Presentation Transcript

  1. Practice Problem The periodic waveform shown is applied to a 100Ω resistor. What value of αyields 50W average power to the resistor? α is the “duty cycle”

  2. i i in d + – V V i i L C in out C L – + I out Practice Problem

  3. i i in d + ! – V V i i L C in out C L – + I out Practice Problem Hint #1: This is a buck-boost converter Hint #2: Pin = Pout Pin = DVin IL = VinIin Pout = Vout Iout Hint #3: IC = 0 Iout = (1-D)IL iin IL Vin DT t Since the input voltage is constant only the dc component of iin contributes to Pin

  4. Practice Problem
