Module Overview • Overview of Active Directory Domain Services Replication • Overview of AD DS Sites and Replication • Configuring and Monitoring AD DS Replication
Lesson 1: Overview of Active Directory Domain Services Replication • How Active Directory Replication Works • How AD DS Replication Works Within a Site • Resolving Replication Conflicts • Optimizing Replication • What Are Directory Partitions? • What Is Replication Topology? • How Directory Partitions and the Global Catalog Are Replicated • How the Replication Topology Is Generated • Demonstration: Creating and Configuring Connection Objects
How Active Directory Replication Works Active Directory replication: • Uses a multimaster model • Uses pull replication • Uses store and forward replication • Uses loose consistency with convergence Changes that initiate replication include: • Addition of an object to Active Directory • Modification of an object’s attribute values • Deletion of an object from the directory
How AD DS Replication Works Within a Site In a single site: • Domain controllers notify replication partners when updates are applied • For normal updates, the change notification happens 15 seconds after the change is applied • Notifications for security related changes are sent immediately • Replication updates are not compressed
Resolving Replication Conflicts In a multimaster replication model, replication conflicts can arise when: • The same attribute is changed on two domain controllers simultaneously • An object is moved or added to a deleted container on another domain controller • Two objects with the same relative distinguished name are added to the same container on two different domain controllers To resolve replication conflicts, AD DS uses: • Server GUID • Version number • Time stamp
Optimizing Replication • In a multimaster replication model, AD DS updates can be replicated using multiple paths • AD DS uses update sequence numbers, high watermarks, and up-to-dateness vectors to ensure that updates are replicated to a specific domain controller only once
What Are Directory Partitions? Schema Configuration <Domain> <Application> Contains: Definitions and rules for creating and manipulating objects and attributes Forest Information about the Active Directory structure Information about domain-specific objects Domain Configurablereplication Information about applications Active Directory Database
What Is Replication Topology? A1 A1 B1 A2 A2 B2 A3 A3 A4 A4 B3 Domain controllers from various domains Domain A Topology Domain B Topology Domain controllers in the same domain Domain A Topology
How Directory Partitions and the Global Catalog Are Replicated Global catalogserver A1 B1 A2 B2 Global catalogserver A3 A4 B3 Global catalogserver Domain controllers from various domains Domain A topology Domain B topology Schema and configurationtopology Global catalog replication
How the Replication Topology Is Generated Active Directory uses the KCC to establish a replication path between domain controllers • Each domain controller has two replication partners for each Active Directory partition • The KCC creates two one-way connection objects between replication partners to ensure that no two domain controllers are ever more than three network hops away • When a new domain controller is added to a site, the KCC recalculates connection objects • Connection objects can replicate one or more partitions
Demonstration: Creating and Configuring Connection Objects In this demonstration, you will see how to create connection objects and configure existing connection objects
Lesson 2: Overview of AD DS Sites and Replication • What Are AD DS Sites and Site Links? • Discussion: Why Implement Additional Sites? • Demonstration: Configuring AD DS Sites • How Replication Works Between Sites • Comparing Replication Within Sites and Between Sites • Demonstration: Configuring AD DS Site Links • What Is the Inter-site Topology Generator? • How Unidirectional Replication Works
What Are AD DS Sites and Site Links? Sites: A1 • Identify network locations with fast reliable network connections • Are associated with subnet objects in Active Directory A2 IP Subnet IP Subnet Site Site Link B1 B2 IP Subnet B3 IP Subnet Site
Discussion: Why Implement Additional Sites? • Why would an organization choose to implement additional sites? • What are the benefits and disadvantages of creating additional sites?
Demonstration: Configuring AD DS Sites In this demonstration, you will see how to: • Create sites and subnets • Move domain controllers to other sites
How Replication Works Between Sites You can configure: A1 • Replication paths between sites • Replication schedulesand frequency • Replication protocols A2 Site Site Link B1 B2 B3 Site
Comparing Replication Within Sites and Between Sites A1 IP Subnet A2 Replication IP Subnet A1 IP Subnet A2 Replication IP Subnet B1 IP Subnet Replication B2 Replication IP Subnet
Demonstration: Configuring AD DS Site Links In this demonstration, you will see how to: • Configure the default site link • Create additional site links • Add sites to the site links
What Is the Inter-site Topology Generator? B2 A2 B1 A1 Inter-site topology generator Bridgehead server IP Subnet • The inter-site topology generator defines the replication between sites on a network Replication IP Subnet IP Subnet Replication Inter-site topologygenerator Replication IP Subnet Bridgehead server
How Unidirectional Replication Works • Unidirectional replication ensures that changes to a read-only domain controller are never replicated to any other domain controller
Lesson 3: Configuring and Monitoring AD DS Replication • What Is a Bridgehead Server? • Demonstration: Configuring Bridgehead Servers • Demonstration: Configuring Replication Availability and Scheduling • What Is Site Link Bridging? • Demonstration: Modifying Site Link Bridges • What Is Universal Group Membership Caching? • Demonstration: Configuring Universal Group Membership Caching • Demonstration: Tools for Monitoring and Managing Replication
What Is a Bridgehead Server? A bridgehead server: Bridgehead Server IP Subnet • Sends and receives replicated data • Is designated for each partition in the site A1 IP Subnet Replication IP Subnet IP Subnet B1 Bridgehead Server
Demonstration: Configuring Bridgehead Servers In this demonstration, you will see how to configure bridgehead servers
Demonstration: Configuring Replication Availability and Frequency In this demonstration, you will see how to configure the site link object to manage replication between sites
What Is Site Link Bridging? IPSubnet IPSubnet Site B Site Link AB Site Link BC Site Link Bridge A1 B2 B1 B3 C2 C1 A2 Site A Site C IPSubnet IPSubnet IPSubnet IPSubnet
Demonstration: Modifying Site Link Bridges In this demonstration, you will see how to: • Disable site link bridging • Create a new site link bridge
What Is Universal Group Membership Caching? A1 A2 B1 Global Catalog Server Bridgehead server • Enables domain controllers in a site with no global catalog servers to cache universal group membership IP Subnet IP Subnet IP Subnet IP Subnet Bridgehead server
Demonstration: Configuring Universal Group Membership Caching In this demonstration, you will see how to: • Configure universal group membership caching for a site • Configure the source for caching
Demonstration: Tools for Monitoring and Managing Replication In this demonstration you will see how to: • Identify the domain controller holding the ISTG role • Force the KCC to run, and how to force replication • Use Repadmin, NLTest, and DCDiag
Lab: Configuring Active Directory Sites and Replication • Exercise 1: Configuring AD DS Sites and Subnets • Exercise 2: Configuring AD DS Replication • Exercise 3: Monitoring AD DS Replication Logon information Estimated time: 60 minutes
Lab Review • What additional changes would you need to make to the AD DS site configuration if you needed to ensure that all replication traffic in the New-York site passed through NYC-DC2? • What additional changes would you need to make if you implemented another WAN connection between Tokyo and London, and wanted to use that WAN connection for AD DS replication instead of routing all replication changes through NewYork-Site? • Why did you force the domain controllers in the lab to update their IP addresses in DNS?
Module Review and Takeaways • Review questions • Considerations for configuring AD DS sites and replication • Tools
