P12311 MSD ProjectRF Anechoic Chamber Automated Antenna Radiation and Gain Measurement System with User Interface Sheldon Palmer Danielle Walters 2/22/2012
Measurement System Control Box Spectrum Analyzer Cable Pass Through Frequency Generator Frequency Generator: Agilent MXG Analog Signal Generator 100kHz-6GHz (N5181A) Spectrum Analyzer: Hewlett Packard Spectrum Analyzer 9kHz-50GHz (8565E) Transmit Antenna Receive Antenna
Motor Arm Allows antenna to be shifted up and down to ensure correct height and side to side to ensure it is centered Allows antenna to be shifted forward and back to ensure correct distance
Motor Arm Arm with mount Turntable Position Marker Acrylic sheets sandwiching turntable Acrylic Sheet Turntable Motor Acrylic Sheet Motor Power Cord
Control System Motor Cord Power Switch Parallel Port Connection Power Adapter DAC USB
Friis Transmission Equation • PTest= Power of Test Antenna • PStandard= Power of Standard Gain Antenna • GTest= Received Gain of Test Antenna • GStandard= Received Gain of Standard Gain Antenna
Free Space Microstrip Measurement Results Raw Data Normalized Data HPBW= 113° - 58° = 55°
Microstrip Chamber Measurement Results Raw Data Normalized Data HPBW= 119° - 58° = 61°
Reflector Chamber Measurement Results Raw Data Normalized Data HPBW= 98° - 82° = 16°
Future Work • Continue Testing System • Ensure LabVIEW Positioning is exact • Continue Improvement to GUI
