  1. TR 1-470Performance Analysis for Dummies Lars Ejskjaer Greg Ferguson

  2. Understanding Performance Analysis Can Help You Sell Gainbetterunderstanding of yourcustomersenvironment Growawareness to possible system bottleneckareas Understand changesthatcanenhanceyourcustomers overall satisfaction GettingStarted… Simple Analysis (1, 2, 3) Valuable Tools and Resources Agenda

  3. The Customer Problem ”My storage is slow…”

  4. Guide the customer to best practices Recommend solutions Administrative Product Provide advice in the context of their environment Your Goal

  5. Understanding of how the customer’s environment was set up Ability to identify missed best practices Administrative Performance Ability to identify common performance issues What You Will Need To Know

  6. Getting Started

  7. Easily Collect Performance Data - Perfstathttps://communities.netapp.com/docs/DOC-16209 Pro Tip: Perform multiple smaller iterations versus one larger iteration for better visibility

  8. Loading Data into LatX for Analysis https://latx.netapp.com/

  9. Find and View the Perfstat NetApp Confidential – Limited Use

  10. FindingSpecificData Pro Tip Use PRESTATS iteration 1 for configuration information Use POSTSTATS for performance measurements

  11. Analysis Strategy • Understand Configuration • Aggregates • Volumes • Look for configuration errors • Analyze Performance • System • Disk • Flash • Make Recommendations

  12. The Simple Analysis Part 1 Disk Configuration

  13. Disk Types on the Controller Prestats- sysconfig -r Pro Tip Common disk types today: SAS, BSAS, MSATA

  14. RAID Groups Poststats – statit Pro Tip Avoid unbalanced raid-groups in aggregates!

  15. 32-bit vs 64-bit Aggregates Prestats – aggr status -v Pro Tip • New features workbest (require) with 64-bits aggregates • Using one aggregate type makes the customer operations easier

  16. Aggregate Utilization Poststats - df –A -h Pro Tip • An aggregate which is 80% full, shouldbemonitored • Aggregates over +90% fullcouldimpact performance

  17. Aggregate Snapshot Copies Prestats - df –A –h, snap status -A & aggr status –v Pro Tip OnlySyncMirror and MetroClusteruseaggregate snapshots If not in use: • Remove schedule • Release space reservation NetApp Confidential – Limited Use

  18. The Simple Analysis Part 2 Volumes

  19. Volume Space Utilization Poststats - df & lun stat –v all (or vol status –v) Pro Tip Databases like Oracle initialize their data files or data couldbestatic so it couldbe fine that the volume is almostfull

  20. Deduplication Poststats- stats perfstat_sis Pro Tip Savings less than 6-8% are just using resourceswithout a real effect, unless data is static, turn it off and save resources!

  21. Deduplication Runtimes Poststats - sis status -l Pro Tip Deduplication is a low priority process but it still occupies system resources Work to understand run times to smooth system scheduling for better performance

  22. Misalignment Poststats - nfsstat –d & lun stat –v all Pro Tip Understand what is in these files/LUNs Logfiles are often ”misaligned” Verifythat virtual machines are aligned

  23. The Simple Analysis Part 3 System Performance

  24. What Are Domains In Data ONTAP? • ONTAP breaks work into groups of processes called domains • ONTAP schedules work across CPU cores as IT sees best • This can be seen in Sysstat –M • Detailed analysis of this is an advanced topic

  25. CPU Utilization Poststats - sysstatM.out Pro Tip: Average CPU utilization >70% depicts a verybusy controller CPU Utilization is a generally poorindicator of performance Look at AVG CPU – Single CPU (thread) utilization is very informative

  26. Writing Data to Disk - CP Type & Time Poststats – sysstat_1sec.out Pro Tip Deferred Back-to-back CP’s are performance killers (type #) • Data can’tget to disk fast enough Investigate (ignoring the CPU utilization): • Mis-alignment • Disk over commited • Solutions: • Move load to anothercontroller/aggregate • Adddisks/Flash Cache

  27. Aggregate Disk Utilization Poststats - statit Pro Tip Analyze performance impact based on drive utilization (by drive type) • SATA drives > 50% = busy • SAS drives > 60% = busy • Statitwill give cluesaboutwhere to move load to

  28. Active Volumes Perfsys Report Pro Tip Mapvolumes to aggregates (aggr status –v) Identifyworkloads to move

  29. FlashCache Perfsys Report Pro Tip Verifythat the system is benefiting from the use of FlashCache Use PCS and perfstat to verify a customersgains by use of FlashCache

  30. Latency in the Environment Poststats - stats perfstat_cifs/_nfs/_fcp Pro Tip High latency = performance impact Latencyrequirementsvary by applicaton Analyze the workload and • Add Disk • Add FlashCache • Upgrade the Controllers

  31. Review of Findings • We reviewed • High disk I/O’s • Busy volumes • Disk configuration issues • Average CPU utilization • Potential Flash Cache benefits • Mis-alignments

  32. Recommendations • Resolve mis-alignments • Consider moving busy volumes • Add drives and reallocate to even out raid groups • Add Flash Cache • Upgrade Controllers • Add more Controllers within Clustered Data ONTAP

  33. Now YOU Can Better Understand System Performance Don’t be afraid – performance is no longer such a mystery! Most importantly, monitor disk utilization! Have FUN!

  34. Important Resources • The Community site • http://communities.netapp.com • ONTAP documentation (particularly ONTAP Command ref) • http://support.netapp.com • Latx – your analysis tool • http://latx.netapp.com

  35. Complimentary Sessions • TR-1-123 Sizing, Designing, and Presenting a NetApp Solution • TR-2-717 Using NetApp Tech Tools to Create Winning Proposals and Tech Refreshes • TR-2-315 A Field Guide to Sizing - Part 1 • TR-3-317 A Field Guide to Sizing – Part 2
