Elementary Microarchitecture Algebra John Matthews and John Launchbury Oregon Graduate Institute
Hawk Goals • Develop specifications that are clear and concise • Simulate the specifications, both concretely and symbolically • Formally verify specifications at the source-code level
Algebraic Verification • Developed a domain-specific algebra for microarchitectures • Proved equational laws that hold between microarchitecture components • We simplify pipelines using these laws while preserving functional (cycle-accurate) behavior • But clock cycle period may change!
Transactions • Group data and control information together • Transactions - containing destinations, sources, and operations - flow through the model • Decide control locally whenever possible R3 <- Add R1 R2 16 5 11
Example: The SuperSimple Pipeline Reg ALU Reference machine: • Each transaction is completed in one (long) clock cycle • Results are written back to register file on the next clock cycle
Example: The SuperSimple Pipeline Reg ALU Reference machine: R3 <- Add R1 R2 - - -
Example: The SuperSimple Pipeline Reg ALU Reference machine: R3 <- Add R1 R2 R3 <- Add R1 R2 - - - - 5 11
Example: The SuperSimple Pipeline Reg ALU Reference machine: R3 <- Add R1 R2 R3 <- Add R1 R2 R3 <- Add R1 R2 - - - - 5 11 16 5 11
Example: The SuperSimple Pipeline Reg ALU Reference machine: R3 <- Add R1 R2 R3 <- Add R1 R2 R3 <- Add R1 R2 - - - - 5 11 16 5 11 R3 <- Add R1 R2 16 5 11
Example: The SuperSimple Pipeline Reg ALU Reference machine: Reg ALU Pipelined machine:
Verifying SuperSimple • Pipelined machine should behave the same as reference machine, except the pipelined machine has one more cycle of latency Reg ALU Reg ALU
Verifying SuperSimple • We incrementally simplify the pipeline • Use local algebraic laws, each proved by induction over time Reg ALU Reg ALU
Circuit Duplication Law • We can always duplicate a circuit without changing its functional behavior F F F
Retiming the Pipeline • We first move delay circuits forward, using the circuit duplication law Reg ALU Reg ALU
Time-Invariance Laws • Delay circuits can be moved across time-invariant circuits without changing behavior ALU ALU
Retiming the Pipeline • Apply time-invariance laws to continue moving delay circuits Reg ALU Reg ALU
Removing Forwarding Logic • The register-bypass laws allow us to remove a bypass circuit on the output of a registerFile Reg Reg Reg Reg
Removing Forwarding Logic • Apply register-bypass law to remove bypass circuit Reg ALU Reg ALU
Removing Forwarding Logic • Apply register-bypass law to remove bypass circuit Reg ALU Reg ALU
Removing Forwarding Logic • Repositioning components Reg ALU Reg ALU
Simplification Complete! • Pipeline has been reduced to reference machine, but delayed by one clock cycle Reg ALU Reg ALU
Simplifying Stalling Pipelines • More complex pipelines often have to stall to resolve hazards or mis-speculation • A stalling pipeline won’t be cycle-accurate with respect to a reference machine • We still simplify as much as possible • Then use other verification techniques on simplified pipeline • Simplified pipeline should be easier to verify
The SomewhatSimple Pipeline • Resolves mem-alu data hazards by stalling • Resolves branch mispredictions by squashing misp ? hazard? ICache Reg ALU Mem Kill
misp ? hazard? ICache Reg ALU Mem Kill Original Pipeline
misp ? hazard? ICache Reg ALU Mem Kill Simplifying pipeline .....
misp ? hazard? ICache Reg ALU Mem Kill Various Retiming Laws Simplifying pipeline .....
misp ? hazard? ICache Reg ALU Mem Kill Various Retiming Laws Simplifying pipeline .....
