  1. Establishing PTK liveness during re-association Nancy Cam-Winget, Cisco Systems Inc Emily H. Qi and Jesse Walker, Intel Corporation N. Cam-Winget, et al

  2. Where we are so far… • Existing Standard & Proposals: • Pre-authentication + 4-Way Handshake at Reassociation (802.11i) • Pre-keying (04/476) • Tentative association(04/606) • Existing Proposal Problems • Pre-authentication + 4-Way Handshake at Reassociation is not fast • Otherwise 802.11r would not exist • Pre-keying and Tentative association incomplete • 802.11i replay protection tied to key freshness and peer liveness • So far, both have failed to explain how they will obtain these • Reservation introduces a novel DoS attack against network resources • Proposals must explain how to protect against these novel DoS attacks, because PAR says 802.11r can’t make security worse N. Cam-Winget, et al

  3. 4-Way Handshake Observations • 4-Way Handshake overloads ANonce, SNonce to perform two functions: • They must be different on each 4-Way Handshake to provide key separation (“fresh” keys) • They must be unpredictable to prove liveness, so are specified as random • Making nonces serve both functions serializes PTK derivation with 4-Way Handshake execution • Infeasible for STA to pre-compute PTK, because ANonce must be unpredictable N. Cam-Winget, et al

  4. Proposal • Pre-compute PTK on the STA prior to Re-Association • Establish security associations liveness and GTK at reassociation time • Not after, as 802.11i does today • Not before, as pre-keying and tentative association propose • Apply updates to the 802.11i 4-Way Handshake to allow it to meet requirements: • Eliminate 4-Way Handshake Msg 1 by making ANonce predictable for AP-to-AP transition • Embed 4-Way Handshake Msg 2 in Reassociation Request • Embed 4-Way Handshake Msg 3 in Reassociation Response • Add AP-Challenge to 4-Way Handshake Msgs 3 and 4, to prove STA liveness to AP • Don’t change the 802.11i key hierarchy N. Cam-Winget, et al

  5. AP Authenticator Optimized Re-Association with 4-way Client Supplicant Client determines new AP for roam, increments ANONCE Generates new PTKi, Generate 802.1X Optimized 4-way Message #2 Reassociate Request( 802.1X 4-way Message #2) AP validates ANONCE Generates new PTK validate 802.1X 4-way Message #2 Generate 802.1X Optimized 4-way Message #3 Reassociate Response( 802.1X 4-way Message #3) Client validates Message #3 (process flows same as TGi) 802.1X 4-way Message #4 Client and AP can now protect 802.1X and 802.11 packets N. Cam-Winget, et al

  6. Optimized 4-way Handshake • Use of 4-way Handshake as on associations defined in 802.11i: • SNonce and ANonce remain unpredictable and random • On Roam use Optimized 4-way Handshake: • ANonce becomes an incrementing counter in reassociations, used as replay protector against rekeys triggered either by IV exhaustion or roams • 4-way Message #1 is not used in the optimized 4-way handshake • Reassociation Request includes optimized Message # 2 • Message #2 conveys ANonce and PMKID STA used to generate the PTK • AP validates ANonce from STA to ensure it is not a replay • Reassociation Response includes optimized Message # 3 • Optimized Message #4 flows as defined in 802.11i • Uses PMK cacheing and established PMKID to kickstart optimized 4-way handshake • ANonce is bound to STA, BSSID and PMKID • Proposal enables 802.11i 4-way and Optimized 4-way handshakes to co-exist N. Cam-Winget, et al

  7. Two new KDE’s • ANonce in Message 2 is conveyed as KDE • AP-Challenge to ensure STA liveness proof to AP N. Cam-Winget, et al

  8. 4-way Handshake Optimized Message 2 N. Cam-Winget, et al

  9. 4-way Handshake Optimized Message 3 N. Cam-Winget, et al

  10. 4-way Handshake Optimized Message 4 N. Cam-Winget, et al

  11. Inserting 802.1X in 802.11 • 802.1X EAPOL Key Frame (Message 2 and 3) are embedded into Reassociation Request and Response in new IE N. Cam-Winget, et al

  12. Optimizations enable • Reuse of TGi • Compression of exchanges reduce latencies • Enables the STA to precompute PTK prior to association (to minimize time spent during association) • Enables the STA to plumb PTK prior to reassociation….fixes race conditions in 4-way handshake N. Cam-Winget, et al

  13. Questions? N. Cam-Winget, et al

  14. Backup slides N. Cam-Winget, et al

  15. 802.11i 4-way Handshake Message values N. Cam-Winget, et al

  16. Optimized 802.11i 4-way Handshake Message values N. Cam-Winget, et al

  17. EAPOL Key Frame Format N. Cam-Winget, et al
