  1. Characterizing Flows in Large Wireless Data Networks Xiaoqiao (George) Meng, UCLA H.Y. Starsky Wong, UCLA Yuan Yuan, UMD Songwu Lu, UCLA

  2. Objectives of Study • To quantitatively characterize data flows in wireless networks • To help understand application behavior in wireless networks Internet Access Points

  3. Study flow traffic at Access Point Flow Traffic in WLAN • What is a flow? A TCP connection, i.e., a stream of packets Internet

  4. Outline • Motivations • Related work • Three issues • Methodology and datasets • Flow modeling results • Applying models • Summary, future work

  5. Motivations • Realistic flow models to evaluate protocol design • Flow captures user demand and application behavior • Compared to packet-level study, hide effect of MAC and channel errors

  6. Related Work • User mobility & network usage • Tang et. al., Mobicom’99 • Tang et. al., Mobicom’00 • Kotz et. al., Mobicom’02 • Balachandran et. al., Sigmetrics’02 • Balazinska et. al., Mobisys’03 • Modeling wireless networks • Konrad et. al., WINET’03 • Yoon et. al., Mobicom’03 • Jardosh et. al., Mobicom’03

  7. Issue #1: Non-stationarity • Flow arrival pattern changes over time • Smaller number of users • Diurnal cycle of human activities

  8. Internet Dormitory Office Issue #2: Location Dependence • The behavior of flow traffic is location specific

  9. Issue #3: Mobility • A flow may traverse different APs when user is roaming Internet Roaming flow AP2 Static flow AP1 AP3

  10. Methodology • Synthesizing data traces to obtain both temporal and spatial information for flows • Tcpdump: temporal info • Syslog: associated AP info • Statistical methods • Match real data with statistical distributions • quantile-quantile plot • Cross-validation whenever possible • Check model validity using multiple datasets

  11. Datasets • 4 settings: campus, conference, corporate, department

  12. Modeling Flows • How to model static flows at an AP? • Is there spatial correlation for static flows across APs? • How to model roaming flows? Technique, results, interpretation and causes

  13. Modeling Static Flow • Characterized by inter-arrival time and flow data size • Model inter-arrival time • Power spectral analysis • Match against statistical distributions • Regression • Weibull regression model characterizes inter-arrival times at both fine and coarse time granularities • Coexistence of long and short inter-arrival times, effect of time-of-day

  14. Modeling Static Flow – cont. • Model flow data size • Match against statistical distributions • Lognormal distribution gives the best match • There exist flows with large chunk of data • Consistent with file size distribution in Internet (Downey et. al., Sigmetrics’01)

  15. Spatial Correlation Flow inter-arrival time across APs • Use q-q plot to measure similarity • High-degree similarity within same subnet, low-degree similarity across subnets • Users in a geographic proximity more likely exhibit similar usage behavior

  16. Spatial Correlation Flow data size across APs • Use q-q plot to measure similarity • High-degree similarity among all APs • Internet file size distribution does not depend on AP

  17. Cross-validation Using UCSD01 dataset • Flow inter-arrival time: Weibull regression model matches among 78% time intervals • Flow data size: Lognormal distribution gives the best match

  18. Roaming Flows • 0.13% flows are roaming while 60% hosts have mobility • Only 4.6% users generate traffic when they are physically moving • Model roaming flows • Hand-off freq • Residing time

  19. Modeling Roaming Flows • Hand-off freq: match Geometry distribution Hand-off decision process is memory-less • Residing time: match Weibull distribution Both short and long residing times exist

  20. Applying Models in TCP • Compare TCP throughput between • Static scenario used by literature • Realistic scenario: dynamic flow arrivals by using derived models • 40% difference

  21. Applying Models in Scheduling • Flow-level performance of Proportional Fair Scheduling (Borst, Infocom’03) between • Assumed scenario: Poisson arrival and constant flow data size • Realistic scenario: using derived models • Difference of per-flow delay is up to 99%

  22. Summary • Flow-level characterization: understand and quantitatively model wireless flows • Main results • Simple models for both static and roaming flows • Flows in same subnet exhibit spatial similarity • Applying our models yields large performance gap

  23. Future Work • Evolution of models with new traces • Check model validity using latest dataset • Composite packet-level modeling • Compose flow model, packet behavior within a flow and channel model

  24. Thank you ! Flow models available at http://www.cs.ucla.edu/wing

  25. Lessons Learned • Systematic data collection • Not ad hoc data collection • Need to model both temporal and spatial dynamics • Synthesizing traces is useful • Signal processing techniques are useful
