Scissor Lifts

With modern automatic and safety features, the European Scissors lifts offer perfectly synchronized platforms for repair and alignment operations. The Bowlin Enterprises International takes pride in offering state-of-the-art units for various automotive applications. Find the heavy duty electric hydraulic scissor lift at a special price, only at Bowlin. Feel free to consult us at 800-579-4625.

bowlin
Télécharger la présentation

Scissor Lifts

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Scissor Lifts

  2. WertherStratos SR/M Lift • Easy 1-click operation converts drive-on/off ramps to weight supporting platform extension for long wheel-base vehicles • Hydraulic synchronization of platforms • Overload safety-valve • Safety-valve in case of sudden loss of pressure • Automatic lowering control • Dead man controls 24V • Set of 4 rubber pads • Buzzer on last portion of descent Capacity 7000 lbs Weight 1600 lbs Lifting/Lowering 35/40 s Lifting Height 1945 mm Motor 230V-60Hz-1-phase

  3. WertherStratos S39 Lift • Hydraulic synchronization of platforms • Overload safety-valve • Safety-valve in case of sudden loss of pressure • Dead man controls 24V • Set of 4 rubber pads • Buzzer on last portion of descent Capacity 8800 lbs Weight 1600 lbs Lifting/Lowering 35/40 s Lifting Height 1.900 mm* Motor 230V-60Hz-1-phase

  4. WertherSaturnus 45 • Hydraulically synchronized platforms and lifting tables • Overload safety-valve • Safety-valve in case of sudden loss of pressure • “Dead man” controls 24V • Set of 4 rubber pads (LT and ATLT) • Front recesses and rear slip plates for wheel alignment on models AT and ATLT Capacity 10,000 lbs Weight 3300-5000 lbs Lifting/Lowering 50 s Lifting Height 2140 mm + (565mm**) Minimum Height 330mm Pneumatic Feed 6-8 bar Motor 4 HP 230V-60Hz-3-phase
