  1. 5LNC - background information • Annex 11, Chapter 2, Appendix 2 • Designators for significant points not marked by the site of a radio navigation aid • 1960’s –140 670 ICAO codes • APAC 27 535 • EUR/NAT 38 598 • MID 12 934 • WACAF 18 437 • SAM 18 629 • NACC 19 131 • ESAF 5 406 OCT 1983 + NOV 1985

  2. 5LNC - codes dispatch

  3. 5lnc – Traditional Registration

  4. 5LNC - Need for dynamic change • ICARD designed to • Meet requirements set in Annex 11, Chapter 2 (2.14) - Appendix 2 • Ensure unique designators allocations (ICAO Strategic Objective A) • Enhance 5LNCs management worldwide (ICAO Strategic Objective D)

  5. A web based system since 1998 5LNC on-line registration

  6. ICARD for all Accessing ICARD : www.eurocontrol.int/icard/

  7. ICARD web page http://www.eurocontrol.int/icard/public/standard_page/5lnc.html

  8. ICARD for AuthorisedUsers • https://extranet.eurocontrol.int/

  9. ICARD- Authorised user menu

  10. Search for existing code

  11. Search codes withspecific pattern

  12. Searchfromgeographical position

  13. Posting a request - 1st option Fromreservelist 1- type-in given code 2-Select Search 3-code isunderlined (active) – click and proceedwithrequest

  14. Posting a request – 2nd option Fromreservelist 1- type-in preference 2-click « Search » 3-select one of the blue code and proceedwithrequest

  15. Posting a request – 3rd option Fromreservelist 1- type-in preference, if any 2- and/or excludingletters 3-click « Search » 4-select and proceewithrequest

  16. Mandatory 1 - Coordinates Allocation withoutcoordinatesis not authorised

  17. Mandatory 2 – proximitysearch To finalise a request for allocation, the proximitysearchwith « map » and « list » functionsismandatory and remains the authoriseduser’sresponsibility

  18. Proximity check with listing The authorised user is made aware of the soundinglikeproximity. Anotherselectionwillthenberequired Note: 500NM is the radius currentlydetermined as safe for a soundinglikeproximity

  19. Proximity check withmapview With the mapfunction , the future 5LNC isidentifiedwith a blue label. Similar codes within a close proximity are highlighted in red

  20. RemindingSafety issues Warnings are prompted to draw the authoriseduser’s attention on the necessity to modify the request.

  21. Posting a 5LNC request –recommended option • From reserve list : random search from given coordinates 1- no need for specific pattern 2- knowncoordinates 3- click « search » for random 4- a list of 30 codes withproximity check doneisautomaticallygenerated 5- request for allocation canbefinalised

  22. Check myrequest • Possible modifications for pending requests

  23. On-line Downloads

  24. Information on duplicates

  25. A milestone for ICARD • 2010 = ICARD Global • SAM and NACC now on board • AFI next and last ICAO region • ICARD soonready for • a unique database • a greaterchoice of codes • possibilities to safelycreate new 5LNCs • Our next challenge • Global coordination • 5LNC update • Clearing duplicates

  26. Gracias Thank you for your attention ! Nikki Goldschmid 林 琪 妮 ICAO EUR/NAT Paris - ICARD data manager ngoldschmid@paris.icao.int  Tel:  +33 (0)14641 8528
