Analyzing Lake Breeze Formation Thresholds on Lake Mendota: Insights and Findings

This study examines the conditions leading to lake breeze formation on Lake Mendota, focusing on temperature differential, wind speed, and CO2 levels. Utilizing data from the TUMBLE site alongside AOS building and airport metrics, we identify key thresholds. Of the 18 rain-free days observed, 11 experienced lake breezes, with the most pronounced examples on March 13 and 15. Our analysis reveals that a temperature difference exceeding 9°C and a wind-to-temperature difference ratio less than 5 are crucial indicators for lake breeze occurrences.

barrett-estes
Télécharger la présentation

Analyzing Lake Breeze Formation Thresholds on Lake Mendota: Insights and Findings

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Finding Thresholds For Lake Breeze Formation on Lake Mendota Finding Stephen Ogden

  2. Methods Temperature Decrease CO2 Increase Water Vapor Increase Wind Speed Decrease Wind Shift TUMBLE site data compared to AOS building and airport data, lake temperatures from MODIS (images from 15 March at the TUMBLE site)

  3. Out of 18 rain-free days, 11 had lake breezes Two lake breezes appeared to reach the AOS building (13 and 15 March), with the 15 March one most obvious These two days had wind to temperature difference ratios of 0.46 and 0.11, respectively The air-sea temperature differences these days were 17.1 and 22.4C The wind to temperature difference ratio was only useful if wind perpendicular to shore was used, not geostrophic wind or total low-level wind Results Shaded area is 1630 to 1730 LST on 15 March at the AOS building

  4. Wind to temperature difference ratios of less than 5 generally had lake breezes (9 of 12 days) A ratio of greater than 5 generally had no lake breezes (2 of 5 days) One day was ignored because the wind was parallel to the coast (ratio of 0) Temperature differences of less than 8C had no lake breezes (0 of 5 days), while greater than 9.6C difference days tended to have lake breezes (12 of 13 days) A minimum temperature difference of 9C was a good dividing line in these days Results Wind/Temp. Difference Ratio Breeze No Breeze 0 1 2 3 4 5 6 7 8 Lake-Air Temp. Difference Breeze No Breeze 0 3 6 9 12 15 18 21 (11.2)

  5. Negative buoyancy is needed to form the stable layer that is the lake breeze air mass This buoyancy is achieved by having the lake be more than 9C cooler than the air above Stable layers (such as over the lake) tend to trap materials (such as CO2) due to a lack of mixing The lack of mixing also contributes to low wind speeds in the lower levels of the layer, similar to the nocturnal boundary layer Overlap With Class
