Optimizing Gear Ratio Distribution: An Optimal Design Problem

bgaither avatar
bgaither
25 diapositives · 317 Views · Dec 21, 2019

This project aims to optimize gear ratio distribution for a bike with 3 pedal sprockets and 7 wheel sprockets. The goal is to evenly distribute 21 possible gear ratios across the interval [1,4]. The process involves defining an objective function and identifying constraints related to sprocket sizes and desired gear ratios. By minimizing the objective function, the best bike configuration can be determined. The constraints include available sprocket sizes and specific gear ratio requirements set by marketing and purchasing. Techniques such as nested loops and simplifications can be applied to efficiently search for the optimal gear distribution. Building an environment to support a more sophisticated search method than brute force is recommended.

Optimizing Gear Ratio Distribution: An Optimal Design Problem - slide 1
01 / 25Optimizing Gear Ratio Distribution: An Optimal Design Problem
1 / 17

Télécharger la présentation

Optimizing Gear Ratio Distribution: An Optimal Design Problem
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. L32. Constrained Optimization Optimizing Gear Ratio Distribution

  2. An Optimal Design Problem

  3. Gear Ratio Distribution Assume 7 wheel sprockets Assume 3 pedal sprockets 21 = 7 x 3 possible gear ratios

  4. It’s a Matter of Teeth E.g., 13 teeth E.g., 48 teeth E.g., Gear ratio = 48/13 = 3.692

  5. Goal Choose 3 pedal sprockets and 7 wheel sprockets so that the 21 gear ratios are as evenly distributed across the interval [1,4].

  6. Notation p(i) = #teeth on the i-th pedal sprocket, for i=1:3. w(i) = #teeth on the i-th wheel sprocket, for i=1:7. This is a 10—parameter design problem.

  7. Things to Do • Define an Objective Function We need to measure the quality of a particular gear ratio distribution 2. Identify constraints. Sprockets are only available in certain sizes etc. Typical activity in Engineering Design

  8. The Quality of a Gear RatioDistribution Ideal: 4 1 Good: Poor:

  9. Average Discrepancy Sort the gear ratios: g(1) < g(2) <… < g(21) Compare g(i) with x(i) where x = linspace(1,4,21).

  10. function tau = ObjF(p,w); g = []; for i=1:3 for j=1:7 g = [g p(i)/w(j)]; end end g = sort(g); dif = abs(g – linspace(1,4,21)); tau = sum(dif)/21;

  11. There Are Other ReasonableObjective Functions g = sort(g); dif = abs(g –linspace(1,4,21)); tau = sum(dif)/21; Replace “sum” with “max”

  12. Goal Choose p(1:3) and w(1:7) so that objF(p,w) is minimized. This defines the “best bike.” Our plan is to check all possible bikes. A 10-fold nested loop problem…

  13. A Simplification We may assume that p(3) < p(2) < p(1) and w(7)<w(6)<w(5)<w(4)<w(3<w(2)<w(1) Relabeling the sprockets doesn’t change the 21 gear ratios.

  14. How Constraints Arise Purchasing says that pedal sprockets only come in six sizes: C1: p(i) is one of 52 48 42 39 32 28.

  15. How Constraints Arise Marketing says the best bike must have a maximum gear ratio exactly equal to 4: C2: p(1)/w(7) = 4 This means that p(1) must be a multiple of 4.

  16. How Constraints Arise Marketing says the best bike must have a minimum gear ratio exactly equal to 1: C3: p(3)/w(1) = 1

  17. How Constraints Arise Purchasing says that wheel sprockets are available in 31 sizes… C4: w(i) is one of 12, 13,…,42.

  18. Choosing Pedal Sprockets Possible values… Front = [52 48 42 39 32 28]; Constraint C1 says that p(1) must be divisible by 4. Also: p(3) < p(2) < p(1).

  19. The Possibilities.. 52 48 42 52 39 32 48 39 28 52 48 39 52 39 28 48 32 28 52 48 32 52 32 28 42 39 32 52 48 28 48 42 39 42 39 28 52 42 39 48 42 32 42 32 28 52 42 32 48 42 28 52 42 28 48 39 32

  20. The Loops.. Front = [52 48 42 39 32 28]; for i = 1:3 for j=i+1:6 for k=j+1:6 p(1) = Front(i); p(2) = Front(j); p(3) = Front(k);

  21. w(1) and w(7) “for free”.. Front = [52 48 42 39 32 28]; for i = 1:3 for j=i+1:6 for k=j+1:6 p(1) = Front(i); p(2) = Front(j); p(3) = Front(k); w(1) = p(3); w(7) = p(1)/4;

  22. What About w(2:6) Front = [52 48 42 39 32 28]; for i = 1:3 for j=i+1:6 for k=j+1:6 p(1) = Front(i); p(2) = Front(j); p(3) = Front(k); w(1) = p(3); w(7) = p(1)/4; Select w(2:6)

  23. All Possibilities? for a=12:w(1) for b = 12:a-1 for c = 12:b-1 for d = 12:c-1 for e = 12:d-1 w(2) = a; w(3) = b; etc

  24. Reduce the Size of TheSearch Space Build an environment that supports something better than brute force search…
