Basic Java Servlet/JSP Web Development

Basic Java Servlet/JSP Web Development. David Lucek Lucek Consulting www.lucek.com dave@lucek.com. Download the Sample Application. Download from www.lucek.com , select the downloads tab Includes the full source Unzip to c: drive or $HOME/lucek. What is a Servlet? .

Télécharger la présentation

Basic Java Servlet/JSP Web Development

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.


Presentation Transcript

  1. Basic Java Servlet/JSP Web Development David Lucek Lucek Consulting www.lucek.com dave@lucek.com @2003 Lucek Consulting

  2. Download the Sample Application • Download from www.lucek.com, select the downloads tab • Includes the full source • Unzip to c:\ drive or $HOME/lucek

  3. What is a Servlet? • Java Servlets/JSP are part of the Sun’s J2EE Enterprise Architecture • The web development part • Java Servlet • is a simple, consistent mechanism for extending the functionality of a web server • Are precompiled Java programs that are executed on the server side. • Require a Servlet container to run in • Latest Servlet Spec is 2.3

  4. What is a Java Server Page (JSP) • Java Server Pages (JSP) • A simplified, fast way to create dynamic web content • HTML or XML pages with embedded Java Code or Java Beans • Can be a mix of template data in HTML/XML with some dynamic content • A JSP is a complied to a Java Servlet automatically by the Servlet container, it is then cached • Latest JSP Spec is 1.2

  5. Why Use Servlets? • Work well in a Heterogeneous Environments • OS and platform neutral • Work with all major web servers (IIS, Apache,etc..) • Well defined Web Architecture framework • Standard built in services such as: • Standard Approach to Authentication using declarative security vice programmatic security • Database connection pooling • Complete support for sessions via cookies and/or URL re-writing • Has automatic fallback to URL re-writing

  6. Why Use Servlets Con’t? • Robust Object-Orientated API in Java language • Ever try to maintain a large ASP, Perl, or PHP site  • Clean separation of Controller/Logic from Presentation • Efficient, scales very well • There are good free Servlet/JSP containers and connectors • That run under both UNIX and win32

  7. J2EE Web Application Components • Java Servlets • Extend off of HttpServlet • JSP pages, normally for Presentation • Java Beans • Normally used as value objects, pass to data to JSPs • Tag Libraries – XML based JSP elements • Web Deployment Descriptor • /web-inf/web.xml

  8. Web Deployment Descriptor • /web-inf/web.xml • Part of the standard • Defines servlets used in the web application • Maps servlets to URLs • A servlet can map to many URLs • Defines resources available to the web app • Defines security constraints • Defines other stuff like • Welcome file list • Session timeout • Error page mapping

  9. J2EE Web Directory Structure 1 • Top Directory is normally the context Path • /tomcat/webapps/servletdemo • Normally, the URL would be http://localhost:8080/servletdemo • Contains JSP and other static content plus the web-inf directory • /web-inf directory • This is a protected directory, can not point browser to any file in this directory • /classes – unpacked web application classes, auto-magically added to CLASS_PATH • /lib – web application JAR files • /taglib – tag library descriptor files

  10. J2EE Web Directory Structure 2 • /web-inf/web.xml • /web-inf/* • Would normally put any static or JSP files here • Protects them from Direct Invocation • Always best to call a JSP through a servlet first

  11. JSP Constructs 1 • Used in JSP pages, pages that end *.jsp • Comment <%-- Comment --%> • Declaration <%! int x = 0; %> • Expression <%= expression %> • Outputs to the Response stream • Like a “printf” to the browser • Do NOT use semi-colon to terminate the line • Scriplets - contains Java Code • <% code fragments %>

  12. JSP Constructs 2 <% if (value.getName().length != 0) { %> <H2>The value is: <%= value.getName() %></H2> <% } else { %> <H2>Value is empty</H2> <% } %> • Implicit objects always available in the JSP Page • “request” – Browser’s Request Object • Use to get HTTP headers, length etc.. • “response” - HttpResponse Object

  13. JSP Constructs 3 • “session” – internal HttpSession Object • “pageContext” • “application” • “out”, same as <%= %> • “config” – servlet configuration • “page” • “exception” • JSP Directives • Are messages or instructions to the JSP container

  14. JSP Constructs 4 • Do not produce any output • “page” directive • <%@ page import=“com.lucek.*” %> • Commonly used for importing class paths • “include” directive • <%@ include file=“header.htm” %> • Good for including static content • “taglib” – lists the tag library descriptor location • Required when using tab libraries

  15. Java Beans as Used in Web Apps • Normally used for all data transfers and business components • Similar to how Java Beans are used in Swing and AWT • But do not need the full implementation • Must have no constructor or no-arg constructor • Must have setter and getter methods for each property value • JSP constructs/tags use Java Beans

  16. JSP Actions • JSP actions are special tags that affect the output stream and are normally used with Java beans • Most commonly used: • <jsp:useBean>, <jsp:getProperty>, <jsp:setProperty> • The code below will display the lastName property of the student bean on the output stream <jsp:useBean id="student" scope="request" class="com.lucek.dto.StudentValue" /> <jsp:getProperty name="student" property="lastName" />

  17. Servlet Container/Engine • Servlets/JSP require a Container • Apache Tomcat is the reference implementation of the Servlet/JSP Specs • It is open source, small, install quickly,and is FREE • Latest Version is 4.1.24 • Web Site: jakarta.apache.org/tomcat • It include a simple HTTP 1.1 server, good enough for development and small intranets.

  18. Tomcat Install • Requires a JDK, get 1.4.1 and install into c:\jdk or $HOME/jdk • Add JAVA_HOME to your environment and the “bin” directory to your PATH • Good practice to unpack into c:\tomcat or $HOME/tomcat • Add CATALINA_HOME to your environment and the “bin” directory to your PATH

  19. Tomcat Directory Structure • Everything is relative to $CATALINA_HOME • /bin – Startup/shutdown scripts • /conf • Server.xml – main configuration file • /common – common class and jar files used by Tomcat and web applications • Put JDBC drivers here • /server – class and jar files used by Tomcat internally • /shared – class and jar files for all web applications • /webapps – This is where you put your web application in a sub-directory or external context file.

  20. Starting Tomcat • /bin/startup.bat or startup.sh • Point Browers to http://localhost:8080, should see default page • All the Docs are there on the default page! • Check out the examples pages, good tutorials

  21. Other Development Tools 1 • Ant Build Tool • Standard Java Build tool • Basic on UNIX make, but much better • Site: http://ant.apache.org • Install in c:\ant or $HOME/ant • Java IDE • Try NetBeans, it is nice • Tomcat is built in, but is an older version • Includes full Servlet and JSP debugging • Site: www.netbeans.org

  22. Other Development Tools 2 • Junit • Standard Automated Unit Testing Tool • Site: http://junit.sourceforge.net • Jedit • Slick Programmer’s Editor • Written in Java • Site: jedit.org

  23. Simple Servlet Application 1 • See “servletdemo” code • Mount the servletdemo, servletdemo/java/src, and servletdemo/web in NetBeans Explorer Tab • For a Hello World Servlet look at: • Java/src/com/lucek/action/HelloWorld.java • To build and run • $ cd servletdemo • Setup the proper build variables in the build.properties file • $ ant all • $ ant deploy • Point your browsers at http://localhost:8080/servletdemo

  24. Simple Servlet Application 2 • Look at the web.xml file and how the same servlet can be mapped to many URLs • Look at SimpleBean.java which should how to pass a Java Bean to a JSP page • Look at the different ways a bean’s value can be obtained in the EditStudent.jsp

  25. Best Practices/Patterns • Always Separate out the logic from the presentation • Use servlets for the logic/controller and JSP’s for presentation • Ideally should never have Java Code in the JSP page • Have a clean separation between your data access and controller layers (DAO) • Always use DTO or value object • Use a Model-View-Controller Architecture • Do not write it, use Struts • Site: jakarta.apache.org/struts/ • Use Unit tests • Junit Automation via Ant build tasks

  26. What we have not talked about • All the specific Servlet APIs • Tag libraries • Sessions, cookies • JDBC service support from the container • Container based authentication • Lots of other stuff

  27. Next Presentation? • Create a data driven web site using MySql and Servlets/JSP • Setup Authentication Realm with declarative security • Setup JDBC connection pooling • Struts?
