1. Team _ - Jan 18 2005

2. Project Goal • The Goal • The goal of our project is to create a working and user friendly simulation of the AODVS system • The secondary goal is to improve upon the existing system by adding timeouts on SID packets (intrusion detection)

3. Design Revisions • Through discussions both with the professor and amongst the group the design has changed in several ways • Nodes will be told when to move, but not where to move, by the Monitor class • Our thoughts on the visualization of network traffic have changed more than once, and may change again

4. Design Revisions (cont) • The Monitor class has had more things moved and added to it for coordination between the various layers of our program • External lookup tables for node and packet types have been added • “Big Picture” remains the same as in original designs

5. Risk Analysis • Timing • Movement handled by coordinating through the Monitor and not leaving it up to the nodes • Cryptography • Pushed off until later, possibility of not getting to it • AODV algorithm not fully implemented or implemented incorrectly • Used an Internet Draft from Univ. of Calif.

6. Schedule • This week • Monitor will be done • 50% of packets implemented and working • Visualization of these packets • Week 7 • Other 50% of packets implemented • Tokens working to tell good nodes from bad • Authority class working to start up system

7. Schedule • Week 8 • Bad nodes implemented • Detection system in place to detect bad routing and dropping packets • Week 9 • Final testing and debugging • Trials to see if our improvement has worked • Week 10 • Evaluation and report

9. Demo!
