Understanding the EVPN VPWS Architecture for Ethernet Services

axel-keller avatar
axel-keller
7 diapositives · 234 Views · Nov 12, 2014

This document outlines the operation of Ethernet Virtual Private Network (EVPN) Virtual Private Wire Service (VPWS) and its ability to efficiently forward traffic between customer attachment circuits (ACs). It discusses various configurations, including single-home, single-active, and all-active scenarios, using Ethernet AD routes and MPLS labels for traffic forwarding. Key components, such as the Route Distinguisher (RD) and Ethernet Tag ID, are explained. The updates from version 02 to 04 are highlighted, emphasizing new inclusions and clarifications for effective implementation.

#understanding the evpn vpws architecture for ethernet services #understanding the evpn vpws architecture for ethernet services ppt #powerpoint #presentation
Understanding the EVPN VPWS Architecture for Ethernet Services - slide 1
01 / 7Understanding the EVPN VPWS Architecture for Ethernet Services
1 / 17

Télécharger la présentation

Understanding the EVPN VPWS Architecture for Ethernet Services
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. draft-boutros-l2vpn-evpn-vpws-04.txtSami Boutros Ali SajassiSamer SalamPatrice BrissetteJohn DrakeJeff TantsuraDirk Steinberg Thomas BeckhausIETF 90, July 2014Toronto, Canada

  2. How it works? • The EVPN ability to forward customer traffic to/from a given customer Attachment Circuit (aka Ethernet AD route) is ideal in providing P2P services (aka VPWS services). • EVPL/EPL can be considered as a VPWS with only two ACs. Traffic forwarding capability of E-VPN between a pair of Ethernet AD routes is used. • MPLS label associated with the destination Ether AD route will be used in forwarding user traffic to the destination AC.

  3. EVPN VPWS Operation – single-home ESI – 10 bytes ESI Set to 0 for single home Segment as per EVPN baseline 3 RD – RD unique per adv. PE per EVI Eth.Tag ID – 4-bytes VPWS service instance Identify EPL/EVPL. MPLS RT– RT associated with a given EVI 2 MPLS Label – (downstream assigned) used by remote PEs to reach EVPL/EPL VPWS Service Config: EVI = 100 Local Eth tag ID = AC2 Remote Eth tag ID = AC1 PE1 PE2 CE1 CE2 ES1– Since CE1 is single homed to PE1, ES1 = 0 ES1 1 ES2 ES2– Since CE2 is single homed to PE2, ES2 = 0 VPWS Service Config: EVI = 100 Local Eth Tag ID = AC1 Remote Eth Tag ID = AC2 5 6 4

  4. EVPN VPWS Operation – single-active RD – RD unique per adv. PE per EVI ESI – 10 bytes ESI as per EVPN baseline 3 Eth.Tag ID – 4-bytes VPWS service instance Identify EPL/EVPL. RT– RT associated with a given EVI MPLS MPLS Label – (downstream assigned) used by remote PEs to reach EVPL/EPL VPWS Service Config: EVI = 100 Local Eth. Tag ID = AC2 Remote Eth. Tag ID = AC1 PE1 VPWS Service Config: EVI = 100 Local Eth. Tag ID = AC1 Remote Eth. Tag ID = AC2 ES1 PE3 CE1 CE2 2 ES2 ES2– Since CE2 is single homed to PE2, ES2 = 0 1 ES1– Since CE1 is multi-homed to PE1, ES1 is a non 0 value VPWS Service Config: EVI = 100 Local Eth. Tag ID = AC1 Remote Eth. Tag ID = AC2 ES1 5 6 PE2 4

  5. EVPN VPWS Operation – all-active RD – RD unique per adv. PE per EVI ESI – 10 bytes ESI as per EVPN baseline 3 Eth.Tag ID – 4-bytes VPWS service instance Identify EPL/EVPL. RT– RT associated with a given EVI MPLS MPLS Label – (downstream assigned) used by remote PEs to reach EVPL/EPL VPWS Service Config: EVI = 100 Local Eth. Tag ID = AC2 Remote Eth. Tag ID = AC1 PE1 VPWS Service Config: EVI = 100 Local Eth. Tag ID = AC1 Remote Eth. Tag ID = AC2 ES1 PE3 CE1 CE2 2 ES2 ES2– Since CE2 is single homed to PE2, ES2 = 0 1 ES1– Since CE1 is multi-homed to PE1, ES1 is a non 0 value VPWS Service Config: EVI = 100 Local Eth. Tag ID = AC1 Remote Eth. Tag ID = AC2 ES1 5 6 PE2 4

  6. Changes from 02 04 • Added requirements sub-section. • Added Patrice, Thomas and Dirk as authors. • Clarified ESI value setting aligning with base EVPN. • ESI value will be set to 0 for single home. • ESI value will be non 0 for single active or all active. • Clarified tag-id value setting in the Ethernet AD route. • Tag-id value will be set to a non 0 unique value per EVI scope for both EPL or EVPL services. • VPWS with multiple site outside the scope of the document • Acknowledged Wen Lin and Jose Liste contributions.

  7. Next steps • Authors believe that document is ready for WG adoption. Thank you
