these things possible with the help of right kind of things that are making something more crucial. So, it would be great to install these sensors for better result. http://en.gassensor.com.cn/

  5. CB-HCHO V0.3 is the third generation formaldehyde sensor is an electrochemical gas concentration sensor. It adopts a dual-channel structure design and unique electrolyte packaging technology. Through mathematical algorithms and scientific calibration, it can simultaneously output formaldehyde and TVCO. Built-in digital temperature and humidity sensors combined with intelligent algorithms, product detection is more accurate and application is more convenient. FEATURES ▪ High sensitivity up to 1ppb ▪ HCHO, VOC in-one design ▪ Full range temperature and humidity compensation ▪ Unique dual-channel design, good anti-interference ▪ Multiple communication methods：URAT、IIC、PWM ▪ Lifetime can reach 3 years (in air) APPLICATIONS ▪ Portable instrument ▪ Desktop air quality monitoring equipment ▪ AirPurifier ▪ HVAC system ▪ Air Conditioner ▪ Smart Home http://en.gassensor.com.cn/

  6. Our all Products • CO2 Sensor • Particulate Matter Sensor • Formaldehyde Sensor • VOC Sensor • Integrated Air Quality Sensor • IAQ Controller & Monitor • Oxygen and Flow Sensor • Mainstream EtCO2 • Spirometer • Industrial Gas Sensor • Ultrasonic Gas Meter & Module • Oxygen Sensor • Gas Analyzer SOLUTION • HVAC & Air Purifier • Smart Home • Outdoor Air Quality • Automotive Air Quality • Intelligent Agriculture • Industrial Safety • Medical Health http://en.gassensor.com.cn/

  7. Performance Evaluation of Real Time Formaldehyde Monitors SPECIFICATIONS: Working principle Electrochemical Measurement range HCHO: 0~1ppm VOC: 0~10ppm（equivalent alcohol concentration） TVOC: 0~10ppm（equivalent alcohol concentration） HOCHO Measurement accuracy ≤0.1ppm：±0.025ppm >0.1ppm：±25% reading（Reference instrument: Gaseraone，25±2℃，50±10%RH） Resolution HCHO: 1ppb VOC: 0.01ppm TVOC: 0.01ppm Response time T90 50s（@25±2℃，50±10%RH） Working condition 0~40℃；15~95%RH（Non-condensing） Storage condition -20~50℃；0~95%RH（Non-condensing） Working voltage DC (+3. 5V ~ +5.5V) Working current <15mA Signal Output 1、UART_TTL（3.3V） 2、IIC（Reserved） 3、PWM（Reserved） Dimension W23*H32*D7 Lifetime 3 years (@0.1ppm Formaldehyde concentration) If you want to know about the overall air quality, formaldehyde sensor is the best to go for. It will let you know the air quality of your surroundings. http://en.gassensor.com.cn/

  8. Contact us Cubic Sensor and Instrument Co.,Ltd Address: Fenghuang No.3 Road, Fenghuang Industrial Park, Eastlake Hi-tech Development Zone, Wuhan, 430205, China Tel: +86-2781628827 Fax: +86-27-87401159 Email: info@gassensor.com.cn Web:- http://en.gassensor.com.cn/
