  1. .NET Reversing The Framework, the Myth, the Legend (waffle edition)

  2. What I do have are a very particular set of skills • I do appsec for financial companies • Not a consultant • Not here on behalf of any employer • Wrote my first app in Qbasic • Microsoft 4 lyfewutwut • Curator of securityreactions.tumblr.com • Staring at the sun made me crazy

  3. Why .NET? Current state of Java security

  4. Pool’s closed Source: http://www.veracode.com/blog/2013/04/the-history-of-programming-languages-infographic/

  5. .NET – Common Language Infrastructure Common Language Infrastructure Thanks, Wikipedia

  6. Common Intermediate Language privatevoidbutton1_Click(objectsender, EventArgs e)     {            MessageBox.Show("I am in a hell of my own creation");        } .methodprivatehidebysiginstancevoidbutton1_Click (objectsender,class[mscorlib]System.EventArgs e )cilmanaged  {// Method begins at RVA 0x221f// Code size 13 (0xd).maxstack8        IL_0000:nop IL_0001:ldstr"I am in a hell of my own creation"IL_0006:callvaluetype[System.Windows.Forms]System.Windows.Forms.DialogResult [System.Windows.Forms]System.Windows.Forms.MessageBox::Show(string)        IL_000b: popIL_000c:ret }// end of method Form1::button1_Click

  7. .NET PE File Format

  8. PE Format - Metadata Streams • #~ (metadata stream) • Predefined content and structure • Contains types, methods, fields, properties and events  • #Strings • Namespace, type, and member names • #US (user string heap) • All strings embedded in source • #GUID • Unique identifier • #Blob (binary data heap) • Method signatures, generic instantiations

  9. The #~ Stream: Metadata Tables • 0×2: TypeDef • 0×4: FieldDef • 0×6: MethodDef • 0×14: EventDef • 0×17: PropertyDef • Types, fields, methods, events and properties • 0×1: TypeRef • Referenced types defined in other assemblies • 0xa: MemberRef • Referenced members of types defined in other assemblies. • 0×9: InterfaceImpl • Defined types and the interfaces that type implements • 0xc: CustomAttribute • Info on attributes applied to elements in the assembly • 0×18: MethodSemantics • Links properties and events with the methods that comprise the get/set or add/remove methods of the property or method. • 0x1b: TypeSpec • 0x2b: MethodSpec • Instantiations of generic types and methods

  10. Browsing a .NET PE: CFF Explorer #~: MethodDef tables

  11. #Strings Tables

  12. I Love Belgium This Much

  13. I heard you like mudkipsobfuscators

  14. …I’ll just leave this here :( :|

  15. Overcoming Obfuscation • Symbol Renaming • Not possible if the original symbols are not in the assembly • Can convert unprintable names to something resembling English • Decryption • Removal of proxy code / junk classes • Removal of tamper detection • Move methods back to their original classes • “Sometimes, dead is better.”

  16. Proof of Concept: Reversing Reflector

  17. Goal: Add new functionality to existing binary • To Do: • Remove strong name singing to permit modification • Identify where toolbar is created and icons defined • Create new icon • Locate event handler for icon click event • Create new event handler • Inject DLL containing our new functionality • Have our new event handler reference this code

  18. Strong Name Signing

  19. Locating toolbar

  20. Adding new toolbar icon: Injecting IL

  21. Toolbar, continued: new IL IL_01ae:ldarg.0IL_01af:ldarg.1IL_01b0:callclass[System.Drawing]System.Drawing.Image ns36.Class476::get_Nyan()IL_01b5:ldstr"Nyan!"IL_01ba:ldc.i4.0IL_01bb:ldstr"Application.Nyan"IL_01c0:callinstancevoidns30.Class269::method_29(classReflector.ICommandBar,class[System.Drawing]System.Drawing.Image,string,valuetype [System.Windows.Forms]System.Windows.Forms.Keys,string)IL_01c5:ldarg.1IL_01c6:callvirtinstanceclassReflector.ICommandBarItemCollectionReflector.ICommandBar::get_Items()    IL_01cb:callvirtinstanceclassReflector.ICommandBarSeparatorReflector.ICommandBarItemCollection::AddSeparator()    IL_01d0:pop

  22. Toolbar continued: Modifying inline resource

  23. Locating event handler

  24. Event handler, continued public voidExecute(stringcommandName) { stringkey = commandName; if (key != null) { intnum; if (Class722.dictionary_4 == null) { Dictionary<string, int> dictionary1 = new Dictionary<string, int>(0x10); dictionary1.Add("Application.OpenFile", 0); dictionary1.Add("Application.OpenCache", 1); dictionary1.Add("Application.OpenList", 2); dictionary1.Add("Application.CloseFile", 3); … Class722.dictionary_4= dictionary1; } if (Class722.dictionary_4.TryGetValue(key, out num)) { switch (num) { case 0: this.method_45(); break; case 1: this.method_46(); break; case 2: this.method_47(); break; … }

  25. Adding IL to Execute()     IL_00c1: ldc.i4.s 13    IL_00c3: call instancevoidclass [mscorlib]System.Collections.Generic.Dictionary`2<string, int32>::Add(!0, !1)    IL_00c8: dup    IL_00c9: ldstr "Application.Deactivate"    IL_00ce: ldc.i4.s 14    IL_00d0: call instancevoidclass [mscorlib]System.Collections.Generic.Dictionary`2<string, int32>::Add(!0, !1)    IL_00d5: dup    IL_00d6: ldstr"Application.Nyan"    IL_00db: ldc.i4.s 15    IL_00dd: call instancevoidclass [mscorlib]System.Collections.Generic.Dictionary`2<string, int32>::Add(!0, !1) …     IL_01b8: ldarg.0    IL_01b9: call instancevoid ns30.Class269::method_65()    IL_01be: leave.s IL_01c8    IL_01c0: ldarg.0    IL_01c1: call instancevoid ns30.Class269::nyan()    IL_01c6: leave.s IL_01c8

  26. Creating ns30.Class269::nyan()

  27. ns30.Class269::nyan() CIL .methodprivatehidebysiginstancevoidnyan () cilmanaged{.maxstack 8    IL_0000: newobjinstancevoid [derp]derp.hurr::.ctor()    IL_0005: callvirtinstancevoid [derp]derp.hurr::showForm()    IL_000a: ret privatevoidnyan(){newhurr().showForm();} Where are these classes implemented?

  28. Adding new DLL to Reflector

  29. …aaaaaand we’re done Let’s launch it.

  30. References and Resources • Anatomy of a .NET Assembly • https://www.simple-talk.com/blogs/2011/03/16/anatomy-of-a-net-assembly-clr-metadata-1/ • CFF Explorer – PE Browser • http://www.ntcore.com/exsuite.php • ILSpyDecompiler • http://ilspy.net/ • RedGate(SmartAssembly, Reflector, Obfuscation Checker) • http://www.red-gate.com/products/dotnet-development/ • Reflexil – RedGate plugin for CIL injection • http://reflexil.net/ • CodeSearch – RedGate plugin, does what it says • http://reflectoraddins.codeplex.com/wikipage?title=CodeSearch • De4dot Deobfuscator • https://bitbucket.org/0xd4d/de4dot/

  31. Questions? • Twitter: @aloria • Email: george.sims@jukt-micronics.com • Blog: http://jukt-micronics.com Special thanks to: AP, CS, CV, BN, DDZ, EK, RL, SR, ZC, ZL and the fine folks at CompuServe for inventing GIF89a
