  1. Data Warehouse Components

  2. Overview of the Components • Source Data Component • Production data • Internal data • Archive data • External data • Data staging component • Extraction • Transformation • Cleaning • standardization • Loading • Data storage component • Information delivery component • Metadata component • Management and control component

  3. Architectural Framework

  4. Data Acquisition You are the data analyst on the project team building a DW for an insurance company. List the possible data sources from which you will bring data into DW • Production data: data from various operational systems • External data: for finding trends and comparisons against other organizations. • Internal data: private confidential data important to an organization • Archived data: for getting some historical information

  5. Architectural Framework

  6. Data Staging • Performs ETL • Extraction • Select data sources, determine filters • Automatic replicate • Create intermediary files • Transformation • Clean, merge, de-duplicate data • Covert data types • Calculate derived data • Resolve synonyms and homonyms • Loading • Initial loading • Incremental loading

  7. Why is a separate data staging area required? • Data is across various operational databases • It should be subject-oriented data • Data staging is mandatory

  8. Architectural Framework

  9. Characteristics of data storage area • Separate repository • Data content • Read only • Integrated • High volumes • Grouped by business subjects • Metadata driven • Data from DW is aggregated in MDDBs

  10. Architectural Framework

  11. Information delivery component • Depends on the user • Novice user: prefabricated reports, preset queries • Casual user: once in a while information • business analyst: complex analysis • Power users: picks up interesting data

  12. Information delivery component

  13. Architectural Framework

  14. Metadata component • Data about data in the datawarehouse • Metadata can be of 3 types • Operational metadata: contains information about operational data sources • Extraction and transformation metadata: Details pertaining to extraction frequencies, extraction methods, business rules for data extraction • End-user metadata: navigational map of DW

  15. Why is metadata especially important in a data warehouse? • It acts as the glue that connects all parts of the data warehouse. • It provides information about the contents and structures to the developers. • It opens the door to the end-users and makes the contents recognizable in their own terms.

  16. Management and Control • Sits on top of all components • Coordinates the services and activities within the DW • Controls the data transformation and transfer in DW storage

  17. Summing up • Data warehouse building blocks or components are: source data, data staging, data storage, information delivery, metadata, and management and control. • In a data warehouse, metadata is especially significant because it acts as the glue holding all the components together and serves as a roadmap for the end-users.

  18. Doubts????????????????

  19. Trends in DW

  20. Case study 1 • As a senior analyst on DW project of a large retail chain, you are responsible for improving data visualization of the output results. Make a list of recommendations

  21. Parallel processing • Performance of DW may be improved using parallel processing with appropriate hardware and software options. • Parallel processing options • Symmetric multiprocessing • Massively parallel processing • clusters

  22. DW with ERP packages

  23. Web Enabled configuration
