  1. Universal system for engine control enhancementmidterm presentation Prestenters : Ehab Shakour Gaby Shakour Instructor : MoniOrbach

  2. Our project • Engine Control unit • What is an ECU ( pros cons) • What is there in the market • What are we aspiring for

  3. The car • Diagram of ECU connecting to the car • List of input/output signals

  4. ECU • Input Output System • Digital Signals Processing with FPGA • RealTime Feedback • Overall system controller • Diagram of ECU (FPGA and PCB)

  5. PCB • Why of PCB • PCB general layout and major parts with connections • Diagram of INPUT system • Diagram of OUTPUT system • Some numbers: channels, voltage range , current range ,input impedance , output impedance , clock speed ,sampling speed, defencesystems,connectors I/O, power.

  6. Computresimulatuion • The need for a computer simulation • Labview Platform • What we’ll be testing

  7. Tasks • Complete PCB design • Build simulator • Test PCB • Next semester: • Build FPGA • Integrate system • Test whole system

  8. Thank you
