PIC processor

PIC processor. Size doesn’t matter!. Agenda. Overview Hardware Environment B o o tloader Debug options Features PIC Start. Overview. Use of PC *.Hex files Use of Programmer PCB with PIC processor. Hardware -> PCB. Analyse system Select a processor Design a PCB

calais
Télécharger la présentation

PIC processor

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. PIC processor Size doesn’t matter! CIMSOLUTIONS B.V.

  2. Agenda • Overview • Hardware • Environment • Bootloader • Debug options • Features • PIC Start CIMSOLUTIONS B.V.

  3. Overview • Use of PC • *.Hex files • Use of Programmer • PCB with PIC processor CIMSOLUTIONS B.V.

  4. Hardware -> PCB • Analyse system • Select a processor • Design a PCB • Determine clock frequency CIMSOLUTIONS B.V.

  5. Hardware -> layout CIMSOLUTIONS B.V.

  6. Hardware -> Programmer • Pick a programmer: JDM programmer • You can find many programmer on the internet CIMSOLUTIONS B.V.

  7. Hardware -> JDM Programmer CIMSOLUTIONS B.V.

  8. Environment -> MP LAB MP LAB features: • Editor • Simulator: • Breakpoints • Real time or single step • Watches • Compiler: CCS compiler CIMSOLUTIONS B.V.

  9. Screenshot MPLAB CIMSOLUTIONS B.V.

  10. Bootloader • www.microchipc.com • Tiny bootloader • Etc... (Many more on the internet) CIMSOLUTIONS B.V.

  11. Bootloader principle CIMSOLUTIONS B.V.

  12. In-circuit debugger Two hardware pins are required (RB6,RB7) • Execute real time or single step • Breakpoints • Real time or single step • Watches CIMSOLUTIONS B.V.

  13. In-circuit emulator • Communicates with parallel port • Full speed emulation • Trace registers and data • Unlimited breakpoints • Time stamp • Sophisticated trace analysis CIMSOLUTIONS B.V.

  14. Features • RS232 (MAX 232) • SPI • USB • CAN • LIN CIMSOLUTIONS B.V.

  15. PIC start • Programmer • RS232 cable • power supply • user's guide • MPLAB IDE • PICC Lite Compiler • sample PIC16F84 microcontroller CIMSOLUTIONS B.V.
