  1. WS-Security Additional Material

  2. Security Element: enclosing information • UsernameToken block • Defines how username-and-password info is enclosed in SOAP • Password must be protected against eavesdroppers (enc) and replay (timestamp/nonce) • BinarySecurityToken block • Encloses binary data • An X.509 certificate or a Kerberos ticket • Has an identifier (Id), a value (ValueType), and an encoding (EncodingType) • XML Signature KeyInfo may point to a certificate used in signing using a Reference to its Id. • Similar for XML Encryption. • So we can sign/encrypt data with a certificate in the header.

  3. ID References • A new global attribute: wsu:Id attribute • <anyElement wsu:id=”..”>..</anyElement> • Note that the SOAP processor needs to support this • wsu:id a WS-Security namespace (wssecurity-secext-1.0.xsd) • Recipients do not need to understand the full schema of the message for processing the security elements • Two wsu:Id attributes within an XML document MUST NO have the same value • Recommended that wsu:Id is used instead of a more general transformation, especially XPath

  4. Signatures • Does not use the Enveloped Signature Transform • So sig does not envelope signed data • Due to mutability of SOAP header • Does not use the Enveloping Signature • So sig is not appended as a child to the document • The sig is appended to the security block • Explicitly include the elements to be signed • Allows for extensions, multiple signatures, etc.

  5. Signing Messages • Multiple signature entries MAY be added into a single SOAP Envelope within one <wsse:Security> header block • MUST be prepended to the existing content • <ds:Reference> elements contained in the signature should refer to a resource within the enclosing SOAP envelope • <wsse:SecurityTokenreference> • How to locate a key in a security token? • Extensible mechanism that provides an open content model for referencing security tokens • Specification considers only use in a header block • New reference option for XML signature • STR Deference Transform • Applied to a SecurityTokenreference • Means that the output is the token referenced by the element, not the element itself • You can conveniently locate and sign security tokens anywhere in the header

  6. XML Encryption Example

  7. Encrypt Decrypt Public key Private key Asymmetric Key Pair Encryption

  8. XML Encryption <EncryptedData Id? Type? MimeType? Encoding?> <EncryptionMethod/>? <ds:KeyInfo> <EncryptedKey>? <AgreementMethod>? <ds:Keyname>? <ds:RetrievalMethod>? <ds:*>? </ds:KeyInfo> <CipherData> <CipherValue>? <CipherReference URI?>? </CipherData> <EncryptionProperties>? </EncryptedData>

  9. Example • SOAP Envelope • SOAP Header • WS Security • Security token (a certificate) • Encryption key (passing symmetric key) • Signature • SOAP Body • Encrypted content

  10. Security block Overall message structure <?xml version="1.0" encoding="utf-8"?> <soap:Envelope> <soap:Header> <wsse:Security> <wsse:BinarySecurityToken>...</wsse:Binary...> <xenc:EncryptedKey>...</xenc:EncryptedKey> <ds:Signature> <ds:SignatureValue>...</ds:SignatureValue> <ds:KeyInfo>...</ds:KeyInfo> </ds:Signature> </wsse:Security> </soap:Header> <soap:Body wsu:Id="body"> <xenc:EncryptedData>...</xenc:EncryptedData> </soap:Body> </soap:Envelope> 1. 2. 3. 4.

  11. 1. Binary security token <wsse:Security> <wsu:Timestamp wsu:Id="T0"> <wsu:Created> 2001-09-13T08:42:00Z </wsu:Created> </wsu:Timestamp> <wsse:BinarySecurityToken ValueType="...#X509v3" wsu:Id="X509Token" EncodingType="...#Base64Binary"> ABCDEF.... </wsse:BinarySecurityToken> <xenc:EncryptedKey>...</xenc:EncryptedKey> <ds:Signature>...</ds:Signature> </wsse:Security>

  12. 2. Passing encryption key We are using another certificate for asymmetric crypto. This one is for symmetric <xenc:EncryptedKey> <xenc:EncryptionMethod Algorithm="...#rsa-1_5"/> <ds:KeyInfo> <wsse:KeyIdentifier EncodingType="...#Base64Binary" ValueType="...#X509v3"> ABCDEF.... </wsse:KeyIdentifier> </ds:KeyInfo> <xenc:CipherData> <xenc:CipherValue>...</xenc:CipherValue> </xenc:CipherData> <xenc:ReferenceList> <xenc:DataReference URI="#enc1"> </xenc:ReferenceList> </xenc:EncryptedKey> Encrypted symmetric key Reference to cipher data

  13. 3. Actual signature <ds:Signature> <ds:SignedInfo> <ds:CanonicalizationMethod algorithm="http://...-exc-c14n#"/> <ds:SignatureMethod algorithm="http://...#rsa-sha1"/> <ds:Reference URI="#T0">...</ds:Reference> <ds:Reference URI="#body">...</ds:Reference> …. </ds:SignedInfo> <ds:SignatureValue> ..... </ds:SignatureValue> <ds:KeyInfo> <wsse:SecurityTokenReference> <wsse:Reference URI="#X509Token"/> </wsse:SecurityTokenReference> </ds:KeyInfo> </ds:Signature> Exclusive canonicalization References & digests to data Reference to certificate.

  14. 3. SignedInfo in more detail <ds:SignedInfo> <ds:CanonicalizationMethod Algorithm="http://...-exc-c14n#"/> <ds:SignatureMethod Algorithm="http://...#rsa-sha1"/> <ds:Reference URI="#T0"> <ds:Transforms> <ds:Transform Algorithm="http://...exc-c14n#"/> </ds:Transforms> <ds:DigestMethod Algorithm="http://...#sha1"/> <ds:DigestValue>...</ds:DigestValue> </ds:Reference> <ds:Reference URI="#body"> <ds:Transforms> <ds:Transform Algorithm="http://...exc-c14n#"/> </ds:Transforms> <ds:DigestMethod Algorithm="http://...#sha1"/> <ds:DigestValue>...</ds:DigestValue> </ds:Reference> </ds:SignedInfo>

  15. 4. Actual message body <soap:Body wsu:Id="body"> <xenc:EncryptedData Type="http://www.w3.org/2001/04/xmlenc#Element" wsu:Id="enc1"> <xenc:EncryptionMethod Algorithm="http://www.w3.org/2001/04/xmlenc#tripledes-cbc"/> <xenc:CipherData> <xenc:CipherValue>...</xenc:CipherValue> </xenc:CipherData> </xenc:EncryptedData> </soap:Body> </soap:Envelope>

  16. SAML Examples

  17. Attribute assertion • An issuing authority asserts that: • subject S • is associated with attributes A,B,.. • with values ”a”,”b”,… • Typically this would be gotten from an LDAP repository • ”john.doe” in ”example.com” • is associated with attribute ”Department” • with value ”Human Resources”

  18. Example attribute assertion <saml:Assertion ...> <saml: Conditions .../> <saml:AttributeStatement> <saml:Subject> <saml:NameIdentifier SecurityDomain="example.com" Name="johndoe" /> </saml:Subject> <saml:Attribute AttributeName="PaidStatus" AttributeNameSpace="http://example.com"> <saml:AttributeValue> PaidUp </saml:AttributeValue> </saml:Attribute> </saml:AttributeStatement> </saml:Assertion>

  19. Authorization decision assertion • An issuing authority decides whether to grant the request • by subject S • for access type A • to resource R • given evidence E • The subject could be a human or a program • The resource could be a web page or a web service, for example

  20. Example authorization decision assertion <saml:Assertion ...> <saml:Conditions .../> <saml:AuthorizationStatement Decision="Permit" Resource="http://example.com/res123"> <saml:Subject> <saml:NameIdentifier SecurityDomain="example.com" Name="johndoe" /> </saml:Subject> </saml:AuthorizationStatement> </saml:Assertion>
