Extended Potential Field Method. Adam A. Gonthier MEAM 620 Final Project 3/19/2006. Can use continuous configuration space Therefore, avoids complexities of discrete planning Field is modeled by potential functions . Benefits: Local method Does not require global map

Télécharger la présentation
## Extended Potential Field Method

**An Image/Link below is provided (as is) to download presentation**
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

**Extended Potential Field Method**Adam A. Gonthier MEAM 620 Final Project 3/19/2006**Can use continuous configuration space**Therefore, avoids complexities of discrete planning Field is modeled by potential functions Benefits: Local method Does not require global map No prior knowledge of obstacles required Drawbacks: Get caught in local minima Does not find optimal path Obstacles, robot modeled as points; in real world, they are not points Potential Field Approach**Potential Field Approach**• Goal is modeled as attractive force • Obstacles modeled as repulsive forces • Robot modeled as point • Robot follows gradient of force field, stopping at goal point 2-D Symmetric Gaussian Obstacle Parabolic Goal Well Total Potential Field**Potential Field Algorithm**• Very simple algorithm • Start at initial point • Find path opposite to gradient • Set new point at distance d along path from old point • Repeat until goal point is reached -Prof. John Spletzer Lehigh University**Potential Field Extension**M. Khatib and R. Chatila • In addition to the goal and obstacle potentials, include rotation and task potentials: • Rotation Potential: • A potential function for the robot’s orientation relative to the goal is considered, thus forcing the robot along a ‘straighter’ path • Task Potential: • Filter out obstacles that should not influence the robot’s motion; the obstacles that are not in the robot’s path. • These additions should help create a superior path for the robot: • The rotation field helps avoid overturning from an obstacle • The task field helps avoid unnecessary turning.**Goal**To produce a Matlab implementation of the extended potential fields method for several configurations References Prof. John Spletzer: http://www.cse.lehigh.edu/%7Espletzer/cse397_Fall05/lec014_MotionPlanning.pdf H. Choset et al (2005). Principles of Robot Motion: Theory, Algorithms and Implementations. Cambridge, MA. MIT Press M. Khatib and R. Chatila. An extended potential field approach for mobile robot sensor-based motions. In Proc. Int. Conf. on Intelligent Autonomous Systems (IAS'4), 1995. R. W. Beard and T.W. McLain, Motion Planning Using Potential Fields, January 2003 Goal and References
