  1. Sketch of test apparatus for FACET experiment wit metallic THz structure V.A. Dolgashev 22June 2012

  2. Kraken chamber with metallic structure, isometric view structure beam waveguide horn connected to 100 GHz detector

  3. Kraken chamber with metallic structure, top view beam 100 GHz RF alignment camera

  4. Kraken chamber with metallic structure, alignment camera view

  5. Kraken chamber with metallic structure, zoom of alignment camera view 0.9 mm 20 mm output rf horn 30 mm phosphor screen for beam alignment mark for structure axis alignment
