Understanding Flowchart and Paragraph Proofs in Geometry

DESCRIPTION

This lesson focuses on mastering flowchart and paragraph proofs in geometry. Students will explore how to complete sentences relating to angle relationships, such as congruence and supplementary angles. The lesson includes a warm-up activity, detailed examples of flowchart proofs, and the construction of two-column proofs. Students will practice ensuring the logical structure of their arguments through clear justifications for each step, enhancing their understanding of geometric concepts through visual representation and written explanations.

1 / 9

Télécharger la présentation

Understanding Flowchart and Paragraph Proofs in Geometry

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 2-7 Flowchart and Paragraph Proofs Warm Up Lesson Presentation Lesson Quiz Holt Geometry

  2. Warm Up Complete each sentence. 1.If the measures of two angles are ? , then the angles are congruent. 2. If two angles form a ? , then they are supplementary. 3. If two angles are complementary to the same angle, then the two angles are ? . equal linear pair congruent

  3. A second style of proof is a flowchart proof, which uses boxes and arrows to show the structure of the proof. The justification for each step is written below the box.

  4. Example 1: Reading a Flowchart Proof Use the given flowchart proof to write a two-column proof. Given: 2 and 3 are comp. 1  3 Prove: 2and 1are comp. Flowchart proof:

  5. Example 1 Continued Two-column proof: 1. 2 and 3 are comp. 1  3 1. Given 2. m2 + m3 = 90° 2. Def. of comp. s 3. m1 = m3 3. Def. of  s 4. m2 + m1 = 90° 4. Subst. 5. 2 and 1 are comp. 5. Def. of comp. s

  6. Check It Out! Example 1 Use the given flowchart proof to write a two-column proof. Given: RS = UV, ST = TU Prove: RT TV Flowchart proof:

  7. 5.RT TV Check It Out! Example 1 Continued 1.RS = UV, ST = TU 1. Given 2.RS + ST = TU + UV 2. Add. Prop. of = 3. Seg. Add. Post. 3.RS + ST = RT, TU + UV = TV 4.RT = TV 4. Subst. 5. Def. of  segs.
