  1. W KME PMS Interface Telecom Division Kyushu Matsushita Electric CO., LTD. “ Ref No. 000430-1

  2. CTI (TAPI 2.1) Software Configuration ACD Report Easy Dialer HOTEL FOS Application RS-232C TAPI 2.1 (Windows OS) PMSi Middle-ware (Inter face) PC TSP (KME Original Interface) (Free of Charge) RS-232C PBX KME PBX (TD-Link1.3) This feature is available from V2-2 “

  3. Panasonic PMS Software Package KME PMS • PMS Interface Package Models KX-A291X 64 users KX-A292X 128 users KX-A293X 448 users • Contents of PMS Interface Software Package 1) CD-ROM : Software Manual / Operating Instructions / Getting Started 2) Dongle (Hardware key for copy protection : Controlling the number of users) 3) Getting Started Manual / End-User License “

  4. Panasonic PMS Interface System Configuration Room PMS Interface KME PMS Interface Hotel Software RS232C RS232C Operator • PMS Interface Software • (PBX - F.O.S. INTERFACE) • Control PBX feature • Inform PBX status “

  5. System Configuration (1) PC 3 COM1 KX-TD500 KX-TD1232 Call Accounting Software by other companies PC 1 COM3 COM1 RS232C PMS Interface package COM2 Front Desk Dongle COM2 Digital PBX FOS by other companies (*1) COM2 COM1 KX-A291,2,3X RS232C PMS Interface PC 2 (*1)Target software companies for Hotel Front Desk : Fidelio, HIS,Eltrax etc “

  6. System Configuration (2) Front Desk PC 1 PC 2 KX-TD500 KX-TD1232 Call Accounting Software by other companies COM1 RS232C PMS Interface package FOS by other companies Dongle Digital PBX COM1 COM2 RS232C PMS Interface “

  7. System Configuration (3) Front Desk PC 1 PC 2 Call Accounting Software by other companies KX-TD500 KX-TD1232 COM3 FOS by other companies RS232C COM1 PMS Interface package RS232C Dongle COM2 Digital PBX COM2 COM1 RS232C “

  8. System Configuration (4) Call Accounting Software by other companies COM5 KX-TD500 KX-TD1232 RS232C COM4 COM1 RS232C PMS Interface package COM3 Dongle RS232C Digital PBX FOS by other companies COM2 “

  9. Environment of Panasonic PMS Interface Minimum Requirements (for installing PMS Interface Software only) 64 Rooms 128Rooms 448Rooms • CPU : Pentium 133MHz 166MHz 166MHz • RAM : 32M 32Mb 32M • HDD : 450M 450M 450M Recommended (for installing PMS Interface Software only) 64 Rooms 128Rooms 448Rooms • CPU : Pentium 350MHz 350MHz 350MHz • RAM : 64M 128M 128M • HDD : 800M 1G 2G Windows based Windows NT Service Pack5 / Windows98 or later PBX - PMS Connection Interface : RS232C Target PBX : KX-TD1232(Single)/TD500 “

  10. Panasonic PMS Interface Software ･ Low to mid size integrated solution for the Hotel market ･ Integrated with FOS (Front Office System) Default : Fidelio, HIS, Eltrax (Sulcus) and KME standard Additional : Other local FOS (by setting PMS I/F parameters) ･ Hotel Service Management Room Status / Mini Bar Status Interface ･ Customer Satisfaction Extension Feature Control Interface (Message Waiting Lamp, Wake Up Call etc.) ･ Call Information SMDR information for guest’s room “

  11. PBX - F.O.S. INTERFACE Message (Information from F.O.S. to PBX) • Extension Block / Unblock (COS) • Wakeup Call Set / Cancel • Do Not Disturb ON/OFF • Message Waiting Lamp ON/OFF • Call Forwarding ON/OFF • Guest Name Set/Clear • Credit Limit Exceeded (to Change Class of Service) • Check In (Unblock Ext. / Set Guest Name etc...) • Check Out (Block Ext. etc...) • Set PBX’s Date and Time • Get PBX’s Date and Time Front Office System Panasonic PBX System “

  12. PBX - F.O.S. INTERFACE Command (Information from PBX to F.O.S.) • Extension Block / Unblock (Change COS) Report • Wakeup Call Set / Cancel Report • Do Not Disturb ON/OFF Report • Message Waiting Lamp ON/OFF Report • Call Forwarding ON/OFF Report • Guest Name Set/Clear Report • Room Status • Mini Bar Status • SMDR Information • Wake Up Confirm • System Date and Time Report (FOS need to request to get PBX’s Date and Time) Front Office System Panasonic PBX System “

  13. Message Command Command Message Customizing KME PMS I/F We can modify this program We can modify this program PMS Interface package PBX interface FOS interface FOS “

  14. PBX interface FOS interface Connection Message Command Customizing KME PMS I/F “

  15. Thank You Very Much For Your Attention Telecom Division Kyushu Matsushita Electric CO., LTD. “
