  1. Testbed

  2. Why a testbed? • Verify if the OS upgrade impacts the functionality/services. • Compatibility between different router vendors. • Test of new services and features.

  3. Testbed • The testbed will be available for the NRENs • Testbed consists of several Cisco and Juniper routers distributed on GÉANT. • three M-20s, two 7000s and one GSR • interconnection between test routers via the MPLS/CCC functionality (carrying L2 frames across GÉANT).

  4. Testbed • the tests routers are connected to the GÉANT routers via STM-1. • Additional equipment: • Linux based PCs • Traffic generators (SmartBits) • Ideally, should have a routes generator. • Comments?

  5. Testbed example

  6. DSCP transparency

  7. DSCP transparency • Currently, any BE packet retag with DSCP 0 • IETF states that the domains should be DSCP transparents • prevents two end-users use a specific DSCP value to differentiate their packets • Avoid remarking the packets which are not using a “GÉANT service tag”

  8. Marking on Juniper M-series • Marking only on an output-queue • Four output-queues per port (in general) • For each output-queue, two loss-priorities (doesn’t mean they are defined or different ) • For one pair <output-queue, loss-priority>, one tagging value is applied to all the packets in this output-queue and with this loss-priority (or no re-tagging)

  9. How to do it? • Current queue utilisation • Remove the rewrite-rule for <Q0, low loss-priority>

  10. How to do it? • Easy => no: • the marking to BE on GÉANT is used to change the unauthorised Premium IP and DWS to BE. • need to find an unused <queue, loss-priority> for remarking the packets. Unused queue: • <queue2, loss-priority high> • <Premium queue, high> (not good bcs of Premium protection) • <queue3, high> (difficult to move network control traffic - internal to JUNOS)

  11. Solution

  12. Implications • Once LBE service deployed (queue 2) • the unauthorised Premium IP and DWS will be receive the same treatment as LBE on the first GÉANT router • then, on the next routers, they will be treated as BE • > to be kept in mind • Acceptable solution? • if congestion, dangerous of Premium if bad configuration • ECN bits kept unchanged.

  13. Less than Best Effort test results

  14. Less than Best Effort - definition • Traffic class able to use the un-utilise by other higher traffic classes bandwidth in the network. • if competition for resources, LBE packets are discarded before any other. • Equivalent to the Internet2 scavenger service. • Use the DSCP 001000 (decimal 8) - same as Internet2.

  15. LBE • In case of congestion, no guaranty • high packet loss • no bandwidth guaranty • Service oriented for • huge data transfer volume • traffic without time constraints • What the hell would you use this service for???

  16. LBE utilisation example • FTP mirroring • GRID data transfer • experimental data transfer • network backup

  17. Implementation • A small percentage of capacity is allocated to this service (0% or 1%)

  18. LBE Test on GÉANT • August 2002 in collaboration with the DataGrid project. • Congestion of two STM-16 interfaces with LBE traffic • fr1.fr interface to es1.es and • es1.es interface to it1.it • Congestion created with two SmartBits SMB-600 from Spirent (STM-16 interfaces).

  19. LBE Test on GÉANT • Test done with three classes of services: Premium, BE and LBE. • One way delay, jitter, throughput, packet losses.

  20. Test topology STM-16

  21. Test - next steps • End-to-end LBE tests • FTP mirroring tests between • Uninet and • the University of Southampton

  22. Delays - load variation • Delays are pretty stable for BE and LBE for load between 5 and 45% of an STM-16.

  23. Delay - congestion • Increase of the LBE delay 1.5ms (1500us). • Slight increase of BE delay when congestion - 400us

  24. Packet loss • No BE packet was lost at any time during the tests (SMB or drop on the routers). • BE load up to 60% of STM-16 load (int cong) • LBE losses increase with the load.

  25. Throughput • The Premium IP, BE throughput are preserved. • As long as their capacity is not higher than the interface capacity.

  26. Re-ordering • The smaller the packets constituting the flow, the higher the re-ordering . • The higher the load in a class, the higher the re-ordering. • Re-ordering higher in case of congestion.

  27. Conclusions • Large amount of LBE traffic don’t have any impact on the BE and the Premium IP. • No packet losses • one-way delay increase almost negligible • IPDV not particularly affected • LBE delay increase of 1ms, packet losses

  28. Useful tool • Feature of the NANOG traceroute to discover the DSCP changes along the path.
