  1. WS – Security Policy Prabath Siriwardena Director, Security Architecture

  2. Why we need a policy ? • How come users get to know the security requirements of your web service? • Web service may need client to authenticate • Web service may need client to sign all his requests • Client may need some part of the response from the service to be encrypted • Client need the service to sign the entire response first and then encrypts

  3. WS-Policy • General framework for endpoints to express requirements. • NOT just for security requirements • Requirements are expressed in terms of a ‘Policy’ • WS-Policy is a set of specifications providing a generalized mechanism for describing policy in a machine readable way.

  4. WS-Policy & WSDL • WSDL focuses on function descriptions • Non-functional descriptions and QoS aspects are covered by WS-Policy • Web services clients do not have a WSDL, yet WS-Policy also applies to web services clients

  5. WS-Policy Framework • WS-Policy, defines a framework for describing policy assertions. • WS-PolicyAttachment, describes how policies are attached to resource [e.g. WSDL] • WS-PolicyAssertions, describes a common set of assertions that are applicable across different domains.

  6. WS-Policy • Basic operators wsp:All wsp:ExactlyOne

  7. WS-Policy -Example <wsp:Policy> <wsp:ExactlyOne> <wsp:All> <A/> <B/> </wsp:All> <wsp:All> <A/> <C/> </wsp:All> </wsp:ExactlyOne> </wsp:Policy>

  8. WS-Policy • <wsp:All> and <wsp:ExactlyOne> are commutative • <wsp:All> and <wsp:ExactlyOne> are associative • <wsp:All> and <wsp:ExactlyOne> are idempotent • <wsp:All> and <wsp:ExactlyOne> are distributive

  9. WS-SecurityPolicy • Based on WS-Policy • Various groups of policy assertions • Expressed in WSDL • Defines six policy assertions that apply to WS-Security • To express security requirements of a Web service according to the WS-Policy spec • What needs to be protected • What tokens to use • Algorithms, reference types, etc..

  10. Assertion Types • Protection assertions • Required Elements Assertion • Token assertions • Security Binding assertions • Supporting token assertions • Protocol assertions

  11. Protection Assertions • Specify what needs to be protected • Integrity Assertions • Confidentiality Assertions

  12. Protection Assertions - Integrity SignedParts This assertion specifies the parts of the message that need integrity protection. <sp:SignedParts ... > <sp:Body /> <sp:Header Name="" Namespace=""/> </sp:SignedParts>

  13. Protection Assertions - Integrity SignedElements This assertion is used to specify arbitrary elements in the message that require integrity protection. <sp:SignedElements XPathVersion="“ > <sp:XPath>xs:string</sp:XPath> </sp:SignedElements>

  14. Protection Assertions - Confidentiality EncryptedParts This assertion specifies the parts of the message that need confidentiality protection. . <sp:EncryptedParts ... > <sp:Body /> <sp:Header Name="" Namespace=""/> </sp:EncryptedParts >

  15. Protection Assertions - Confidentiality EncryptedElements This assertion is used to specify arbitrary elements in the message that require confidentiality protection. <sp:EncryptedElements XPathVersion="“ > <sp:XPath>xs:string</sp:XPath> </ sp:EncryptedElements >

  16. Protection Assertion Example <sp:SignedParts xmlns:sp="http://...securitypolicy"> <sp:Body/> <sp:Header Name="To" Namespace="http://.../ws/2004/08/addressing"/> <sp:Header Name="From" Namespace="http://.../ws/2004/08/addressing"/> </sp:SignedParts> <sp:EncryptedParts xmlns:sp="http://...securitypolicy"> <sp:Body/> </sp:EncryptedParts>

  17. Required Elements Assertion • This assertion is used to specify header elements that the message MUST contain. <sp:RequiredElements XPathVersion="”> <sp:XPath>…</sp:XPath> </sp:RequiredElements>

  18. Token Assertions • Token assertions specify the type of tokens to use to protect or bind tokens and claims to the message. • UsernameToken • X. 509 • IssuedToken

  19. Token Assertions - UsernameToken • This element represents a requirement to include a UsernameToken <sp:UsernameToken sp:IncludeToken=“”> <wsp:Policy> <sp:WssUsernameToken11 ... /> </wsp:Policy> </sp:UsernameToken>

  20. Token Assertions - IssuedToken • This element represents a requirement for an issued token, that is one issued by some token issuer. <sp:IssuedToken sp:IncludeToken=“”> <sp:Issuer>..</sp:Issuer> <sp:RequestSecurityTokenTemplate TrustVersion="" > </sp:RequestSecurityTokenTemplate> <wsp:Policy> </wsp:Policy> </sp:IssuedToken>

  21. Token Assertions - IssuedToken • This element represents a requirement for an issued token, that is one issued by some token issuer.

  22. Token Assertions – X.509 This element represents a requirement for a binary security token carrying an X509 token.

  23. Token Assertions – X.509 <sp:X509Token sp:IncludeToken=""> <wsp:Policy> <sp:RequireKeyIdentifierReference /> <sp:RequireIssuerSerialReference /> <sp:RequireEmbeddedTokenReference /> <sp:RequireThumbprintReference /> <sp:WssX509V1Token10/> <sp:WssX509V3Token10 /> <sp:WssX509Pkcs7Token10 /> <sp:WssX509PkiPathV1Token10/> <sp:WssX509V1Token11/> <sp:WssX509V3Token11/> <sp:WssX509Pkcs7Token11/> <sp:WssX509PkiPathV1Token11/> </wsp:Policy> </sp:X509Token sp:IncludeToken>

  24. Token Assertions • Token Inclusion • Never • Always • AlwaysToRecipient • Once

  25. Token Assertions • What we didn’t cover... • KerberosToken Assertion • SecurityContextToken Assertion • SecureConversationToken Assertion • SamlToken Assertion • HttpsToken Assertion

  26. Security Bindings • A set of properties that together provide enough information to secure a given message exchange. • The bindings are identified primarily by the style of protection encryption used to protect the message exchange. • A binding defines the following security characteristics: • • The minimum set of tokens that will be used and how they are bound to messages • • Any necessary key transfer mechanisms • • Any required message elements (e.g. timestamps) • • The content and ordering of elements in the wsse:Security header. Elements not specified in the binding are not allowed. • • How correlation of messages is performed securely (if applicable to the message pattern)

  27. Security Binding Assertion • AlgorithmSuite Assertion • Layout Assertion • TransportBinding Assertion • SymmetricBinding Assertion • AsymmetricBinding Assertion

  28. AlgorithmSuite • This assertion indicates a requirement for an algorithm suite <sp:AlgorithmSuite> <wsp:Policy> <sp:Basic256 /> <sp:Basic192 /> <sp:Basic128/> <sp:TripleDes/> </wsp:Policy> </sp:AlgorithmSuite>

  29. AlgorithmSuite

  30. Layout This assertion indicates a requirement for a particular security header layout <sp:Layout> <wsp:Policy> </wsp:Policy> </sp:Layout>

  31. Layout

  32. TransportBinding • Indicates that the transport layer is used to satisfy the security requirements <sp:TransportBinding> <wsp:Policy> <sp:TransportToken> <wsp:Policy> ... </wsp:Policy> </sp:TransportToken> <sp:AlgorithmSuite> ... </sp:AlgorithmSuite> <sp:Layout> ... </sp:Layout> <sp:IncludeTimestamp/> </wsp:Policy> </sp:TransportBinding>

  33. TransportBinding

  34. SymmetricBinding • Indicates that the message layer is used to satisfy the security requirements • Defines "Encryption Token" and "Signature Token" properties • Where multiple messages are exchanged the tokens perform the same functions for all messages

  35. SymmetricBinding

  36. AsymmetricBinding • Indicates that the message layer is used to satisfy the security requirements • Defines “Initiator Token” and “Recipient Token”properties • The Initiator Token is used for the message signature from initiator to recipient, and encryption from recipient to initiator. • The Recipient Token is used for encryption from initiator to recipient, and for the message signature from recipient to initiator. • Where multiple messages are exchanged the tokens perform different functions

  37. AsymmetricBinding

  38. SupportingTokens • Services may require multiple sets of claims to be presented • Corresponds to additional tokens in a message • Supporting tokens are included in the security header and may optionally include additional message parts to sign and/or encrypt.

  39. SupportingTokens

  40. SupportingTokens

  41. EncryptedSupportingTokens • Encrypted supporting tokens are supporting tokens that are included in the security header and MUST be encrypted when they appear in the security header. Element encryption SHOULD be used for encrypting these tokens. • The encrypted supporting tokens can be added to any SOAP message and do not require the “message signature” being present before the encrypted supporting tokens are added. • Introduced in WS-Security Policy 1.2

  42. SignedSupportingTokens • Token specified under this assertion will be signed by the message signature.

  43. SignedSupportingTokens • If transport level security is used there won’t be any signature in the message.

  44. SignedSupportingTokens

  45. SignedEncryptedSupportingTokens • Signed, encrypted supporting tokens are Signed supporting tokens that are also encrypted when they appear in the wsse:Security header. ElementEncryption SHOULD be used for encrypting the supporting tokens. • Introduced in WS-Security Policy 1.2

  46. EndorsingSupportingTokens • Endorsing tokens sign the message signature, that is they sign the entire ds:Signatureelement produced from the message signature and may optionally include additional message parts to sign and/or encrypt.

  47. EndorsingSupportingTokens • When transport level security is used – there is no message signature and the signature generated by the supporting token will sign the Timestamp.

  48. EndorsingSupportingTokens

  49. EncryptedEndorsingSupportingTokens • Endorsing, encrypted supporting tokens are Endorsing supporting tokens that are also encrypted when they appear in the Security header. Element Encryption SHOULD be used for encrypting the supporting tokens. • Introduced in WS-Security Policy 1.2

  50. SignedEndorsingSupportingTokens • Signed endorsing tokens sign the entire ds:Signature element produced from the message signature and are themselves signed by that message signature, that is both tokens (the token used for the message signature and the signed endorsing token) sign each other.
