1. ???? ?????? ???? (???? 2)???? ???? ??? ?????? ??? ????
?"? ?. ????
2. CLINICAL APPROACH, SOME BACKGROUND & the FUTURE
3. VOCABULARY I CO - cardiac output = SV x HR AND also
CO = ?P / SVR ? ?P (driving pressure) = MAP - CVP
SVR systemic vascular resistance .
PVR pulmonary vascular resistance.
CaO2 art O2 content [(1.34 x Hb x O2sat) + (pO2 x 0.003)].
DO2 - O2 delivery (CO2 x CO).
VO2 O2 consumption [CO x CO2 x O2 extraction].
O2 extraction the difference in CO2 between the aorta and the pulmonary artery.
4. VOCABULARY II Drugs:
Nitroprusside Nipride [check cyanide or isothiocyanate]
Nitroglycerine NTG [check methemoglobin]
Adrenaline Epinephrine (USA)
Noradrenaline Norepinephrine (USA)
Milrinone Primacor
Dobutamine Dobutrex
5. S E P T I C S H O C K
7. What do we need to diagnose SEPTIC SHOCK ?
Septic shock is suspected in children with the inflammatory
triad: fever (or hypothermia), tachycardia & vasodilation (common in benign pediatric infections) + signs of low perfusion
such as ?
CNS changes (? in mental status, irritability, hypotonia)
Prolonged capillary fill (> 2 sec, cold shock) -> common
Flash capillary fill (warm shock) -> less common
? urine output
8. DEFINITIONS OF SHOCK
9. SEPTIC SHOCK: WARM SHOCK Early, compensated, hyperdynamic state
Clinical signs
Warm extremities with bounding pulses, tachycardia, tachypnea, confusion
Physiologic parameters
widened pulse pressure, increased cardiac ouptut and mixed venous saturation, decreased systemic vascular resistance
Biochemical evidence:
Hypocarbia, elevated lactate, hyperglycemia
10. Late, uncompensated stage with drop in cardiac output
Clinical signs
Cyanosis, cold and clammy skin, rapid, thready pulses, shallow respirations
Physiologic parameters
Decreased mixed venous sats, cardiac output and CVP, increased SVR, thrombocytopenia, oliguria, myocardial dysfunction, capillary leak
Biochemical abnormalities
Metabolic acidosis, hypoxia, coagulopathy, hypoglycemia
11. SEPTIC SHOCK (CONT)
12. GOALS OF 1ST HOUR RESUSCITATION (I) Maintain oxygenation, ventilation, circulation and threshold heart rate (next slide)
Therapeutic end points:
Capillary refill; no difference between peripheral & central pulses; warm extremities; urine > 1 mL/kg/h; normal mental status & BP for age
Monitoring: pulse oximeter; cont ECG; A-line; continuous temp (core & peripheral); bladder catheter; repeated glu & iCa
14. GOALS OF 1ST HOUR RESUSCITATION (II) Airway & breathing: reasons to intubate ? work of breathing; respiratory acidosis (pCO2 > 60 mmHg, pH < 7.25 with nl BE); hypoxia (pO2/FiO2 < 200); loss of airway protection 2nd to
? mental status.
Circulation: two peripherals, intraosseous, cut-down. If inotropes are to be given ? central venous line.
Fluids: repeated 20 mL/kg boluses. Follow rales, gallop, hepatomegaly, & ? work of breathing. Sometimes 200 mL/kg were infused.
Vasoactive drugs: Dopamine is 1st line. If shock remains resistent: Adrenaline for cold shock (? & ? effects) and Noradrenaline for warm shock (?-effect).
15. GOALS OF 1ST HOUR RESUSCITATION (III) Hydrocortisone Tx: *adrenal insufficiency should be suspected (purpura fulminans; catecholamine-resistance; hx of CNS abnormality or prior chronic steroid therapy).
* adrenal insufficiency = total cortisol < 18 mg/dL.
Dose? 1-2 mg/kg for stress coverage to 50 mg/kg for shock bolus followed by same dose as a 24 hour continuous infusion.
16. GOALS OF STABILISAZTION Goals: normal perfusion; perfusion pressure normal for age; mixed venous O2 saturation > 70%; 3.3 < CI < 6.0 L/min/m2.
Hemodynamic support may be required for days. There are several variations:
low C.O. and high SVR ? consider Nipride/NTG + steroids; Milrinone is another option.
high C.O. and low SVR ? Norepinephrine + steroids.
low C.O. and low SVR ? Adrenaline + steroids.
Shock refractory to cathecolamines ? r/o pneomothorax, tamponade, Addison, hypothyroid, ongoing blood loss or an abdominal catastrophy.
CONSIDER ECMO
18. CAN WE CHANGE THE COURSE OF AN INFECTIOUS DISEASE ?OR IS THE PICU IMPORTANT ?
19. June 1992 December 1997 (n=331)
Demographics:
Median age 2 y & 8 m (range 5 w to 17.5 y)
M / F - 143:188
Septicemia 281; meningitis 50
deaths:
In PICU: total 33 [29 (10%) septic, 3 (6%) meningitis]
Before arriving PICU: total 29
In 1997 there were 2/111 deaths (predicted 38/111)
The proportion of complications remained unchanged (~5.5% for amputations or skin grafting; ~8% for neurological abnormalities)
20. MD CENTERALIZED CLINICAL MANAGEMENT (I) When dx suspected? prompt PCN injection by the family physician (GP)
Continuous telephone advice by PICU attending prior to arrival of mobile team
Mobile Intensive Care Team led by PICU attending & nurse transferred all patients to the central unit
Elective intubation & ventilation, hemodynamic monitoring, and ongoing resuscitation performed at referring hospital
Patient stabilized prior to transport
21. Photocopies of all documentation done
Treatment included
Aggressive fluid resuscitation (4.5% Albumin)
Early intubation and ventilation
Generous use of Inotropes
Correction of coagulopathy
Correction of metabolic derangements (K, Ca, Mg, Phosph, Bicarb & Glu)
Early renal replacement therapy
MD CENTERALIZED CLINICAL MANAGEMENT (II)
24. DO WE HAVE A SPECIFIC TARGET ?
25. TREATMENT OF GRAM-NEGATIVE BACTEREMIA AND SEPTIC SHOCK WITH HA-1A HUMAN MONOCLONAL ANTIBODY AGAINST ENDOTOXIN. ZEIGLER EJ ET ALN Engl J Med. 1991 Feb 14;324(7):429-36 HA-1A is an IgM monoclonal ab that binds to the lipid A domain of endotoxin.
543 adult patients with sepsis presumed to be of gram-negative origin (not necessarily shock or bacteremia proven !)
Total mortality: placebo 43%; HA-1A 39% (p=0.24).
Among the 200 who had gram-negative bacteremia mortality was 45/92 (49%) in the placebo group and 32/105 (30%) in the HA-1A group (p=0.014).
Follow-up studies ?drug increases mortality and was abandoned.
26. THE NEXT DECADE SAW DOZENS OF FAILED TRIALS AND MILLIARDS OF $$ WASTED
29. ACTIVATED PROTEIN C
33. Xigris 12/2003 ? NO DATA in CHILDREN ! Despite that Eli Lilly insists on full price
34. HEMODYNAMIC VARIABLES in DIFFERENT SHOCK STATES
35. FINAL THOUGHTS Recognize compensated shock quickly- have a high index of suspicion, remember tachycardia is first sign. Hypotension is late and ominous.
Gain access quickly- if necessary use an IO line.
Administer adequate amounts of fluid rapidly. Remember ongoing losses.
Correct electrloytes and glucose problems quickly.
If the patient is not responding the way you think he should, broaden your differential, think about different types of shock.
